AT1000

User's Manual

Version 2.0

Table of Contents

Need help?

Do you have a question about the AdTrap AT1000 and is the answer not in the manual?

Questions and answers

Summary of Contents for BluePoint Security AdTrap AT1000

Page 2: Table Of Contents
User’s Manual Version 2.0 Table of Contents TECHNICAL SPECS ............................3 SAFETY REQUIREMENTS ........................... 3 GETTING STARTED ............................4 About your AdTrap ..........................4 What’s in the Box? ..........................4 What about Security? ........................4 ADTRAP LEDs AND PORTS ..........................5 INSTALLING YOUR AdTrap ..........................
Page 3: Technical Specs
TECHNICAL SPECS  Power Supply; Input: 100-240v-50/60 Hz @0.5A Output: DC 5v @3A Input Size: 5.5mm  Weight 7oz  CE Approved  Up to 350 Megabits per second Bandwidth  2x Gigabit Ethernet Ports SAFETY REQUIREMENTS CAUTION - Risk of Shock Voltage inside this unit.
Page 4: Getting Started
GETTING STARTED About your AdTrap  Can handle up to 350Mbps  Automatically stays updated as advertisers change their ad schemes  Blocks advertisements from music and video streams, mobile apps and web pages  Works with ANY Internet browser ...
Page 5: Adtrap Leds And Ports
ADTRAP LEDs AND PORTS LED LIGHT SEQUENCE Self Test Mode… AdTrap is Oﬀ/ON Oﬀ Flash Flash boo ng up… Internet found, Oﬀ/ON Flash Flash Flash con nuing to boot… AdTrap is Flash Flash Oﬀ/ON ready Power: Connector for the power cord LAN: 1 Gigabit port for the router or home computer WAN: 1 Gigabit port for the modem AdTrap User’s Manual | Page 5...
Page 6: Installing Your Adtrap
INSTALLING YOUR ADTRAP There are two ways to connect the AdTrap to your network. Proxy Mode or Inline Mode. Installation Proxy Mode: Proxy Mode AdTrap User’s Manual | Page 6...
Page 7: Adtrap Setup Utility
AdTrap Setup Utility is a program that eases the configuration of the AdTrap in proxy mode and has shortcuts to settings and updates. The setup utility does not install anything on your computer. The main function is to scan your network for an AdTrap and configure your computer to use the AdTrap as a proxy server.
Page 8: Installation Inline Mode
Installation Inline Mode: Inline Mode AdTrap User’s Manual | Page 8...
Page 9 AdTrap User’s Manual | Page 9...
Page 10: Adtrap Settings
ADTRAP SETTINGS Use: To monitor various configuration options and operational status of the AdTrap Access AdTrap Settings: 1. The Default Access is located on a label at the bottom of your AdTrap. In your browser address bar, type in the Web Admin address provided on the label. Choose one of them. Settings - Proxy Mode (Connected to an all-in-one modem &...
Page 11 Steps: Choose which configuration the AdTrap is connected Choose to change your password and your time zone Gives you information about your network and setup Gives you the opportunity to download the setup utility  AdTrap Anywhere Adtrap can be used on your mobile device over your carrier’s data plan. The phones data get transferred from your data plan to your home network through the AdTrap then back to your phone again.
Page 12  General This is where you can setup the main functions of the AdTrap. General Timezone – Set up the Timezone for your location. This will also set up the time when the AdTrap updates for 1am your local time. Hardware CPU Clock –...
Page 13: Adtrap Rules
Subnet Mask – Sets your subnet mask. Gateway – Sets your Gateway. This is usually a node or device that controls the traffic on your network. MAC Address – Allows you to change your MAC Address. Networking – DNS SERVERS Use DNS SERVERS from DHCP –...
Page 14: Reports
Reports: The AdTrap has an advanced logging system in which you can see which ads are being blocked at any time.  Real-time Blocked Ads As you are browsing the internet, you can view this page to see what add links are being blocked in real time.
Page 15: Adtrap Anyhere
AdTrap Anywhere Installing AdTrap Anywhere on your iDevices (iPhones, iPads) 1. If you are in proxy mode, you must log into your router and forward TCP port 5555 to the AdTrap IP address. 2. Use iCloud or any other backup program and backup your iPhone. 3.
Page 16 Android Devices (Your device must be rooted) 2. If you are in proxy mode, you must log into your router and forward TCP port 5555 to the AdTrap IP address. 3. Log into your AdTrap. 4. Click Settings then AdTrap Anywhere 5.
Page 17: Basic Troubleshooting
Basic Troubleshooting Factory Reset: Use the factory reset to restore the AdTrap to its original state. This will also reset the password. The updates and rules of the AdTrap will not be affected. Steps: 1. Unplug all cables including the power. 2.
Page 18: I Can Get On The Internet, But Everything Is Slow
AdTrap and the AdTrap logo, are trademarks of BluePoint Security, Inc. All other trademarks and registered trademarks in any part of this document are the property of their respective owners.
