Summary of Contents for DSP4YOU PWR-DSP1
-
Page 1: User Manual
PWR-DSP1 User Manual PWR-DSP1 DSP processed Plate Amplifier User Manual Version 1.0 Revision Description Date V1.0 User manual – Initial version 01-08-2011 Page 1 of 23 Copyrights DSP4YOU ltd... - Page 2 PWR-DSP1 User Manual PRODUCT DESCRIPTION The PWR-DSP1 answers the needs for a high power yet high quality plate amplifier module. Based on the synergetic and innovative technology from DSP4YOU and PASCAL Audio, the module is a turnkey solution for multi-way powered speakers.
-
Page 3: Table Of Contents
2.4.2 Digital Signal Processing (DSP)..........................8 2.4.3 Audio Video Bridging (AVB)............................9 Setup guide ....................................10 Box content ..................................10 Mounting instructions ..............................10 3.2.1 Mechanical installation of PWR-DSP1........................10 3.2.2 Thermal consideration ............................10 Connectivity...................................11 3.3.1 Network ..................................11 3.3.2 Analog audio connectivity ...........................11 Step by Step guide................................12 AVB Streamer Tools setup guide ..........................12... -
Page 4: Safety Instructions
PWR-DSP1 User Manual Safety Instructions • Read the information for use • Please keep this user manual in a safe place during the lifetime of the product. The user manual forms an integral part of the product. Reselling of the product is only possible if the user manual is available. Any changes made to the product have to be documented in writing and passed on to the buyer in the event of resale. - Page 5 PWR-DSP1 User Manual Cleaning Unplug the Amplifier Unit from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Power-cord Protection Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon them or against them, paying particular attention to cords and plugs, and the point where they exit from the Amplifier Unit.
-
Page 6: Product Overview
PWR-DSP1 User Manual Product Overview Front Panel Description – Top section 1. LINK OUT analog output for channel linking out from input channel 1. 2. ANALOG INPUTS channel 1&2. Fully balanced input with Pin1 (shield), Pin2 (+), Pin3 (-) 3. XLR/AVB SOURCE SWITCH for momentary source selection between the analog and the network (AVB) source... -
Page 7: Front Panel Description - Bottom Section
The amplifier outputs are provided on 3 x MOLEX connectors, 6.3mm pitch as shown on picture below. Female connectors are flush mounted to the enclosure of the PWR-DSP1. Three male connectors along with 6 inserts are provided as part of the product. -
Page 8: Feature Description
PWR-DSP1 User Manual Feature description 2.4.1 PWR-DSP1 Amplifier specifications The PWR-DSP1 is an amplifier with total of 2400W limit by its power supply. The following electrical specifications show the typical operating 2.4.2 Digital Signal Processing (DSP) The PWR-DSP1 amplifier is a plate amplifier with embedded Digital Signal Processing (DSP) controlled remotely over Ethernet networks. -
Page 9: Audio Video Bridging (Avb)
AVB devices will be released as soon as 1722.1 standard is ratified. In the mean time, It basically means that AVB streams can only be built among AVB devices of DSP4YOU (e.g. Dana server, Eline, Epower). Please check www.dsp4you.com... -
Page 10: Setup Guide
M4 T Nuts (12pcs required per PWR-DSP1) to mount unit to your enclosure Mounting instructions The PWR-DSP1 is a plate amplifier module intended to be installed at the back of a custom loudspeaker enclosure. See the mechanical drawing at the end of this document for more information. -
Page 11: Connectivity
If a DHCP server is present at boot up, the PWR-DSP1 will automatically acquire an IP address from DHCP If no DHCP server is present at boot up, the PWR-DSP1 will use the Link Local Address (Auto IP) P 169.254.0.xxx Note that no IP address needs to be remembered since units are discovered / remembered by their names in the software. -
Page 12: Step By Step Guide
PWR-DSP1 User Manual Step by Step guide The PWR-DSP1 is a powerful amplifier and could easily damage your system if incorrectly configured. Do make sure to follow these basic step by step instructions for your first time operating the product. -
Page 13: System Configuration
System Configuration User interface overview The AVBStreamer Toolbox provides a simple user interface for configuration of the AVB and DSP setting of PWR-DSP1 units. The architecture of the software can be seen below: A Device tree on the left side lists all discovered AVB devices and Virtual devices... -
Page 14: Device Info Tab
PC to load at a later time to an online device. Until ratification of 1722.1 standard, only DSP4YOU products will be recognized as part of the AVB tree. A firmware upgrade will provide discovery of other AVB devices in the future. In the mean time, It means that AVB streams can only be built among AVB devices of DSP4YOU (e.g. -
Page 15: Audio Settings Tab
4.2.3 Audio settings Tab The PWR-DSP1 includes an embedded Digital Signal Processor (DSP) used to perform basic signal processing such as filtering, gain control, equalization, dynamic range compression and time alignment. In ONLINE mode (i.e. selecting an actual unit from the device tree) all changes are performed real time and automatically saved in the flash memory of the PWR-DSP1. - Page 16 Either controlled from the switch at the back of the unit or from software, you can select the audio source between: Analog audio from the 2 x XLR connector at the back of the PWR-DSP1 Network audio from another AVB device on the network Note: Network audio (AVB) selection is only available for plug-in with the software AVB option enabled.
- Page 17 PWR-DSP1 User Manual At any times during the tuning, one can easily mouse over the curve to provide a real time reading of the equalization at a certain point. Select from Peak, High Shelf, Low Shelf filters Band selection by radio...
-
Page 18: Audio Video Bridging (Avb) Stream Configuration
4.2.4 Audio Video Bridging (AVB) stream configuration This section applies to PWR-DSP1 enabled with the AVB option. Contact DSP4YOU if you did not purchase the AVB option and would like to enable it. While the PWR-DSP1 AVB configuration requires limited setup, the following section will only highlight steps involved in building/deleting an AVB stream. - Page 19 PWR-DSP1 User Manual 2 simple sections: Talkers (source) on the left, Listeners (destination) on the right. Select one Talker (i.e. Source) from the Talker list and drag&drop it in the “Drop Talker Here” box. Repeat the same step for the Listener side (i.e. destination). The dialog box should now look like this: With the talker and listener selected, the next step in building a stream is to select the source channels from the talker channel section.
-
Page 20: System Settings Tab
PWR-DSP1 User Manual 4.2.4.2 Delete a stream Once a stream is configured, the stream is listed in the Talker stream list (below the Talker audio channels), and is uniquely identified by the Listener’s hostname. To delete a stream, simply drag from the Taker stream list the particular stream into the garbage bin. - Page 21 PWR-DSP1 User Manual 4.2.5.2 Save configuration Once a configuration defined, you can save the DSP parameters to a single xml file. If your Windows OS is not configured to show file extensions, make sure to add a .xml to the file name as shown below.
-
Page 22: Technical Specifications
PWR-DSP1 User Manual Technical specifications Electrical specifications Item Description Network Processor Plug&Play network processor for remote Amplifier/ DSP control over Ethernet networks. Support of DHCP, Auto IP and mDNS for automatic addressing. Digital Signal Processor On board DSP for gain, parametric equalizer, matrix mixing, phase, compressor limiter, delay,... -
Page 23: Mechanical Drawings
Product Warranty Terms and conditions DSP4YOU Ltd warrants all our products to be free of from defects in materials and workmanship for a period of one year from the invoice date. Our warranty terms do not cover failure of the product due to an external trigger, misuse, servicing or usage out of the recommended installation instructions.
