Tempest
What's in the box
BaseStation
TM-400 series Base
•
Power Cord
•
2dBi Omni-directional whip antenna (x2)
•
3.5mm to 3.5mm 3 conductor data pairing cable
•
- - - - - Used to pair a Base to the Belt(s)
USB A to B cable - - - - - Used to upgrade Base firmware
•
USB A to Mini B - - - - - Used to upgrade Belt firmware
•
Base-Sync cable
•
- - - - - Used if you have more than one Base
- - - - - Improves RF performance when using multiple systems
CD with manual, T-Desk software
•
BeltStation
TM-400 series Belt
•
Li-Poly rechargeable battery
•
5VDC wall charger with Mini USB connector
•
Remote Transceiver (optional)
Remote RF transceiver
•
RJ-45 to RJ-45 CAT-5 cable
•
2dBi Omni-directional whip antenna (x2)
•
Mounting Plate and screws
•
400 Quick Start Guide
®
Directional Antenna Kit (optional)
Directional antennas (x2)
•
Mounting brackets (x2)
•
Antenna Mounting Bar
•
"C" Clamp Mount
•
"RP-TNC" to "N" cables (x2)
•
5 Bay Battery Charger (optional)
Battery Charger
•
AC Cable
•
Note: Charge ALL BeltStation batteries prior to set-up
What else you may need
Headset, one for each user
•
- - - - - May be dynamic or electret microphone, with a
4-PIN XLR female connector
3-PIN XLR cables to connect to external 2-Wire
•
Intercom system
RJ-45 cables to connect to external 4-Wire Intercom system
•
RJ-45 cable to connect to PC for T-Desk LAN control
•
Advertisement
Summary of Contents for Tempest 400
- Page 1 Tempest 400 Quick Start Guide ® What’s in the box BaseStation Directional Antenna Kit (optional) TM-400 series Base Directional antennas (x2) • • Power Cord Mounting brackets (x2) • • 2dBi Omni-directional whip antenna (x2) Antenna Mounting Bar • •...
- Page 2 RF perfor- Charge the BeltStation batteries prior to starting set-up. mance especially in the presence of other Tempest systems. A BeltStation must be paired with a BaseStation for any com- munication to take place. Pairing should be done AFTER the default RF configuration is changed on the BaseStation.
-
Page 3: Quick Start Guide
The belt will appear in the first available slot on the Base LCD screen • and out (from Base to 4-Wire) levels. Repeat for each Belt • *Refer to the Tempest Owner’s Manual for detailed system information. Note: BeltStations are named to their default setting name. They may be renamed. - Page 4 334.821.6861 Auburn, Alabama 36830 www.tempestwireless.com Tempest is manufactured by CoachComm, LLC and is distributed by Clear-Com Communication Systems. ®Clear-Com and the Clear-Com Communication Systems logo are registered trademarks of The Vitec Group plc © 2009 CoachComm LLC. All rights reserved.
