Summary of Contents for Autocop VT2000 series
Page 1
E N G L I S H SINGLE VIDEO INTERCOM SYSTEM USER’S MANUAL VT2000 series (05 Ver.) VERSION V1.1...
Page 2
FEATURES ■ The system can expand to 2 outdoor stations (up to 8 outdoor stations or cameras) in connection with 5 monitors or audio-phones ■ Intercom communication between monitors or audio-phones ■ Simple wiring with bus of 4-core cable ■ Lock connected from outdoor station * The sketch map only shows structure of the system...
2.2 Outdoor Station VT 581 1. Microphone 2. Camera 3. Speaker 4. Call button 5. Mount box 6. Panel fixed position Note: Connection terminal Dimension: 162(H)×130(W)×50(D) and unlock port LB are designed on PCB Board. 2.3 Outdoor Station VT 584 1.
4. OPERATION ■ Normal Operation Instructions When visitor presses the “CALL” button on the outdoor station, the electronic bell in indoor monitor chimes, at the same time, the screen displays the visitors’ images. When pick up the handset (press “TALK” button on free hand indoor monitor ), you can talk with the visitors for 90 seconds.
Page 11
When monitoring or talking, press “UNLOCK” button just open the lock connected with the being supervised outdoor station. Selecting Ring Tune ■ When monitor is standby, press “UNLOCK” button for 2 seconds, the monitor plays current ring tune, and entering into the tune selecting mode. Sequentially press “UNLOCK”...
5. MOUNTING INSTRUCTION 5.1 Indoor Monitor mounting Accessory fittings: 1) Mounting Bracket and special 4 core wire are already connected with indoor monitor. 2) Three 4X25 self-taping screws are used for fastening the Mounting Bracket on the wall. Installation steps ■...
5.2 Outdoor Station mounting The location for outdoor station should keep away from snow, rain, and intensity light. The height same as indoor monitor, usually at 145~160CM. VT 584 installation steps: Drill a hole (75X75X35mm) on the wall at recommended height, mounting bracket, press outdoor station which...
6. SYSTEM CONNECTION For indoor monitors, first, connect the cable in the mount bracket, then connects the JS-VP port with the monitor by using 4 core cable (which is GX-4P-2C3 in following diagram). Power positive. +12V present when outdoor station calling or being supervised. Power negative (GND) Image signal (Video signal) Talk and control signal...
Page 15
With Jumper (Dry contact mode). Extra power supply for latch must be installed, and nearly all kinds of electronic latch can be used, please see Note 2 for reference. Incidentally, in this mode, you can continue talking and monitoring during unlock operation. POWER SUPPLY Dry contact mode...
Page 16
Wire Connection for VT581/584 VT581/584 is connected with the cable directly. See diagram for VT584. One 4 core cable is provided, with VT 581/584 connecting JS-VP cable(which is GX-4P-150 in the diagram) Wires in colour on terminal: GX-3P-150 POWER SUPPLY 1-RED(1R)...
Page 17
Wiring Diagram For Extended Monitors (1 door stations : N monitors ) REF:210W REF:210W Wiring Diagram For Extended Monitors and Outdoor Stations - 14 -...
Page 18
( 2 door stations : N monitors ) REF:210W REF:2WAY - 15 -...
7. MAIN TECHNICAL PARAMETER Power supply for indoor monitor: DC 15~18V (VT680/684/686/687 supplied by Adaptor) AC 100~240V (VT680P/684P/686P supplied by SMPS) Power supply for outdoor station: DC 10~12V (Supplied by indoor monitor) Audio-phone (VT 672): DC10~12V (Supplied by indoor monitor) Power consumption: Standby 0.5W;...
Page 20
The design and specifications can be changed without notice to the user. Right to interpret and copyright of this manual are preserved. VTK-0612...
