Videology 20Z404-27XF Instruction Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Prior to Using This Document: Videology reserves the right to modify the information in this

document as necessary and without notice. It is the user's responsibility to be certain they possess the

most recent version of this document by going to www.videologyinc.com, searching for the model

number, and comparing revision letters on the respective document, located in the document's footer.

For technical assistance with this product, please contact the supplier from whom the product was

purchased.

Videology Imaging Solutions, Inc. USA

37M Lark Industrial Parkway

Greenville, RI 02828

Tel: 401-949-5332

Fax: 401-949-5276

www.videologyinc.com

Doc # INS-20Z404-27XF

Revision: A

IMAGING SOLUTIONS INC.

Original Equipment Manufacturer

Instruction Manual

20Z404-27XF

Videology Imaging Solutions, B.V. Europe

Neutronenlaan 4

NL-5405 NH Uden, Netherlands

Tel: +31 (0) 413-256261

Fax: +31 (0) 413-251712

www.videology.nl

Issue Date: 8/24/2011

Page 1 of 38

Table of Contents

Need help?

Do you have a question about the 20Z404-27XF and is the answer not in the manual?

Questions and answers

Summary of Contents for Videology 20Z404-27XF

Page 1 Instruction Manual 20Z404-27XF Prior to Using This Document: Videology reserves the right to modify the information in this document as necessary and without notice. It is the user’s responsibility to be certain they possess the most recent version of this document by going to www.videologyinc.com, searching for the model number, and comparing revision letters on the respective document, located in the document’s footer.
Page 2: Table Of Contents
Key Action Commands - 1 (*NN 75 PP XX YY) ............... 36 10.15. Key Action Commands - 2 (*NN 75 PP XX YY) ............... 37 Contact Information ......................38 Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 2 of 38...
Page 3: Document History
More than 1,000k at Room Temperature Iris Durability More than 500k at Room Temperature Focus Length ∞ ~ 1.0m (Tele) ~ 0.01m (Wide) Signal Process Digital Signal Process Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 3 of 38...
Page 4 Phase (°) 180° (Base) 200 ± 40% 130 ± 40% 115 ± 40% Amplitude (%) 100%(Base) Phase (°) 103 ± 20° 345 ± 20° 170 ± 20° 135° (Base) Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 4 of 38...
Page 5 All other connectors on the camera module are used solely for manufacturing. (Not for user) 3.3. J208 – 3 Pin Connector (Remote Control) PIN No. NAME DC OUT Output GND (for R/C) R/C Data Input Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 5 of 38...
Page 6: Recommended Circuit For Local Controls
Menu mode will be displayed again once Menu is pressed. Menu is used to select the subcategories. 0.01uF 6.8K 8.2K 180K KEY 2 POWER BRT(+) BRT(-) SHARP(+) SHARP(-) NEG/POS ON/OFF (FREEZE) (FLIP/INVERT) Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 6 of 38...
Page 7: Auto Iris
TELE RESET WIDE 1 sec pause 1 Cycle 5.2. Focus 1V pause NEAR 1V pause 1 Cycle 5.3. Auto Iris OPEN CLOSE 3sec 3sec 6 sec 1 Cycle Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 7 of 38...
Page 8 6. Dimensions Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 8 of 38...
Page 9 7. OSD Navigation 7.1. OSD (On Screen Display) 1) OSD DISPLAY POSITION 2) DESCRIPTION Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 9 of 38...
Page 10 Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 10 of 38...
Page 11 “temporary automatic focus” category is selected. Automatic focus is also possible based on external AF command. FOCAL DIST Minimal distance the camera can focus. Ex) 10cm: Objects closer than 10cm cannot be brought into focus. Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 11 of 38...
Page 12 Can be adjusted from 0 (dark) to 48 (bright). Note: Not used while in manual mode. FLICKERLESS Removes screen flickering caused by discordance of frequency and lighting. D.S.S. Use under very low light conditions for full color surveillance. OFF, FLD 2 FLD 128 Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 12 of 38...
Page 13 Can be used in Temporary Automatic Mode only. Color will be automatically adjusted (the word “pressed” will be displayed). Adjusts R-Gain value from 0-255 BLUE Adjust B-Gain value from 0-255 Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 13 of 38...
Page 14 WHITE BAL 3D-DNR [SPECIAL] GENERAL INITIAL EXIT 7.2.7. SPECIAL  Special settings to fine tune your camera. SPECIAL D-EFFECT OFF/V-FLIP/H-FLIP SHARPNESS FREEZE COLOR [MOTION] PRIVACY INITIAL  EXIT  Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 14 of 38...
Page 15 Zone can be set to UPPER, LOWER, RIGHT, CENTER or WHOLE detection field as shown below: UPPER LEFT CENTER RIGHT LOWER SENSITIVITY Sets sensitivity to detect movement from 1 (low) to 15 (high). MENU FOCUS EXPOSURE WHITE BAL 3D-DNR SPECIAL [GENERAL] INITIAL EXIT Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 15 of 38...
Page 16 VERSION VER 1.1N INITIAL EXIT  CAM ID Displays the camera‟s ID from 0-255. LANGUAGE Displays the currently set language. PROTOCOL DEFAULT, P/D (Pelco D) P/P (Pelco P) Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 16 of 38...
Page 17 8. Communication Protocol Customer is responsible for converting RS-485 to RS-232. Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 17 of 38...
Page 18 Customer is responsible for converting RS-485 to RS-232. Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 18 of 38...
Page 19 The check sum is the sum of 9 bytes (byte0~byte8). The header must be „*‟. All bytes of the packet must be in all Capital Letters. Figure 1. Command Packet Block Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 19 of 38...
Page 20 ASCII format: 2A 32 42 37 35 30 30 30 30 Sum = 2A+32+42+37+35+30+30+30+30 = 1CA hex So, the Check Sum = CA So the complete command packet. = * 2B 75 0000 CA Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 20 of 38...
Page 21 If the camera response mode is in Skip Command response packet mode, then the camera will not send Command response packet. However, the data response packet will be transmitted to the PC even if in the skip command response packet mode. Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A...
Page 22: Command List
If user commands the One shot AF response packet, the camera will execute one shot AF action. After that action, the camera will send the One Shot AF Finished Response Packet. Format: *NNAAAAAAYY Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A...
Page 23: Response Packet Commands
**4) If you‟re in an internal or external preset mode and you‟re trying to set the non-zoom tracking mode, you can move to a non-zoom tracking mode as long as the zoom lens isn‟t tracking or in an abnormal preset position. Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A...
Page 24 Correct ? Response) Response Packet Send *00000000AA Send Command (Command Response Packet? Response) Figure 4. One Shot AF & One shot AF finished response packet (Camera ID = 00) Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 24 of 38...
Page 25: General Control Commands - 1
Auto Refresh On  *NNQQ0000YY Set Auto Refresh *NNBFPP00YY 01~FE(44min ~ 1Day 18Hour 16min)  Time Period Read Auto Refresh Read *NNBE0000YY 01~FE(44min ~ 1Day 18Hour 16min) Time Period *00RR0000YY Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 25 of 38...
Page 26 If day&night mode is auto, RR is effective value.  Day Status  Night Status D&N Auto mode Set Mode *NN95PPXXYY   D&N Day  D&N Night mode Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 26 of 38...
Page 27 Off / FLD 2 / FLD4 / FLD8 / FLD12 / FLD16 / Shutter FLD 24 / FLD 32 / FLD 64 / FLD 128  *RR000000YY Status Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 27 of 38...
Page 28 Iris Manual mode AGC Manual mode Shutter/Iris/AGC all Manual mode *NN810PXXYY Auto Exposure mode Shutter Manual mode Iris Manual mode AGC Manual mode Shutter/Iris/AGC all Manual mode  Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 28 of 38...
Page 29: Focus Control Commands
Response Don‟t Transmit One Shot AF finish Response Packet Packet Enable Transmission of One Shot AF finish Response Packet (!!) One Shot AF finish Response Packet *NNAAAAAAYY  Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 29 of 38...
Page 30: Zoom/Focus Operation Commands - 1
* α will be changed by Lens Offset Adjustment. (!!) The range of ZZZ Focus Special Mode : ( 2B0hex~offsetMax (720hex±α)) Focus Auto/Manual Mode : The range of ZZZ is decided by camera.  Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 30 of 38...
Page 31 Zoom Start Ratio (Optical Zoom Ratio) *SS0RRR00YY (00 hex ~ 1B hex) Zoom Stop Ratio (Digital Zoom Ratio) (00 hex ~ 10E hex) Reference to the Set Zoom Start ratio/Stop ratio command. Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 31 of 38...
Page 32 Don‟t Transmit Preset Response Data Enable Transmission of Preset Response Data (!!) Preset response packet : *NN111111YY * IPP (Internal Preset Position), EPP (External Preset Position), PRP (Preset Response Packet) Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 32 of 38...
Page 33 00 hex ~ FF hex : RED adjust data  Set BLUE *NNBAPPXXYY 00 hex ~ FF hex : BLUE adjust data  * MWBM (Manual WB Mode) Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 33 of 38...
Page 34: Privacy Control Commands 2
Mask Top Position (00 hex ~ 64 hex)  00~64 Read *NND8QQXXYY Mask Area 0 Mask Area 1 *QQRR0000YY Mask Area 2 Mask Area 3  Mask Top Position (00 hex ~ 64 hex)  Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 34 of 38...
Page 35 Mask Area 1 *QQRR0000YY Mask Area 2 Mask Area 3  Mask Right Position (00 hex ~ 64 hex)  Mask Initial *NNCBXXXXYY Mask 1~4 On/FF, Color, Size Initial  Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 35 of 38...
Page 36: Key Action Commands - 1 (*Nn 75 Pp Xx Yy)
▪ In white balance push auto mode, it indicates Push Action. KC_AWB_UP ▪ Switch AWB modes (automanualindooroutdoorpush auto) KC_AWB_DN ▪ Switch AWB modes in reverse sequence of KC_AWB_UP Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 36 of 38...
Page 37 ▪ Toggles Reverse/Normal mode KC_1SHOT_AF ▪ Execute Auto Focusing one time KC_DAYNIGHT ▪ Day&Night mode change, OFFAUTOON KC_MAXFLDUP ▪ Slow shutter max field up KC_MAXFLDDN ▪ Slow shutter max field down Doc # INS-20Z404-27XF Issue Date: 8/24/2011 Revision: A Page 37 of 38...
Page 38: Contact Information
Please visit our website at: http://www.videologyinc.com VIDEOLOGY IMAGING SOLUTIONS is an ISO 9001 registered video camera developer and manufacturer serving industrial, machine vision, biometric, security, and specialty OEM markets. Videology designs, develops, manufactures, and distributes video, image acquisition, and display technologies and products to OEMs worldwide.
