- Page 1 Chroma-Q™ Magic Box™ EtherSwitch 7F™ User Manual Version 1.1 September 2012 PN: 156-0501...
-
Page 2: Warranty Statement
(c) by operation outside the specifications contained in the user documentation; (d) by the use of spare parts not manufactured or sold by Chroma-Q or by the connection or integration of other equipment or software not approved by Chroma-Q unless the Customer provides acceptable proof to Chroma-Q that the defect or damage was not caused by the above;... - Page 3 Chroma-Q products are safe, effective, and fully satisfactory for the intended end use. Suggestions of use shall not be taken as inducements to infringe any patent. Chroma-Q sole warranty is that the product will meet the sales specifications in effect at the time of shipment.
-
Page 4: Table Of Contents
OpticalCon Fibre Optic and RJ45 Ethercon Ports …………………………………….……. 4 LED Indicators …………………………………………………….……. 5 Installation …………………………………………………….……. 5 Troubleshooting ………...……………………………………….………... 5 Specification ………...……………………………………….………... 6 Technical specification ...………..….……………………………………………. 6 Drawings ...………..….……………………………………………. 7 Maintenance ………...……………………………………….………... 7 www.chroma-q.com Magic Box EtherSwitch 7 User Manual V1.1 September 2012... -
Page 5: Product Overview
The unique Magic Box interlocking enclosure facilitates easy rack mounting when used in single units or pairs, and easy truss mounting via captive nut insert. Rack mounting brackets are available in single unit and dual unit versions, enabling you to customize your equipment rack or your installation by mixing and matching different Magic Box interface. -
Page 6: Led Indicators
The Speed LED indicator will light up green when the port is connected to a 1000Mbps Ethernet station, and amber when connected to a 100Mbps Ethernet device. The indicator will remain off when the port is connected to a 10Mbps Ethernet device. www.chroma-q.com Magic Box EtherSwitch 7 User Manual V1.1 September 2012... -
Page 7: Installation
2.5 Installation Unique Magic Box interlocking enclosure facilitates easy rack mounting when used in pairs and easy truss mounting via captive nut insert. Rack mounting brackets are available in single unit and dual unit versions. Note: for truss mounting, we recommend the use of a ½"-13UNC x ¾" long bolt to avoid damage. - Page 8 100 Mbps : 148,81pps 1000 Mbps : 1488,1pps Port Connection: Link and Activity LED indicators Power: Power LED Max Fiber Optic cable run: 550m / 1800ft Colour: Black Approvals : Pending www.chroma-q.com Magic Box EtherSwitch 7 User Manual V1.1 September 2012...
-
Page 9: Drawings
Maintenance With care, the Chroma-Q Magic Box EtherSwitch 7F will require little maintenance. However, as the unit is likely to be used in a stage environment we recommend periodical internal inspection and cleaning of any resulting dust and cracked oil residue.
