Summary of Contents for Trigger Scootercar
- Page 2 Please read this user manual carefully to familiarize yourself with safe and effective usage procedures. We would like to inform you that our scootercar is produced under a strict quality control system. The Trigger must undergo all periodic maintenance and services.
-
Page 3: Table Of Contents
Rear Lights ......................20 Battery and Fuse Replacement ..................21 Pre-operation Check ....................... 21 Summary of Instructions for Lubrication ..............22 Running in Your New Scootercar ................22 Technical Instructions .............. 23 Disassembling Front Body Part..................23 Assembling Left Front Wheel ..................23 Reporting Safety Defects ............ -
Page 4: Trigger Specifications
Trigger Specifications Table 1: Specifications Engine GE5 50 c.c. TGB Overall Length 2350 Overall Height 1240 Dry Weight Displacement c.c. 49.3 Spark Plug BPR6HS, BPR7HS, BP6HS 0,6~0,7 mm Battery V-AH 12V / 4AH – 7AH Fuel unleaded gasoline (octane 92 and up) or... -
Page 5: Identification Numbers
Identification Numbers Figure 1 The frame number is located under the dashboard, as shown in the figure on the left. This number is important when applying for an insurance policy. The number is also engraved into the chassis, behind the right front wheel. -
Page 6: Trigger Part Overview
Trigger Part Overview Figure 2 Figure 3... - Page 7 Trigger Part Overview continued Table 2 Figure 2 back mirror muffler headlight brake light front turn signal light luggage compartment lock Figure 3 luggage rack speedometer roll bar left handle bar switch side support left handle bar main switch rear brake lever...
-
Page 8: User's Guide
User’s Guide Main switch Figure 4 The “ ” position (between ON and OFF) is for checking the lubricant oil warning light. When the key is positioned at “ ”the oil warning light should flash once. If it doesn’t light, please contact your dealer for a replacement. -
Page 9: Important Before Starting
The Trigger uses an automatic choke. This means that no throttle is necessary when starting the engine. If the Trigger keeps failing to start, take the scootercar to the dealer for repair. To protect the engine, please avoid sudden acceleration or full speed riding. -
Page 10: Kick Start And Air Filter
Kick Start and Air Filter Figure 5 4.3.1 Kick start When the electric starter does not work, please use the kick start instead. When the engine has started, relocate the kick start to the original position. 4.3.2 Air filter The air filter must be cleaned or replaced by the dealer every 5.000 kilometers or six months. -
Page 11: Switches And Controls
Switches and Controls 4.4.1 Dashboard Figure 6 Figure 6 oil warning light (red) Turn the main switch to the “ ” position between “ON” and “OFF”. The oil warning light should flash once. turn signal light (green) When the turn signal is switched on, the light will flash and a beep will sound. fuel level meter speedometer odometer... -
Page 12: Left Handle Bar Switch
4.4.2 Left Handle Bar Switch Figure 7 4.4.3 Right Handle Bar Switch Figure 8 Figure 7 Figure 8 signal light switch front brake lever horn throttle grip The horn will sound when pushed. To increase throttle, turn towards you. rear brake lever To start the engine, the rear brake head light switch lever must be operated. -
Page 13: Brake System Instructions
Brake System Instructions Figure 9 Release the throttle before braking and apply the front and rear brakes simultaneously and gradually. To avoid skidding or loosing control, try to avoid sudden braking. Braking can be extremely difficult when riding on metal surfaces, construction sites, manhole covers, tram rails and wet roads. -
Page 14: Inspection Of Brake Fluid
Figure 11 To use the parking brake, push the small lever down while pulling the left break lever 4.5.1 Inspection of Brake Fluid Figure 12 Please check the brake fluid level regularly. It should be approximately 15 mm from the top (as shown in figure 12 on the left). -
Page 15: Fuel Tank
Fuel Tank Figure 13 When the fuel indicator is on “E” position, you may have to refill the tank immediately. The fuel inlet is located next to the passenger seat. Always use premium or unleaded gasoline (euro 95). Don’t overflow the fuel tank. WARNING Since gasoline is inflammable, please do not smoke or get in the vicinity of fire. -
Page 16: Tire
Front tire pressure: 2,10 kg/cm² Rear tire pressure: 2,50 kg/cm² Since the scootercar is fitted with tubeless tires, please repair the tire surface directly when pierced by sharp thorns, nails etc. Charging the battery... -
Page 17: Maintenance & Inspection
Maintenance & Inspection Gear Oil Replacement Change of gear oil should be carried out after the first 1000 km. After that, oil should be changed every 5.000km. Gear lubricant code SAE 85W-90. The gear lubricant inlet is located at the left hand side of the rear wheel on top of the crankcase. -
Page 18: Light Bulb Replacement
Before installing the spark plug, check the electrode gap with a gauge and modify if necessary to measure 0.6-0.7 mm (figure 16). When reinstalling the spark plug, clean the gasket surface and utilize a new gasket. Tighten the plug with a torque of 20N/M (2.0 kg/M). Light Bulb Replacement 5.4.1 Head Lights (12V 15W x 2) -
Page 19: Front Signal Lights (12V 10W)
5.4.2 Front Signal Lights (12V 10W) Figure 20 Disassembling the light bulb socket. Turn the bayonet catch counter clockwise from the inside of the body. Replace with a 12 Volt 10 Watt bulb. 5.4.3 Rear Lights Figure 21 Disassembling the rear light reflector. Unfasten both screws at the top to take off the outer reflector. -
Page 20: Battery And Fuse Replacement
The 10A fuse is located in a separate container that can be unscrewed for replacement. Pre-operation Check Table 4: Before operating the scootercar, the following points must be checked: inspection items description front brake Check whether brakes function within normal parameters. -
Page 21: Summary Of Instructions For Lubrication
Try not to accelerate with full throttle. When a cylinder, piston, or crankshaft is replaced, please avoid full speed riding within the first 1.000 KM. Avoid full acceleration when the scootercar is not in optimal condition. -
Page 22: Technical Instructions
DISCLAIMER The information on this page is for technical reference purposes only. The instructions / maintenance should only be carried out by your Trigger dealer. Trigger Technics is not responsible for any damage resulting from improper use. Disassembling Front Body Part... -
Page 23: Reporting Safety Defects
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Trigger Technics BV. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. -
Page 24: Safe Riding Tips
If the user has any questions with regard to a part or the scootercar as a whole, please consult our distributor or agent for more details.
