Summary of Contents for Mobilife MPP101
- Page 2 ISCLAIMER While every effort has been made to ensure that the information in this manual is accurate and complete, no liability can be accepted for any errors or omissions ELTRADE reserves the right to change the specifications of the hardware and the software described in this manual without notice This document contains information proprietary to ELTRADE Ltd.
-
Page 3: Table Of Contents
ONTENTS IRST AINTENANCE Safety Precautions ........... 4 Changing the Paper Roll........ 13 Warnings ............4 Cleaning the Print Head......... 14 Cautions ............6 Changing the Batteries ........15 Preventing Malfunctioning ......7 ROUBLESHOOTING Installation Instructions......... 18 NTRODUCTION Windows 2000/XP Operating System Unpacking the printer ........ -
Page 4: Read This First
Internal inspections, or other liquids. Do not allow liquids to enter alterations and repairs should be conducted the interior. The printer has not been waterproofed. If the exterior comes into MPP101 User Manual... - Page 5 Do not immerse humidity and short-circuit leading to fire. the batteries in water. MPP101 User Manual...
-
Page 6: Cautions
(boot) of a car. Contact with the metallic components of MPP101 User Manual... -
Page 7: Preventing Malfunctioning
Stop using the printer immediately if you detect condensation. Continued use may damage the equipment. Remove the battery or disconnect the power adapter (if connected) from the printer and wait until the moisture evaporates completely before resuming use. MPP101 User Manual... -
Page 8: Introduction
If any, contact Customer Service. Printer Modules The MPP101 Printer main modules are: (See Figure 1 and Figure 2) 1. Base 2. Cover Figure 1. Top View 3. - Page 9 NTRODUCTION Figure 2. Bottom View 7. Battery Compartment 8. Belt Clip 9. Battery Fresh Seal MPP101 User Manual...
-
Page 10: Installation And Operation
Setting Up Removing the Battery Fresh Seal To start operating the printer, pull out the battery fresh seal as shown on Figure 3. Figure 3. Removing the Battery Fresh Seal Figure 4. Connect the Power Supply Adapter MPP101 User Manual... -
Page 11: Turning The Printer On And Off
NSTALLATION AND PERATION Plug the Power Supply Adapter into the mains LED Indication outlet and connect it to the MPP101 printer as LED status Description shown on Figure 4. Printer Off Make sure the temperature is within the 0 - 40°C range! -
Page 12: Bluetooth Connection Range
Bluetooth Connection Range To establish a proper communication with the printer, it should be placed not far than 10 m from the Bluetooth antenna of the device as shown on Figure 5. ≤10 m Figure 5. Bluetooth Connection Range MPP101 User Manual... -
Page 13: Maintenance
Remove the remaining of the used paper and insert a new paper roll into the bin as indicated Close the cover and pull out a little of the paper on Figure 7. as displayed on Figure 8. MPP101 User Manual... -
Page 14: Cleaning The Print Head
Open the paper bin cover. If a paper roll is Never touch the head; oils on your loaded, remove it. skin can damage the head. Do not clean the head immediately Reload paper roll and close the printer cover. after printing; the head may be hot. MPP101 User Manual... -
Page 15: Changing The Batteries
Remove the belt clip as shown on Figure 10. Figure 10. Removing the Belt Clip Open the battery compartment as shown on Figure 11. Opening the Battery Compartment Figure 11. Insert the batteries as displayed on Figure 12. MPP101 User Manual... - Page 16 Figure 12. Placing the Batteries Close the battery compartment and attach the Figure 13. Attaching the Belt Clip belt clip pushing it to the printer base and sliding it till a click is heard (See Figure 13). MPP101 User Manual...
-
Page 17: Troubleshooting
Turned off Turn it on! Connection cannot be Distance to the printer? Higher than 10 m Take the printer closer! established Software Settings? Not correct Correct the settings! Data prints incorrectly Software settings? Not correct Correct the settings! MPP101 User Manual... -
Page 18: Installation Instructions
Next button. Refer to your Bluetooth manager to The next dialog box (see Figure 16) will determine, which COM port is assigned ask you to select a printer driver. for a printer port. MPP101 User Manual... - Page 19 (See Step 1.), select the If you are using Windows XP, you will be mpp100.inf file and press the OK warned that the driver is not signed and button. will be asked to confirm the installation. MPP101 User Manual...
-
Page 20: Operating Instructions
OFTWARE Operating Instructions Windows 2000/XP Operating System Before start printing with MPP101 you need to change the port settings in the printer driver properties: Step 1. Go to the Printers and Faxes folder (Start » Settings » Printers and Faxes) right-click on the MPP100 printer and select Properties. - Page 21 OFTWARE Step 3. Disable the bidirectional support (Enable bidirectional support should not be checked). The rest of the MPP100 properties can be set as of the other Windows printer drivers. Figure 18. Ports Properties MPP101 User Manual...
-
Page 22: Technical Specifications
Normal, Double Height, Double Width Number of characters/line 16, 24, 32, 48 Graphics resolution (dpi) Paper end detection Photo-interrupter Communication Interface Bluetooth Bluetooth Profile supported Drivers available Windows 2000/XP Baud Rates (bits/s) 115200 Print Buffer (KBytes) Flash Memory (KBytes) MPP101 User Manual... - Page 23 10 – 90 (no condensation) Paper cover opening angle (°) Dimensions (mm) 115 mm x 74 mm x 40 mm Weight (without the paper roll) (gr) It depends on the communication speed, the printing typology, the battery condition and the temperature. MPP101 User Manual...
