- Page 1 Pulse watch with integrated calorie counter User Manual Please read this manual thoroughly before first using this device HMM Diagnostics GmbH D-69221 Dossenheim, Germany www.hmm.info...
-
Page 3: Table Of Contents
Display & functions Product description Specifications III. Setup & functions Quick start: Heart rate monitoring runner Setting up your smartLAB ® Entering the setting loop Setting time and the calendar Setting daily alarm Setting the heart rate zone Setting the count down timer... - Page 4 Using the stopwatch Using the countdown timer Using the SCAN function Using Time in Zone Using the calorie counter Quick set: Calorie counter / Ambient Heart Rate (AHR) runner pulse watch Training with your smartLAB ® IV. Miscellaneous Maintenance Troubleshooting...
-
Page 5: Introduction
Important notice • Before your smartLAB ® runner pulse watch is able to display your heart rate, you have to push the MODE-button in any main menu for a few sec- onds. • If you enter the setup menu accidentally, press MODE to get back to the main menu. -
Page 6: Putting On The Elastic Transmitter
Putting on the elastic transmitter Your smartLAB ® runner pulse watch has an elastic chest strap with inte- grated transmitter, that can easily be worn during your exercises. To apply the belt, carry out the following steps: • Attach one end of the adjustable elastic strap to the... - Page 7 • Position the transmitter on the chest, just below the breastbone with the smartLAB ® runner logo the right way up. • Press the elastic strap around your chest and attach it to the other end of the transmitter.
-
Page 8: Ii. Your Smartlab
II. Your smartLAB runner ® Display & functions SELECT ST./FWD - selecting menu items - increase unit SCAN/REV MODE - display Interlock Code - main menu selection - decrease unit - analysis functions... - Page 9 Set contents 1 smartLAB ® runner pulse watch 1 elastic fabric chest strap with transmitter 1 User manual 1 smartLAB plastic box ® 1 CR 2025 battery 1 CR 2025 + 1 CR 2032 battery...
-
Page 10: Product Description
Product description To deliver reliably coded heart rate information, your smartLAB ® runner pulse watch utilizes a safe 122 kHz low frequency. So, all you have to con- centrate on is getting the most from your exercise. Each time you put on your chest transmitter and then press the MODE key... -
Page 11: Specifications
Once the interlock is established, you can exercise in close proximity with other heart rate monitors, safe in the knowledge that your smartLAB ® runner pulse watch will display only your own heart rate, and not the heart rate of those around you. -
Page 12: Iii. Setup & Functions
Quick start: Heart rate monitoring Your smartLAB ® runner pulse watch has a variety of features. To set these up, you will need to read the instructions. However, if you just want to see how the heart rate feature works, follow these steps: •... -
Page 13: Setting Up Your Smartlab ® Runner
Your smartLAB ® runner has one setting loop, which is entered from the „Time of Day (ToD)“ screen. Once you enter this screen, press and release of SELECT takes you to the next setting in the loop and returns to the „Time of Day“... -
Page 14: Entering The Setting Loop
Entering the setting loop In the „Time of Day“ screen, press and hold SELECT until the seconds flash and the select icon “SET“ appears on the display. Note: Pressing the MODE button at any stage in the setting loop takes you back to the main screen for that setting. - Page 15 Press SELECT to move to minutes. Press ST./FWD to increase, SCAN to de- crease the minutes. Press SELECT to move to day of the week. Press ST./FWD to advance, SCAN to move back the day of the week. The day of the week is indicated by its character in the lower display section.
-
Page 16: Setting Daily Alarm
ST./FWD to increase, SCAN to decrease. Setting the heart rate zone Your smartLAB runner pulse watch has a programmable target zone, mak- ® ing it easier to control the intensity of your workout. Please refer to „Train- ing with your smartLAB ®... - Page 17 The default heart zone settings are not intended as suggested or recommended upper or lower zone values. These values should be carefully adjusted according to your personal fitness level. Press SELECT to move to the heart zone high setting. This is indicated by a heart symbol and the arrow up symbol.
-
Page 18: Setting The Count Down Timer
Setting the count down timer Press SELECT to move to the count down timer. The repeat icon (2 arrows as a circle) will be flashing around „TMR“. The countdown timer counts down from up to 10 hours. You can now set it, so that it automatically resets and continues counting down repeatedly, or times a single event. -
Page 19: Setting Heart Rate Recovery (Hrr)
Setting heart rate recovery (HRR) Note: Your smartLAB ® runner pulse watch automatically measures your heart-rate-recovery (HRR). HRR refers to the time it takes for your heart rate to drop from the preset high to the preset low recovery limit after you have finished your workout. - Page 20 Press SELECT to move to HRR high (displayed by „HRR“ and the heart with arrow up symbol). Press and release ST./FWD to increase or SCAN to de- crease the required value. Note: It is suggested that this be set 5 bpm below the heart zone high limit. Press SELECT to move to HRR low (displayed by „HRR“...
-
Page 21: Setting The Calorie Counter
Setting the calorie counter The calorie counter shows the number of calories burnt during exercise, using heart rate intensity. You need to enter • your Ambient Heart Rate (AHR) value - this is your typical heart rate at rest before starting exercise. •... - Page 22 Press ST./FWD to increase (120 bpm maximum) or SCAN to decrease the ambient heart rate (30 bpm minimum). Press SELECT to move to set weight. The kilogram value will be flashing. The weight range is from 20 - 150 kg (44 -330 lbs). Press and release SCAN/ FWD to increase or SCAN to decrease the weight.
-
Page 23: Setting Heart Rate
Setting heart rate Your smartLAB runner pulse watch has 5 main screens: ® 1. Time of Day 2. Stopwatch 3. Countdown Timer 4. Time in Zone 5. Calorie Counter By pressing and holding MODE in any main screen will turn on and display your heart rate. -
Page 24: Alarm Settings
2 minutes, it automatically powers off. Alarm settings Hourly alarm: Your smartLAB runner pulse watch will give 2 beeps on the ® hour. Daily alarm: Press MODE to move to the „Time of Day“ screen. To view the current alarm setting (displayed for 2 seconds) press and release ST./FWD. -
Page 25: Using The Stopwatch
Note: To view the heart rate recovery time, move to the „Time in zone“ main screen and press ST./FWD. Using the stopwatch The stopwatch of your smartLAB runner can be used with or without heart ® rate activated and is operated in the same way for either modus. -
Page 26: Using The Countdown Timer
Note: Maximum stopwatch time is 9 hours, 59 minutes, 59,9 seconds. Using the countdown timer The countdown timer of your smartLAB ® runner pulse watch can be used with or without heart rate activated. When the time has counted down to zero, an audible alarm sounds for 10 seconds. -
Page 27: Using The Scan Function
Using the SCAN function Your smartLAB ® runner pulse watch has a variety of different scan modi that help you analyzing the measured values. You can choose between the fol- lowing SCAN modi: Current session scan: When heart rate is on, press and release SCAN in any main screen. -
Page 28: Using Time In Zone
Using Time in Zone With the Time-in-Zone function you can control how long you were in the optimal heart rate range (see also the chapter “Setting heart range” in this manual). Typically, exercise programs comprise a warm-up, workout for a specified time (in a zone) and cool down. -
Page 29: Using The Calorie Counter
Quick set: Calorie counter / Ambient Heart Rate (AHR) Your smartLAB®runner pulse watch has a quick set feature, allowing you to set your AHR quickly just before you begin your workout. Calories will be counted from 5 bpm above this value. You need to be wearing the transmit- ter and monitor, and have heart rate switched on. -
Page 30: Training With Your Smartlab ® Runner Pulse Watch
Note: If your heart rate is above 120 bpm, your smartLAB®runner will de- fault to the setting already stored. Training with your smartLAB runner pulse watch ® Exercising at the right heart rate intensity, is key to meeting your fitness and performance goals. - Page 31 Intensity of exercise: If you are a beginner with the goal of improving over- all fitness, losing weight or reducing stress, exercise in the healthy zone, which is 50-59 percent of your maximum heart rate. If you already exercise regularly and are aiming to lose body fat, exercise in the fat burning zone, which is 60-69 percent of your maximum heart rate.
- Page 32 Example: Taking a 30 year old just starting on an exercise program with the aim of getting fitter would start exercising at a gentle intensity of 50-59% of maximum heart frequency (MHR): 50% of 190 = 95 bpm, 59% of 190 = 112 bpm.
- Page 33 The F.I.T.T. Method: (Frequency, Intensity, Time, Type of Exercise) - Frequency of exercise: Exercise in the zone that you have set at least 3-5 times per week, with no more than 48 hours between sessions. Even on „rest days“ gentle exercise such as leisurely walk can be beneficial. - Intensity of exercise: Select a zone that is both within your capability and in which you can achieve consistency.
-
Page 34: Miscellaneous Maintenance
IV. Miscellaneous Maintenance • Thoroughly wipe and dry your smartLAB®runner pulse watch and transmitter after use • Store in a cool and dry place. You can use the smartLAB plastic box, ® for example. • Do not expose to direct sunlight or temperatures above 122 degrees Fahrenheit (50°C) or below 14 degrees Fahrenheit (-10°C). -
Page 35: Troubleshooting
Troubleshooting • What if the heart rate reading is erratic or totally absent 1- Make sure that the chest transmitter is sufficiently tight. The transmitter should be positioned and the elastic strap tightened so that the electrodes are flat against your skin. Adjust the transmitter side to side or slightly up or down until it is positioned correctly, and the electrodes make good contact with your skin 2- Make sure the transmitter electrodes are sufficiently moist. - Page 36 • What if the heart rate reading becomes extremely high? Electromagnetic signals from outside sources may cause abnormally high heart rate readings. Common sources of electromagnetic signals are high voltage power lines, electric motors and mobile phones. Your heart rate should return to normal once you move away from the source.
-
Page 37: Warranty
Warranty HMM Diagnostics GmbH products need to fulfill high quality requirements. Because of this reason, HMM Diagnostics GmbH gives a 2-year warranty by purchasing this smartLAB product. You can even extend the warranty from ® 2 to 5 years without extra pay when you register your product. Please use the warranty card included in your product set. - Page 38 Manufacturer: HMM Diagnostics GmbH Friedrichstr. 89 D-69221 Dossenheim, Germany mail: info@hmm.info www.hmm.info Weitere Informationen zu den smartLAB Produkten / ® More information on our smartLAB products: ® www.smartlab.org...
