Doran 360RV User Manual

Wireless electronic tire pressure monitoring system (tpms)
Hide thumbs
Table of Contents

Advertisement

Quick Links

PLEASE READ THIS MANUAL CAREFULLY BEFORE
The DORAN 360RV is designed solely to monitor tire pressure. It is not
designed to provide warning of a potential or actual tire blowout.
The National Highway and Traffic Safety Administration considers a
tire flat when the pressure is 25% below the tire manufacturers'
recommended operating pressure.
Manufacturing LLC
360RV
USER MANUAL
USING THIS PRODUCT.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 360RV and is the answer not in the manual?

Questions and answers

Summary of Contents for Doran 360RV

  • Page 1 PLEASE READ THIS MANUAL CAREFULLY BEFORE USING THIS PRODUCT. The DORAN 360RV is designed solely to monitor tire pressure. It is not designed to provide warning of a potential or actual tire blowout. The National Highway and Traffic Safety Administration considers a tire flat when the pressure is 25% below the tire manufacturers' recommended operating pressure.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS I. Introduction to the Doran 360RV------------------------------------------------------------------------------------- Components------------------------------------------------------------------------------------------------------------- Glossary of Terms----------------------------------------------------------------------------------------------------- II. Setup and Installation 1. Monitor Installation------------------------------------------------------------------------------------------------- 2. Programming the System---------------------------------------------------------------------------------------- A. Programming the Sensor Location-------------------------------------------------------------------- B. Baseline Pressure Programming---------------------------------------------------------------------- C. Programming the Date & Time for Stored Alarm History--------------------------------------- D.

  • Page 3: Introduction To The Doran 360Rv

    However, low pressure is the leading cause of premature tire failure and the 360RV can provide early notice of potential problems and assist in maintaining proper pressurization in vehicle tires. The 360RV can be used on all pneumatic tires.

  • Page 4: Components

    I. INTRODUCTION Tires can fail for other reasons besides low pressure or overloading. Always be on the alert for any other tire problems as indicated by unusual noises, vibrations, uneven tread wear, or bulges on the tire! If any of these symptoms occur, have the tires checked immediately by a professional! SYSTEM COMPONENTS: (1) Display Monitor w/ fused 12-volt power...

  • Page 5: Setup And Installation

    12-volt power receptacle. This method is the quickest, however it does not allow you to receive the full benefits of the Doran 360RV. Using the accessory cigarette lighter adapter plug for your power source will delay information to the monitor if the power is removed when the vehicle is turned off and the power is removed from the receptacle.

  • Page 6: Programming The System

    II. SETUP AND INSTALLATION The monitor is fused internally, however some installers would still prefer to install an inline fuse for precautions. We suggest an optional 2-amp fast blow fuse be used for this purpose. The first time the monitor is powered up the display will show NSP .

  • Page 7: Programming The Sensor Location

    II. SETUP AND INSTALLATION A. Programming the Sensor Location 1. Be sure that the power is on. The first time the monitor is switched on; the display should show NSP .This will signify that no sensor is programmed, or the monitor has not received a new sensor signal yet.
  • Page 8 II. SETUP AND INSTALLATION 4. Using the arrow keys select the first tire position that you want to program. The selected wheel location will be solid. The other wheel positions will only be an outline. If sensors have already been programmed to the monitor, the only sensor locations that will be displayed will be the ones that do not have a sensor already programmed to it.

  • Page 9: Baseline Pressure Programming

    II. SETUP AND INSTALLATION 10. Once you have completed the sensor programming sequence for all tires, press the PROG button momentarily to move to the next step, this will be the Base Line Pressure Programming. The monitor will display as shown in Figure 2-7. If you are completely done with all of the programming operations you can press the PROG button for 5 seconds and the monitor will return to the normal mode of operation.

  • Page 10: Programming The Date & Time For Stored Alarm History

    II. SETUP AND INSTALLATION 188 PSI,depending on your needs. Each wheel position can be set with a different baseline air pressure if this is what is needed. The monitor has been pre-programmed for 100 PSI at each wheel position. If this is the baseline air pressure that you need then you will not have to do anything in this mode and can press the PROG button and go to the next step.
  • Page 11 II. SETUP AND INSTALLATION NOTE: To skip this section and go directly to Programming the Unit of Measure section, just press the PROG button briefly 1 time. The display should look like Figure 2-17. Anytime during this mode you can escape out to the next program mode by pressing the PROG momentarily. 1.
  • Page 12 II. SETUP AND INSTALLATION SET button for 3 seconds until the monitor beeps twice and the display flashes twice. The display is shown like Figure 2-14. 4. To adjust the hour (h) you will need to press and hold the SET button until the center digit flashes. Figure 2-14 Keep in mind that the hour will be displayed as a 24- hour clock.

  • Page 13: Programming The Unit Of Measure

    II. SETUP AND INSTALLATION D. Programming the Unit of Measure NOTE: To enter directly into this program mode you will need to press the PROG button for 5 seconds until the PROGRAM is displayed. Then press the PROG button again briefly 3 times to enter this mode (see Figure 2-17 for screen display).

  • Page 14: Delete Sensor Location

    II. SETUP AND INSTALLATION E. Delete Sensor Location This step is only used when a sensor is to be removed from the memory of the monitor. This would be used to remove a sensor from one position and locate it to a different location, or to remove a sensor.

  • Page 15: High Pressure Alarm Programming

    II. SETUP AND INSTALLATION 3. If you have additional sensors that need to be deleted repeat the steps until all required sensors are deleted. If you need to program deleted sensors to a different location, or add new sensors to the monitor's memory simply press the PROG button twice to enter into the Programming Sensor Location mode (see page 7).

  • Page 16: Installing The Sensor On The Vehicle

    This should not be necessary with the Doran 360RV. The dill pin should not be extracted to the point that air is released all the time from the valve stem. This should be checked with a bit of soapy water if you do make an adjustment to the dill valve and after the sensors have been installed.
  • Page 17 Figure 3-4 and the green LED light will come on (see Figure 3- 4). You are now ready to enjoy the safety and comfort of your new Doran 360RV Tire Pressure Monitor System. 3. If any of the wheel positions are not within the baseline air pressures an alert will be...

  • Page 18: Alarm Modes

    NOTE: The DORAN 360RV will illuminate a flashing low tire pressure warning light and an audible alarm for three minutes when the inflation pressure in one or both tires is equal to or less than 12.5 % below the programmed baseline air pressure. The warning will continue to illuminate as long as the malfunction exists, whenever the monitor is switched on.

  • Page 19: First Stage Alarm For 12.5% Low

    IV. ALARM MODES FIRST STAGE ALARM FOR 12.5% LOW AIR PRESSURE: On a first level low pressure alarm the monitor will alarm at 12.5% below the programmed base line air pressure. When this happens the backlight on the monitor screen will light up. The green LED light will go out, the Red warning light will begin to flash and the audible beeper will cycle at 1 flash or beep per second, Figure 4-1...

  • Page 20: High Pressure Alarm

    High Pressure Alarm: The Doran 360RV monitor is capable of monitoring for a High Pressure Warning. This is a warning that is displayed when the baseline air pressure is exceeded by 25%. When this happens the Green light will go out. The audible beeper will beep once per second and HIGH PRESSURE will be displayed on the monitor screen.

  • Page 21: Normal Mode Accessory Functions

    V. NORMAL MODE ACCESSORY FUNCTIONS 1. Drop and Hook Feature This feature allows the operator of the vehicle to drop the monitoring of either the front or the rear vehicle allowing the monitor to only receive the RF signals from the vehicle that is in close proximity to the monitor.

  • Page 22: System Reset Function

    3. Stored Alarm Information The Doran 360RV has the ability to store the last 10 alarm faults that have occurred. They cannot be erased; they can only be replaced by newer, more recent alarms.

  • Page 23: Backlight For Night Operations

    V. NORMAL MODE ACCESSORY FUNCTIONS The display will show as follows: Figure 6-2 Actual pressure for the alarm Figure 6-3 d07 is for the 7th month or July. Figure 6-4 d04 is for the 4th day of the month Figure 6-5 Figure 6-5 d06 is for the year 2006 Figure 6-6 A02 stands for AM and 2:00 Figure 6-7 M33 Stands for 33 minutes...

  • Page 24: Faqs And Tips

    DOES THE MONITOR NEED TO BE POWERED BY A LIGHTER ACCESSORY? No. In fact you will loose some of the benefits of the 360RV if the monitor is wired in this method. If a hard wire option is utilized the end user then will benefit from the sleep mode option that the system incorporates.
  • Page 25 With the 360RV system you can air up a low tire with the tire being warm and replace the sensor without worrying about the sensor giving a false alarm, like some of the other...
  • Page 26 Smaller tires may require rebalancing. WHAT SHOULD I DO IF A SENSOR IS LOST OR DAMAGED? If a sensor is lost or damaged and needs replacing, call Doran Mfg. LLC toll free at 1-866-816- 7233 to order a new sensor.

  • Page 27: Tips

    It is possible, during an instantaneous blowout, to have the sensor blown off the tire before it has had a chance to send a signal to the monitor. The 360RV is not designed for this type of tire failure. Tire failure referred to as a blowout, is commonly due to low tire pressure resulting in an overheating of the tire sidewalls to the point of disintegration.

  • Page 28: Limited Warranty

    The exclusive remedy for any product determined by DORAN Mfg. LLC to be defective within such period shall, at the sole option of DORAN Mfg. LLC, be the repair or replacement of such defective product, or the refund of the purchase price therefore.
  • Page 29 VI. FAQS AND TIPS PROCEDURE: Products determined to be defective within the terms of this Limited Warranty should be returned to Doran Mfg. LLC, transportation prepaid. Call DORAN Mfg. LLC for return authorization. No unauthorized returns shall be accepted. Sender is responsible for all costs incurred in the removal or reinstallation and shipping of the returned product.

  • Page 30: Specifications

    (2)THIS DEVICE MUST ACCEPT ANY INTERFERENCE THATMAY CAUSE UNDESIRED OPERATION THE DORAN 360RV IS A DEVICE FOR DISPLAYING TIRE PRESSURES. AS WITH ALL DEVICES THAT USE RF SIGNALS, THE SIGNAL CAN BE INTERRUPTED. THE DORAN 360RV HAS BEEN DESIGNED TO WORK OPTIMALLY TO OVERCOME THE INTERFERENCE THAT CAN BLOCK RF SIGNALS.
