HDMI 4 Ports Splitter Amplifier by Cat5 x1
HDMI Over Cat5 Extender
plus x4 Splitter
Model # 50 - 15010
Table of Contents
1.0 Introduction..............................................................2
2.0 Specifications............................................................2
3.0 Package Contents......................................................3
4.0 Panel Descriptions.....................................................4
5.0 Connection and Operation..................................................5
１
Advertisement
Table of Contents
Summary of Contents for MCM Custom Audio 50-15010
-
Page 1: Table Of Contents
HDMI 4 Ports Splitter Amplifier by Cat5 x1 HDMI Over Cat5 Extender plus x4 Splitter Model # 50 - 15010 Table of Contents 1.0 Introduction……………………………………………………..2 2.0 Specifications…………………………………….………..……2 3.0 Package Contents………………………………………….…..3 4.0 Panel Descriptions…………………………………….…….…4 5.0 Connection and Operation..........5 １... -
Page 2: Introduction
HDMI 4 Ports Splitter Amplifier by Cat5 x1 HDMI 4 Ports Splitter Amplifier by Cat5 x1 Dear Customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. 1.0 INTRODUCTION This HDMI Splitter is an HDMI splitter with four RJ45 outputs. -
Page 3: Package Contents
HDMI 4 Ports Splitter Amplifier by Cat5 x1 Output Video HDMI 1.2a Operating Frequency Video Amplifier Bandwidth 1.65Gpbs/165MHz Vertical Frequency Range 50/60Hz Resolutions(HDTV) Interlaced(50&60Hz) 480i,576i,1080i Progressive(50&60Hz) 480p,576p,720p,1080p Mechanical Size of HDMI 4 Ports Splitter Amplifier 270×180×40mm (L-W-H) Weight of HDMI 4 Ports Splitter 1300g Amplifier (Net) Size of Receiver (L-W-H) -
Page 4: Panel Descriptions
HDMI 4 Ports Splitter Amplifier by Cat5 x1 5) Four pieces of 5V DC@ 2A Power Supply. 4.0 PANEL DESCRIPTIONS HDMI 4 Port Splitter Amplifier by Cat5 x1 H D M I 4 P o r t s S p l i t t e r A m p l i f i e r b y C a t 5 X 1 P o w e r... -
Page 5: Connection And Operation
HDMI 4 Ports Splitter Amplifier by Cat5 x1 5.0 CONNECTION AND OPERATION 1) Connect the single HDMI source (such as HD-DVD, PS3, STB ) to the main HDMI input using a piece of HDMI cable. 2) Connect each piece of CAT-5e/6 cable to both of the output of the HDMI 4 Ports Splitter Amplifier and input of the Receiver.
