Rolsen RDV-4002/RDV-4003 DVD Service Manual
Service Manual
SAFTY PRECAUTIONS
GENERALS GUIDELINES
1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the
short circuit.
2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers are property installed.。
3. After servicing, make the following leakage current checks to prevent the customer from being exposed to shock hazards.
LEAKAGE CURRENT COLD CHECK
1. Unplug the AC cord and connect a jumper between the two prongs on the plug.
2. Measure the resistance value, with an ohmmeter, between the jumped AC plug and each exposed metallic cabinet part on the equipment
such as screw-heads, connectors, control shafts, etc. When the exposed metallic part has a return path to the chassis, the reading should be
between 1MΩ and 5.2MΩ. When the exposed metal does not have return path to chassis, the reading must be ∞.
Advertisement
Table of Contents
Related Manuals for Rolsen RDV-4002
Summary of Contents for Rolsen RDV-4002
- Page 1 Rolsen RDV-4002/RDV-4003 DVD Service Manual Service Manual SAFTY PRECAUTIONS GENERALS GUIDELINES 1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. 2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers are property installed.。...
-
Page 2: Leakage Current Hot Check (See Figure 1.)
Rolsen RDV-4002/RDV-4003 DVD Service Manual LEAKAGE CURRENT HOT CHECK ( See Figure 1.) 1. Plug the AC cord directly into the AC outlet. Do not use an isolation transformer for this check. 2. Connect a 1.5KΩ, 10 Watts resistor, in parallel with a 0.15uF capacitors, between each exposed metallic part on the set and a good earth ground such as a water pipe, as shown in Figure 1. - Page 3 Rolsen RDV-4002/RDV-4003 DVD Service Manual electro static discharge (ESD). 1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on your body by touching a known earth ground. Alternatively, obtain and ware a commercially available discharge ESD wrist strap, which should removed for optional shock reasons prior to applying to the unit under test.
-
Page 4: Important Safety Notice
Rolsen RDV-4002/RDV-4003 DVD Service Manual IMPORTANT SAFETY NOTICE There are special components used in the schematic diagram, Exploded Views and replacement part list. It is essential that these critical parts should be replaced with manufacture’s special parts to prevent shock, fire, or other hazard. - Page 5 Rolsen RDV-4002/RDV-4003 DVD Service Manual Handling of optical pickup Do not subject the optical pickup to static electricity as it is extremely sensitive to electrical shock. To prevent the breakdown of the laser diode, an antistatic shorting pin is inserted into the flexible board (FPC Board).
- Page 6 Rolsen RDV-4002/RDV-4003 DVD Service Manual Grounding for electrostatic breakdown prevention 1、Human body grounding Use the antistatic wrist strap to discharge the static electricity from your body. 2、Work table grounding 3、Put a conductive material (sheet) or steel sheet on the area where the optical pickup is placed and ground the sheet.
-
Page 7: Front View
Rolsen RDV-4002/RDV-4003 DVD Service Manual DIAGRAM FRONT VIEW RDV-4003 RDV-4002... -
Page 8: Rear View
Rolsen RDV-4002/RDV-4003 DVD Service Manual REAR VIEW RDV-4003 RDV-4002... -
Page 9: Remote Control Unit
Rolsen RDV-4002/RDV-4003 DVD Service Manual REMOTE CONTROL UNIT... - Page 10 Rolsen RDV-4002/RDV-4003 DVD Service Manual EXPLODED VIEW RDV-4003...
- Page 11 Rolsen RDV-4002/RDV-4003 DVD Service Manual RDV-4002...
- Page 12 Rolsen RDV-4002/RDV-4003 DVD Service Manual SCHEMATIC DIAGRAM OF FRONT PANEL...
- Page 13 COMMON1389HD_HDMI_HD60_V4 History Date MT1389HD(LQFP256) DVD MP Board for SANYO HD60 PUH (Small Size) The original released. 2005/03/07 Supports 1389HD & Memory Card Interface MDxxx add protection circuit for OPU 2005/05/30 delete U20 and U21 2005/07/28 INDEX & POWER, RESET add R177 and R178 for HDMI I2C 2005/10/27 MT1389HD SDRAM &...
- Page 14 JITFO 390pF JITFN V1P4 DV33 V2P8 750k CB17 2200pF CB19 + CE12 + CE10 CB18 0.1uF/NC + CE11 104F 47uF/16v 104pF 47uF/16v 104pF 680k ADIN 47uF/16v APLLVDD3 1uF/10v CE21 CB38 CE20 104pF 10uF/50v 100uF/16v 150k DACVDD3 150k 680k 2200pF CB11 V1P4 0.1uF 1uF/10v...
- Page 15 MA[0..11] MA[0..11] BA[0..1] BA[0..1] DQ[0..15] DQ[0..15] DQM[0..1] DQM[0..1] DCLK DCLK DRAM DCKE DCKE CAS# CAS# RAS# RAS# AD[0..7] AD[0..7] FLASH DRAM [2,6] [2,6] PCE# PCE# MA10 DQ10 PRD# PRD# A10/AP DQ10 MA11 DQ11 DQ11 PWR# PWR# DBA0 DQ12 BA0/A13 DQ12 A[0..20] A[0..20] DBA1...
- Page 16 H601# [2,6] H601# [2,6] V601# V601# +5VV +5VV [2,6] YUV[1..6] YUV[1..6] [2,6] ASPDIF ASPDIF LSCH LSCH RSCH RSCH CENT CENT 1.8uH 9015C 9015C 1.8uH USBM USBM 330pF 270pF 330pF 270pF USBP USBP [1,2,6] URST# URST# USBVDD USBVDD +5VV +5VV 9015C CVBS 9015C 1.8uH...
- Page 17 ACLK [2,6] ACLK ABCK [2,6] ABCK ALRCK LSCH [2,6] ALRCK LSCH 89_AL RSCH RSCH 89_AL 89_AR CENT CENT 89_AR 89_ALS 89_ALS 89_ARS 89_ARS 89_CTR 89_CTR 89_SW 89_SW [ 4 ] MUTE_DAC MUTE_DAC [ 4 ] [ 4 ] R112 ABCK SBCLK1 120pF -12V...
- Page 18 1392DAC_AVDD3 CB71 CB72 CB73 [2,5] ALRCK ALRCK 104pF 104pF 104pF [2,5] ACLK ACLK [2,5] ABCK ABCK [2,4] ASPDIF ASPDIF CENY [2,4] YUV4 YUV4 DV33 92_DV33 [2,4] YUV5 YUV5 1392_AVDD3 CVBS 5 5 5 [2,4] YUV6 YUV6 ASPECT [2,4] H601# H601# [2,4] V601# V601#...
- Page 19 Rolsen RDV-4002/RDV-4003 DVD Service Manual...
