IMPORTANT NOTICE
Before operating the unit, please read these instructions carefully.
Retain the manual for future reference.
You are advised to follow the instructions carefully when operating the unit.
Do not use any chemical solvents, cleaning agents or corrosive detergents to clean dirt off the surface of the screen.
By doing so, you may cause irreversible damage to the surface of the TFT screen. To clean off dirt or fingerprints, we recommend
using a soft, damp, lens cleaning cloth.
Using spare parts from another manufacturer may cause permanent damage to the unit.
When operating the display unit, avoid touching or pressing the LCD glass panel.
Excessive force may cause irreparable damage to the LCD screen.
Some states restrict the use of video screens and televisions in vehicles. In the interest of safety, this monitor shouldnever be
installed where it will be visible, directly or indirectly, by the operator of the motor vehicle.
Lock the LCD screen in the fully closed position when it is not in use.
AHDM7/ 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Myron & Davis HEADREST 7.0
- Page 1 IMPORTANT NOTICE Before operating the unit, please read these instructions carefully. Retain the manual for future reference. You are advised to follow the instructions carefully when operating the unit. Do not use any chemical solvents, cleaning agents or corrosive detergents to clean dirt off the surface of the screen. By doing so, you may cause irreversible damage to the surface of the TFT screen.
-
Page 2: Main Features
MAIN FEATURES °® HEADREST 7.0 16:9 WIDE SCREEN TFT-LCD MONITOR BUILT IN DVD PLAYER BUILT IN WIRELESS HEADPHONE IR TRANSMITTER 1 AUDIO/VIDEO INPUT FULL FUNCTION WIRELESS REMOTE CONTROL (OSD) ON SCREEN DISPLAY FOR CONTROL OF PICTURE QUALITY AND FUNCTIONS FULL BAND WIRELESS FM MODULATOR WITH 6 PRESETS MEMORY. -
Page 3: Optional Accessories
DVD PLAYER Supports DVD, VCD, AUDIO CD, and MP3. MONITOR 7.0" wide screen TFT LCD active matrix STANDARD ACCESSORIES PACKAGE CONTENTS Remote control (AAA x 2 batteries) Operating manual A/V input cable OPTIONAL ACCESSORIES °X °X Single Channel Wireless IR Headphones AE21 Dual Channel Wireless IR Headphones A E22... -
Page 4: Remote Control Operation
REMOTE CONTROL OPERATION MONITOR FUNCTION DESCRIPTIONS DRIVER button PASSENGER button Press these buttons to select which monitor you would like to control with the remote control. POWER button Press this button to turn on the selected monitor, press again to turn off the monitor. SOURCE button Press SOURCE button to toggle between sources on the selected monitor. - Page 5 DVD FUNCTION DESCRIPTIONS NUMBER buttons DOWN button Direct access for CD tracks, DVD chapters, and password setting. Moves the selection or cursor down. PBC/MENU button NEXT button Toggles available subtitles when playing VCD 2.0, or shortcut to Advances to the next chapter or track. DVD selection title menu.
-
Page 6: Monitor Operation
MONITOR OPERATION Adjust the monitor to a comfortable viewing angle free from glare or bright ambient light. ● Press the POWER button on the unit or remote to turn on the monitor. ● Press the SOURCE button to select viewing source. ●... - Page 7 ● The BRIGHTNESS adjustment controls the intensity of the ● The CONTRAST adjustment controls the black level ratio. backlight. ● The COLOR adjustment controls the balance of blue, yellow, ● The TINT adjustment controls the intensity of blue, yellow, and red. and red.
- Page 8 ● The FM MOD selection toggles the FM modulator on and off. ● The FM CHANNEL selects FM frequency that your source will broadcasted on, Press < or > to change broadcast channel. ● The FM PRESETS toggles between 6 preset FM frequencies ●...
- Page 9 FM PRESET INSTRUCTIONS 1. Press the "MENU" button on the monitor or the "PIC MENU" 2. Press the "MENU" or "PIC MENU" button until "FM CHANNEL" is button on the remote control. Continue pressing the button and displayed. Select the channel you would like to use in the OSD menu. scroll until "FM MOD"...
- Page 10 3. Press the "MENU" or "PIC MENU" button until "FM PRE- 4. To save the preset, press and hold the < button on your remote con- SETS" is displayed. Select the preset location you would like to trol or the "DOWN" button on the monitor for 3 seconds. The displayed save the desired channel at.
-
Page 11: Regional Coding
DVD OPERATING The DVD player has the ability to play DVD, VCD, Audio CD, and MP3 audio. Make sure you read this section completely before using the DVD section. REGIONAL CODING Both the DVD player and DVD disc are coded by region. These regional codes must match in order for the disc to play. If the codes do not match, the disc will not play. -
Page 12: General Setting
General setting Press [SETUP]. The screen will display the system setting menu. To navigate the menu, use [ ] the buttons. To confirm your selection, press [ENTER]. In the sub-menus, use the [ buttons to make your selection, press [ENTER] to enter the item to be changed. - Page 13 Press [SETUP] to exit system setting. Note:three screen ratio modes are available (16:9 WIDE, 4:3PS, 4:3L) It enables user to select the disc to match your screen. Below is chart showing the various formats. The recommended setting is wide. Last Memory Function The DVD player can identify the last format of the disc being used to store the last frame shown in its memory prior to unit being pow- ered off.
- Page 14 Setup Brightness and Contrast Press [SETUP] to access the menu. The screen will display the system setting menu. Navigate to the video setup page and press [ENTER]. Use the [ ] button to move the yellow band to "Quality" item. Press [ENTER] to confirm the screen will display as below: Navigate the yellow band to the item you want to change.
- Page 15 How to handle discs How to hold disc Do not touch the face containing information. When there are stains on face of disc Wipe gently with a wet cloth and then with dry one. When a disc is brought in from a cold environment to hot, condensation may form on the face of the disc.
-
Page 16: Troubleshooting
LIMITED ONE-YEAR WARRANTY (NON-TRANSFERABLE) Myron & Davis warrants to the original purchaser a non-transferable warranty to repair or replace, free of charge, the video product(s) in materials and workmanship under normal use and conditions for a period of one (1) year from date of purchase. Limited warranty excludes: Labor cost for removal, reinstallation, and trouble shooting of the video product(s).
