- Page 1 Reference Manual DOC. REV. 4/9/2013 VL-EPMs-U1 SUMIT-ISM™ Serial Communications + GPS Module...
- Page 2 Copyright © 2013 VersaLogic Corp. All rights reserved. Notice: Although every effort has been made to ensure this document is error-free, VersaLogic makes no representations or warranties with respect to this product and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose.
- Page 3 Utility routines and benchmark software This is a private page for VL-EPMs-U1 users that can be accessed only by entering this URL address directly. It cannot be reached from the VersaLogic public website. The VersaTech KnowledgeBase is an invaluable resource for resolving technical issues with your VersaLogic product.
-
Page 4: Table Of Contents
Dimensions and Mounting ....................6 Hardware Assembly ....................8 Stacking Restrictions ..................... 9 External Connectors ......................10 VL-EPMs-U1 Connectors..................10 VL-EPMs-U1 Connector Functions and Interface Cables ........11 Jumper Blocks ........................12 Jumpers As-shipped Configuration ..............12 Jumper Summary ....................13 Operation ........................14 Serial Ports ........................ -
Page 5: Introduction
The VL-EPMs-U1 is an embedded serial communications module with global positioning system (GPS) capability. Based on the SUMIT-ISM form factor, the VL-EPMs-U1 supports SUMIT and PC/104 stackable expansion buses on a 95 mm x 96 mm (3.76” x 3.78”) footprint. -
Page 6: Technical Specifications
VL-EPMs-U1B – 0.043 kg (0.096 lb) VL-EPMs-U1C – 0.066 kg (0.146 lb) VL-EPMs-U1E – 0.054 kg (0.120 lb) * Optional Data represents standard operation at +25°C with +5V supply unless otherwise noted. Specifications are subject to change without notification. VL-EPMs-U1 Reference Manual... -
Page 7: Block Diagram
Introduction Block Diagram COM1 RS-232 COM2 RS-232 SCH3114 SUMIT Connectors SCH3116 COM3 Super I/O RS-232/422/485 GPS Module Header COM4 RS-232/422/485 COM5 RS-232/422/485 COM6 RS-232/422/485 Figure 1. VL-EPMs-U1 Block Diagram VL-EPMs-U1 Reference Manual... -
Page 8: Rohs-Compliance
(PBDE) flame retardants, in certain electrical and electronic products sold in the European Union (EU) beginning July 1, 2006. VersaLogic Corp. is committed to supporting customers with high-quality products and services meeting the European Union’s RoHS directive. -
Page 9: Technical Support
Introduction Technical Support If you are unable to solve a problem after reading this manual, please visit the VL-EPMs-U1 product support web page (see below). The support page provides links to component datasheets and device drivers. VL-EPMs-U1 Support Page http://www.versalogic.com/private/epmsu1support.asp The VersaTech KnowledgeBase contains a wealth of technical information about VersaLogic products, along with product advisories. -
Page 10: Physical Description
Physical Description Dimensions and Mounting The VL-EPMs-U1 complies with SUMIT-ISM (Legacy Type 1) form factor, which provides for specific mounting hole and stackable bus locations as shown in the diagram below. 3.575 3.375 0.125 DIA x4 Use 3mm or #4 standoffs 0.000... - Page 11 GPS Antenna Connector 0.44 0.39 0.36 0.06 0.43 Serial Port 0.38 Connectors PC/104 (ISA) SUMIT Connector Connectors Figure 3. VL-EPMs-U1x Height Dimensions (Not to scale. All dimensions in inches.) Note Not all connectors are present on all models. VL-EPMs-U1 Reference Manual...
-
Page 12: Hardware Assembly
ARDWARE SSEMBLY The VL-EPMs-U1 comes in a variety of configurations that use SUMIT-A only, SUMIT-A and SUMIT-B, and PC/104 (ISA) connectors. The module can be added to the middle or top of the stack, above any SUMIT boards and below any PC/104 boards. -
Page 13: Stacking Restrictions
A maximum of two VL-EPMs-U1 boards are supported in the stack. When two VL-EPMs-U1 boards are in the stack, one must be configured with a base address of 0x4E. The other board must be configured to 0x162E or 0x164E. Address 0x2E is reserved for the CPU board's Super I/O. -
Page 14: External Connectors
J4 – COM1-2 J8 – GPS All Models J5 – Antenna GPS Models GPS Models J9 – GPS to Antenna GPS Models J10 – PC/104 (ISA) Models C, D, G, H Figure 5. VL-EPMs-U1 Connectors – Top Side VL-EPMs-U1 Reference Manual... -
Page 15: Vl-Epms-U1 Connector Functions And Interface Cables
— — SUMIT-B (Bottom) Samtec ASP-129637-01 1.669 3.317 — — SUMIT-A (Bottom) Samtec ASP-129637-01 2.712 3.317 1. The PCB origin is the center of the mounting hole located in the lower left, as oriented in Figure 5. VL-EPMs-U1 Reference Manual... -
Page 16: Jumper Blocks
Physical Description Jumper Blocks UMPERS SHIPPED ONFIGURATION (Model E) (Models A, B, C) (Model B) Jumper headers are present only on the standard VL-EPMs-U1 models indicated here. (All models) (All models) Figure 6. As-shipped Jumper Configuration VL-EPMs-U1 Reference Manual... -
Page 17: Jumper Summary
Physical Description UMPER UMMARY Not all jumper headers are present on all standard VL-EPMs-U1 models (A, B, C, and E), as indicated in the Jumper Summary table. Table 2: Jumper Summary Jumper Block Description Shipped Page — V1[1-2] GPS Backup power. This jumper header is installed on the VL- EPMs-U1B and E only. -
Page 18: Operation
Operation Serial Ports The VL-EPMs-U1 can be configured with up to six serial ports, COM1-6, depending on the model. The table below describes serial port configurations. Table 3: Serial Port Configurations Port Type Connector Models COM1/2 RS-232,16C550A compatible, 115 Kbps,... -
Page 19: Serial Port Connectors
DB-9M connectors. The pinouts for these connectors are shown below. Table 4: COM1 and COM2 Pinouts VL-CBR-2001 J4 Pin RS-232 DB-9 COM1 Pin RXD# TXD# Ground — VL-CBR-2001 J4 Pin RS-232 DB-9 COM2 Pin RXD# TXD# Ground — VL-EPMs-U1 Reference Manual... - Page 20 +5V pull-up +5V pull-up +5V pull-up Ground Ground Ground — Note: In full-duplex RS-485 operation the four signals [TxD+/TxD–] and [RxD+/RxD–] must be externally connected together by the user to form a single differential pair consisting of [TxD/RxD+] and [TxD/RxD–]. VL-EPMs-U1 Reference Manual...
- Page 21 +5V pull-up +5V pull-up +5V pull-up Ground Ground Ground — Note: In full-duplex RS-485 operation the four signals [TxD+/TxD–] and [RxD+/RxD–] must be externally connected together by the user to form a single differential pair consisting of [TxD/RxD+] and [TxD/RxD–]. VL-EPMs-U1 Reference Manual...
-
Page 22: Gps And Antenna
ONNECTOR A Trimble GPS antenna, VersaLogic part number VL-CBR-ANT02, is available for GPS- enabled models of the VL-EPMs-U1. The antenna has a 5-meter cable and male SMA connector. ATTERY The GPS receiver option provides a battery for back-up (BBU) power to keep the module's RAM memory alive and to power the real-time clock when the receiver's prime power is turned off. - Page 23 When using the TSIP protocol to change port assignments or settings, confirm that your changes do not affect the ability to communicate with the receiver (e.g., selecting the PC COM port settings that do not match the receiver’s, or changing the output protocol to TSIP while not using iQ_CHAT). VL-EPMs-U1 Reference Manual...
-
Page 24: Coordinate Systems
GPS time is currently 13 seconds ahead of UTC time. Time tags for most output messages can be in either UTC time or GPS time, as chosen by TSIP command 0x35. VL-EPMs-U1 Reference Manual... -
Page 25: Performance Characteristics
15 seconds, the receiver will normally re-establish track within two seconds. If the lost signal is not re-acquired within 15 seconds, the receiver initiates a broader frequency search. The receiver will continue to search for the satellite until it falls below the elevation mask. VL-EPMs-U1 Reference Manual... -
Page 26: Start-Up
This initialization process should not be interrupted. With a complete almanac and back-up power, the time to first fix can typically be shortened to less than 42 seconds. The receiver will respond to commands almost immediately after power-up. VL-EPMs-U1 Reference Manual... -
Page 27: Sumit-A Top Connector (J6)
Operation SUMIT-A Top Connector (J6) The table below shows the SUMIT-A Top connections to the VL-EPMs-U1. Signals that are not connected are pass-through only. The +5V signals on this connector are available to power the VL-EPMs-U1. This connector is present on all models. -
Page 28: Sumit-B Top Connector (J7)
The table below shows the SUMIT-B Top connections to the VL-EPMs-U1. Signals that are not connected are pass-through only. The +5V signals on this connector are available to power the VL-EPMs-U1. This connector is present on the C, D, G, and H models only. (See the SUMIT "lane shifting" note on page 23.) -
Page 29: Pc/104 (Isa) Connector (J10)
The +5V and ground signals on this connector are available to power the VL-EPMs-U1. This connector is present on the C, D, G, and H models only. (See the SUMIT "lane shifting" note on page 23.) -
Page 30: Sumit-A Bottom Connector (J12)
The table below shows the SUMIT-A Bottom connections to the VL-EPMs-U1. Signals that are not connected are pass-through only. The +5V and ground signals on this connector are available to power the VL-EPMs-U1. This connector is present on all models. (See the SUMIT "lane shifting" note on page 23.) -
Page 31: Appendix A - References
Appendix A – References SUMIT Interface SUMIT Specification PC/104 Interface PC/104 Specification Lassen iQ GPS Receiver Lassen iQ GPS Receiver System Designer Reference Manual General PC Documentation Amazon.com The Programmer’s PC Sourcebook General PC Documentation Amazon.com The Undocumented PC VL-EPMs-U1 Reference Manual...
