- Page 1 SECURITY ELECTRONICS PTE1000 Installation & User Manual PTE1000 Series Security Energisers Pakton Technologies Pty Ltd ABN 66 405 694 842 16 Ferrier Road, Narangba Qld 4504 PO Box 408 Narangba, QLD 4504 Tel: (07) 3888 3793 Fax: (07) 3888 4330 Email: sales@pakton.com.au...
-
Page 2: Table Of Contents
Table of Contents TABLE OF CONTENTS ....................2 INTRODUCTION ......................5 How it works......................... 5 FEATURES........................6 PTE1000 Features ........................ 6 Optional Features ........................ 6 SPECIFICATIONS......................7 DESCRIPTION ......................8 Parts of the PTE1000 ......................8 Status Lights ........................8 Status Lights ........................ - Page 3 Service Light ........................18 Keypad control In brief......................18 TECHNICAL INFORMATION (TECHNICIANS SECTION) ........19 Power Options........................21 LEDs ............................ 21 Jumpers ..........................22 10.0 INSTALLATION PROGRAMMING OPTIONS ............26 Programming mode ......................26 To exit programming mode ....................26 Change the installer PIN ....................
- Page 4 Operation of electric security fence ..................40 APPENDIX B: GROUP SIMULTANEOUS PULSE (SP) FEATURE ........41 Group linking via the Keypad “bus”................41 Group Installation notes ....................42 APPENDIX C: PTE0313 GROUP VOLTAGE DISPLAY ............43 Keypad Connections ...............Error! Bookmark not defined. LCD Contrast Control ..............Error! Bookmark not defined.
-
Page 5: Introduction
Installation and User Manual for PTE1000 V4 Introduction How it works Electric fences are an excellent perimeter security option. They operate on 3 levels: x They instil fear of electrocution in the minds of potential intruders x They can give a nasty shock to anyone who attempts to breach the fence x The fence can be monitored to give an alarm if it is cut or shorted. -
Page 6: Features
Installation and User Manual for PTE1000 V4 Features PTE1000 Features 1. LED and LCD display. 2. 3 joules stored energy. 3. Stylish wall mountable enclosure. 4. Operates from 16Vac via a plug pack. 5. Optional internal rechargeable back up battery. 6. -
Page 7: Specifications
Installation and User Manual for PTE1000 V4 Specifications PTE1000 PCB version 4.3 or higher. Software (firmware) version 5.0 or higher. Specification Name Specification Energiser output voltage – PTE102x 8.5kV peak no load, 0.9J at 500R per channel. Energiser output voltage – PTE101x +/-5kV peak no load. 2.0J at 500R Pulse rate Crystal locked at 0.8 Hz AC power input... -
Page 8: Description
Installation and User Manual for PTE1000 V4 Description Parts of the PTE1000 Voltage Status Display Lights Battery Access Cover Fence Terminals Output terminals Return (monitor) terminals 08/07/2006 10:11 PM Page 8 of 43... -
Page 9: Status Lights
Installation and User Manual for PTE1000 V4 Status Lights Power – On whenever the unit has power. OK (armed) – On when the unit is armed (pulsing), will flash when in low voltage mode. Fence – On when there is a fence alarm (either channel). Mimics the state of the Fence alarm output below. -
Page 10: Keypad (Optional)
Installation and User Manual for PTE1000 V4 Keypad (optional) Keypad Lights (LEDs) Power – On with AC power, flashes on low battery. Service – On with any Energiser fault (like low batter). Arm – On when the energiser is armed (pulsing), flashes when in low power mode. 1 –... -
Page 11: Internal Beeper / Keypad Beeper
For diagrams showing how to connect the PTE1000 to a fence see chapter 7. Synchronised Groups of PTE1000’s PTE1000 series energisers may be linked to form a “group” to power multiple sectors. Using Pakton’s Simultaneous Pulse technology. See appendix B. -
Page 12: Low Power Mode
Installation and User Manual for PTE1000 V4 Low Power mode PTE1000 series energisers are able to be switched into low power mode. Low Power mode may be used in situations where the fence is not required to be a deterrent but is still required to actively detect intrusion. -
Page 13: Installation
Installation and User Manual for PTE1000 V4 Installation Installation Steps. Read the entire manual first! Design and build the fence (beyond the scope of this manual), ask your distributor for help if required. Decide where the PTE1000 is to be mounted. It should be inside, under cover. If on an external wall it should be within a wiring box and definitely not in direct sunlight. -
Page 14: High Voltage Wiring
Installation and User Manual for PTE1000 V4 High Voltage Wiring Example Wiring Diagrams Energiser Earth ENERGISER EARTH PTE101x Single Channel Energiser Conventional Fence Fence Earth Reference Earth PTE101x Single Channel Energiser configured for conventional fence operation. Energiser Earth ENERGISER EARTH PTE101x Single Channel energiser Bi-polar Fence Reference Earth... - Page 15 Installation and User Manual for PTE1000 V4 Energiser Earth ENERGISER EARTH Fence Zone 1 PTE102x Dual Channel Energiser PTE102x Dual Channel Energiser Fence Zone 2 Reference Earth REFERENCE EARTH Fence Earth PTE102x Dual Channel Energiser showing two zones in operation. Below are two example “Energiser to Fence to Earth”...
- Page 16 Installation and User Manual for PTE1000 V4 Lightning Diverters Fence PTE102x Dual Channel Energiser Reference Earth Fence and Energiser Earth Lightning Earth Lightning Diverters fitted at the fence. 08/07/2006 10:11 PM Page 16 of 43...
-
Page 17: Users Guide
Installation and User Manual for PTE1000 V4 Users Guide ECHNICAL STUFF Your PTE1000 security energiser has been designed to be easy to control. In it’s simplest form it is operated by the on / off switches at the base of the unit. If the Keypad has been installed it can be remotely controlled from the keypad, the keypad also allows instant audiovisual indication of the state of the energiser and therefore the fence it is powering. -
Page 18: To Silence The Alarm
Installation and User Manual for PTE1000 V4 O SILENCE THE ALARM Enter your PIN and press . This will silence the alarm but not disarm the system, the armed light will still be on. The zone lights on the keypad will flash to show where the breach occurred. The siren and strobe are ready to respond again if needed. -
Page 19: Technical Information (Technicians Section)
Installation and User Manual for PTE1000 V4 Technical information (technicians section) Relay Output 2 Relay Output 1 Error LED Keypad Bus Jumpers J3 / J4 Control input Expansion Port Power LED 12V DC Battery 16V AC 2A M205 Glass Fuse Power 2A M205 Glass Fuse Figure 1 - PTE101x Low Voltage Wiring Diagram... - Page 20 Installation and User Manual for PTE1000 V4 Keypad Bus General Relay Output Channel 2 Relay Error LED Output Channel 1 Relay Output Ch2 control input Ch1 control input Display Port Jumpers J3 / J4 12V DC 2A M205 Glass Fuse 16V AC 2A M205 Glass Fuse Power...
-
Page 21: Power Options
Installation and User Manual for PTE1000 V4 Label Type Description AC IN 3 Way AC Power input. 16-18Vac via F2 (2 Amp fuse). Batt 2 Way 12V dc or Battery connection via F1 (3 Amp fuse). Display 10 Way Expansion header. 2 Way PTE101x: Energiser control input (dry contact). -
Page 22: Jumpers
Installation and User Manual for PTE1000 V4 Meaning Power On with AC or DC power Error Flashes error code ,See table below Flashes Green if channel 1 is operating and voltage is good. As above for Channel 2 Will be on (RED) if the relay is in the alarm condition. - Page 23 Installation and User Manual for PTE1000 V4 dry contacts for IN1 and IN2. Do not use unless the control signal is coming from a voltage free contact i.e. a relay. J7 (2) As above. J8 (1) Links IN2 to Keypad screw terminals for Low Power mode control.
- Page 24 Installation and User Manual for PTE1000 V4 Negative Fence Output Earth Positive Fence Output Negative Return Channel 2 Monitor Earth Positive Return Channel 1 Figure 3 - PTE101x High Voltage Wiring Diagram 08/07/2006 10:11 PM Page 24 of 43...
- Page 25 Installation and User Manual for PTE1000 V4 Channel 1 Fence Output Earth Channel 2 Fence Output Monitor Reference Earth Channel 1 Return Channel 2 Return Figure 4 - PTE102x High Voltage Wiring Diagram NOTE: The order of the return terminals is different to that of the output terminals. 08/07/2006 10:11 PM Page 25 of 43...
-
Page 26: 10.0 Installation Programming Options
Installation and User Manual for PTE1000 V4 10.0 Installation Programming Options The PTE1000 series has non-volatile memory in which are held programming options (setup parameters). These are factory pre-set but can be field programmed using a keypad or a PC serial cable (from Pakton) and suitable software. -
Page 27: Programming Options In Brief
Installation and User Manual for PTE1000 V4 Programming Options in brief Option Meaning Description Siren On Time Sets the time that the siren (and keypad beeper) will stay on for after an alarm. Siren Cycles The number of times the siren will sound for the “on time” above. -
Page 28: Programming Options In Detail
Installation and User Manual for PTE1000 V4 Programming options in detail Siren on time (01x#) This option sets the time that the siren relay and keypad Value Time beeper will be on for after a fence alarm occurs. After this 10 Seconds time the siren will turn off for the same amount of time and 30 Seconds... -
Page 29: Power Level, Both Channels (06X#)
Installation and User Manual for PTE1000 V4 Power level, both channels (06x#) Same as above, but for low Power mode. Value (x) Power 0.5% 1.0% 1.5% 2.0% 2.5% 3.0% 3.5% 4.0% 4.5% 5.0% Low Power Alarm Level (07x#) Sets the voltage threshold below which the fence alarm will Value (x) Voltage occur. -
Page 30: Missed Pulse Count (13X#)
Installation and User Manual for PTE1000 V4 Missed Pulse count (13x#) Enables the pulse count to be varied from the default (3). Value (x) Missed Pulses This is the number of bad or missing pulses are counted before the alarm occurs. Note: The lower this option is set the more likely you are to get false alarms Fence Alarm Voltage, Channel 1 (14x#) Sets the voltage threshold below which the fence alarm will... -
Page 31: Battery Alarm Voltage (16X#)
Installation and User Manual for PTE1000 V4 Battery Alarm Voltage (16x#) Sets the battery voltage threshold below which the general Keypad Alarm alarm will activate. number The default Battery Alarm Voltage is Low = 11.0 Volts and 9.0 V 8.0 V Alarm = 10.0 Volts 9.5 V 8.0 V... -
Page 32: Relay Function Details
Installation and User Manual for PTE1000 V4 Relay function details. Function Logic for alarm state (opposite of normal state) Fence x Channel x is on AND the fence voltage has fallen below the programmed fence alarm voltage for more pulses than the missed count setting. Not latched. Fence x Channel x is off OR the fence voltage has fallen below the programmed fence alarm or... -
Page 33: 11.0 Sector Setup Tests And Adjustment
Installation and User Manual for PTE1000 V4 11.0 Sector Setup Tests and Adjustment With a single sector system there are three considerations for the electric fence monitor voltage level. 1. The monitor should go into alarm if one of the live wires is shorted to ground. 2. -
Page 34: 12.0 Warranty
Installation and User Manual for PTE1000 V4 12.0 Warranty The PTE1000 Series Electric Fence Energiser is covered by a 24 month warranty against defective parts or workmanship. If you have any problems, return the Energiser to Pakton Technologies Pty Ltd along with your proof of purchase, or contact the store of purchase or distributor. -
Page 35: Appendix A: As3350.2.76 Requirements For Security Electric Fences
Appendix A: AS3350.2.76 Requirements for Security Electric Fences Definitions Connecting lead an electric conductor, used to connect the energizer to the electric fence or the earth electrode Electric animal fence an electric fence used to contain animals within or exclude animals from a particular area Electric fence a barrier which includes one or more electric conductors, insulated from earth, to which electric pulses are applied by an energizer... -
Page 36: Particular Requirements For Electric Animal Fences In Australia
Figure 5 – Warning plate symbol 8. The energizer earth electrode shall penetrate the ground to a depth of at least 1 m. 9. Connecting leads that are run inside buildings shall be effectively insulated from the earthed structural parts of the building. This may be achieved by using insulated high voltage cable. -
Page 37: Installation Of Electric Security Fences
20. Where an electric animal fence crosses a public pathway, a non-electrified gate shall be incorporated in the electric fence at the point or a crossing by means of stiles shall be provided. At any such crossing, the adjacent electrified wires shall carry warning plates as described above. - Page 38 Figure 7 – Typical Constructions where an Electric Security Fence is Exposed to the Public Note 2: Typical electric security fence installations are shown in Figure 9 and Figure 10. 08/07/2006 10:11 PM Page 38 of 43...
-
Page 39: Separation Between Electric Fence And Physical Barrier
Figure 8 – Typical fence constructions where the electric security fence is installed in windows and skylights EPARATION BETWEEN ELECTRIC FENCE AND PHYSICAL BARRIER Where a physical barrier is installed in compliance with 3 at least one dimension in any opening should be not greater than 130 mm and the separation between the electric fence and the physical barrier should be –... -
Page 40: Prohibited Mounting
ROHIBITED MOUNTING Electric fence conductors should not be mounted on a support used for any overhead power line. PERATION OF ELECTRIC SECURITY FENCE The conductors of an electric fence should not be energized unless all authorized persons, within or entering the secure area, have been informed of its location. Where there is a risk of persons being injured by a secondary cause, appropriate additional safety precautions should be taken. -
Page 41: Appendix B: Group Simultaneous Pulse (Sp) Feature
Appendix B: Group Simultaneous Pulse (SP) feature In some Industrial Installations it may be preferable to provide the ability to link multiple units into a group. When linked the individual PTE1000’s become a “Group”. Members of a group have simultaneous high voltage output pulses and act as is they are one energiser with multiple outputs. -
Page 42: Group Installation Notes
Group Installation notes 1. All PTE1000’s need an appropriate high voltage circuit earth connection. 2. Each unit must have it’s own AC supply (charger) and battery. 3. Allow for the heat load of multiple units mounted inside a cabinet, approx. 5W each, 10W if the AC plug pack is also in the enclosure. -
Page 43: Appendix C: Pte0313 Group Voltage Display
Appendix C: PTE0321 Perimeter Patrol Software The Pakton PERIMETER PATROL software package enables one or more PTE1000 energizers to be monitored and controlled from a PC. It features: x User definable mimic screen background (map) x Ability to place the Zone mimics anywhere over the map x User and administrator PIN numbers x Support for PTE101x or PTE102x Energisers.
