ARX®6000 Hardware Installation
Guide
Part Number: 810-0001-00, Revision R
Acopia Networks, Inc.
41 Wellman Street
Lowell, MA 01851
(978) 513-2900 tel
(978) 513-2990 fax

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARX 6000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Acopia Networks ARX 6000

  • Page 1 ARX®6000 Hardware Installation Guide Part Number: 810-0001-00, Revision R Acopia Networks, Inc. 41 Wellman Street Lowell, MA 01851 (978) 513-2900 tel (978) 513-2990 fax...

  • Page 2: Revision History

    In no event will Acopia Networks be liable for direct, indirect, special, exemplary, incidental, or consequential damages resulting from any defect or omission within this document. Acopia Networks, Inc. reserves the right to alter the contents of this document at any time, and without any notice.

  • Page 3: Table Of Contents

    Contents Chapter 1 Introduction Audience for this Manual..................1-1 Document Conventions .....................1-1 Related Documents ....................1-2 Safety and Regulatory Notices..................1-3 Class A ITE Label....................1-3 Laser Product Notice..................1-4 Qualified Personnel Warning ................1-5 Environmental....................1-5 High Temperature Warning.................1-5 Restricted Area Warning................1-5 Warning for Rack-Mounting and Servicing..........1-6 Power .........................1-7 Power Cord Usage ..................1-7 Electric Shock Warning ................1-7...
  • Page 4 File Services ...................... 2-4 Security and Authentication ................2-5 Management ...................... 2-5 Chapter 3 Chassis Hardware Chassis Components....................3-2 Power Supply..................... 3-3 Disk Drives......................3-5 Logical Unit Numbers (LUNs) ..............3-5 Status LEDs....................3-6 Fan Tray Module ....................3-6 Features ...................... 3-6 Chassis Configurations .....................
  • Page 5 Chapter 5 System Specifications System Specifications ....................5-2 System Power Requirements..................5-4 Power Cord and Cable Requirements ...............5-5 Regulatory Compliance ....................5-6 FCC Compliance .......................5-7 Chapter 6 Unpacking and Installing the Chassis Safety Instructions.....................6-2 Required Tools and Equipment .................6-2 Verifying Shipment ....................6-3 Unpacking the Chassis ....................6-4 Removing the Fan Tray .....................6-6 Removing a Power Supply.................6-7 Rack-Mounting the Chassis ..................6-8...
  • Page 6 Booting the Switch ....................7-3 Sample: Booting a Non-Replacement Switch ........... 7-3 Preparing for Switch Replacement..............7-7 Before You Begin: Verifying Hardware Compatibility......7-7 Choosing Switch Replacement..............7-7 Matching the Private Subnet ..............7-8 Entering the Private Subnet..............7-8 Finding the UUID of the Failed Switch ............. 7-9 Applying the UUID................
  • Page 7 Removing and Replacing FRUs 1 Before You Begin ..................... B-1 Removing and Replacing Modules ................B-2 Removing and Replacing a Disk Drive..............B-3 Removing and Replacing the Fan Tray ..............B-4 Removing and Replacing a Power Supply............... B-5 Removing and Replacing the Air Filter ..............B-5 ARX®6000 Hardware Installation Guide 2-vii...
  • Page 8 2-viii ARX®6000 Hardware Installation Guide...

  • Page 9: List Of Figures

    List of Figures Figure 3-1. Chassis Front View ................... 3-3 Figure 3-2. Disk Drive and Power-Supply Locations..........3-4 Figure 3-3. Dual-Channel Internal Drive Connections..........3-5 Figure 4-1. NSM-TX Front Panel ................4-6 Figure 4-2. NSM-FX Front Panel ................4-7 Figure 6-1. Chassis Shipping Carton ................
  • Page 10 ARX®6000 Hardware Installation Guide...
  • Page 11 List of Tables Table 3-1. ARX®6000 Chassis Configurations ............3-7 Table 5-1. System and Module Specifications ............5-2 Table 5-2. Module Power Consumption..............5-4 Table 5-3. Required Power and Data Cables............... 5-5 Table 6-1. Verify Shipping-Crate Contents..............6-3 Table 8-1. Module Operational States and LED Patterns..........
  • Page 12 4-xii ARX®6000 Hardware Installation Guide...

  • Page 13: Introduction

    Chapter 1 Introduction This manual describes the Acopia™ Adaptive Resource Switch 6000 (ARX®6000) and its hardware components. It also describes how to install the switch and connect it to the network. Audience for this Manual This manual is intended for field engineers and network administrators responsible for setting up and connecting the switch to a network at the enterprise data center facility.

  • Page 14: Related Documents

    Introduction Related Documents Cautions show how to avoid possible service outage or data loss. CAUTION Warnings are instructions for avoiding damage to the equipment. WARNING Danger notices help you to avoid personal injury. DANGER DANGER Related Documents In addition to this guide, the following Acopia documentation is also available: •...

  • Page 15: Safety And Regulatory Notices

    Introduction Safety and Regulatory Notices Safety and Regulatory Notices The maximum ambient room temperature that the unit can operate in is 55° C. CAUTION Do not block power supply vents or otherwise restrict airflow when installing unit in CAUTION rack. Mechanical loading of rack should be considered so that the rack remains stable and WARNING unlikely to tip over.

  • Page 16: Laser Product Notice

    Introduction Safety and Regulatory Notices Laser Product Notice Class 1 laser product. WARNING Produit laser de classe I. ATTENTION Class 1 lasers are defined as products which do not permit human access to laser radiation in excess of the accessible limits of Class 1 for applicable wavelengths and durations.

  • Page 17: Qualified Personnel Warning

    Introduction Safety and Regulatory Notices Qualified Personnel Warning Only trained and qualified personnel should be allowed to install, replace, or service WARNING this equipment. Il est vivement recommandé de confier l'installation, le remplacement et la maintenance ATTENTION de ces équipements à des personnels qualifiés et expérimentés. Environmental High Temperature Warning To prevent the switch from overheating, do not operate it in an area that exceeds the...

  • Page 18: Warning For Rack-Mounting And Servicing

    Introduction Safety and Regulatory Notices Cet appareil est à installer dans des zones d'accès réservé. Ces dernières sont des zones ATTENTION auxquelles seul le personnel de service peut accéder en utilisant un outil spécial, un mécanisme de verrouillage et une clé, ou tout autre moyen de sécurité. L'accès aux zones de sécurité...

  • Page 19: Power

    Introduction Safety and Regulatory Notices Power Power Cord Usage Do not use the attached power supply cable for other devices or usage. WARNI The attached power supply cable was designed to be connected and to be used for Acopia devices, and the safety for this purpose has been confirmed. Please do not use it for other devices or usages.

  • Page 20: Circuit Breaker (15A)

    Introduction Safety and Regulatory Notices Les ports étiquetés LINK, 1/1 through 1/6, CONSOLE, MGMT, MIRROR, et DEBUG ATTENTION sont des circuits de sécurité basse tension (safety extra-low voltage ou SELV). Les circuits SELV ne doivent être interconnectés qu'avec d'autres circuits SELV. Circuit Breaker (15A) This product relies on the building's installation for short-circuit (overcurrent) WARNING...

  • Page 21: International Power-Cord Requirements

    Introduction Safety and Regulatory Notices Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par ATTENTION une pile de type semblable ou équivalent, recommandée par le fabricant. Jeter les piles usagées conformément aux instructions du fabricant. International Power-Cord Requirements International Cords should have the following characteristics- •...

  • Page 22: Contacting Customer Service

    Introduction Contacting Customer Service Contacting Customer Service You can use the following methods to contact Acopia Customer Service: support@acopia.com E-mail 1-866-4Acopia (1-866-422-6742) Telephone http://www.acopia.com/support/ Acopia TAC Online Acopia’s online customer knowledge base and support request system 1-10 ARX®6000 Hardware Installation Guide...

  • Page 23: Product Overview

    Chapter 2 Product Overview This chapter provides a general overview of the Acopia ARX®6000. Topics include the following: • “The ARX” on page 2-1 • “Redundancy Features” on page 2-3 • “Switch Management” on page 2-3 • “Supported Protocols” on page 2-4 The ARX The Adaptive Resource Switch (ARX) 6000 is a 6-slot switch for use in large data centers and regional data centers.
  • Page 24 Product Overview The ARX The switch consists of a 6-slot chassis that accommodates a system management and control module and a family of service modules that support Fast Ethernet and Gigabit Ethernet interfaces for connectivity to network infrastructure, network-attached storage (NAS) devices, and file servers with direct-attached storage (DAS).

  • Page 25: Redundancy Features

    Product Overview Redundancy Features Redundancy Features The ARX®6000 system is designed to provide a highly available service with fault tolerance and no single point of failure. This design provides the following features: • High availability (HA) clustering for switch redundancy, including intra-box (modules) and inter-box (redundant-pair) failover capability: –...

  • Page 26: Supported Protocols

    Product Overview Supported Protocols See the CLI Network-Management Guide CLI Reference Guide for information about configuring the in-band interfaces. Supported Protocols The Acopia switch supports a range of network, application, and file-access protocols, including the following: • Layer 2 and layer 3 network protocols •...

  • Page 27: Security And Authentication

    Product Overview Supported Protocols • Network File System (NFS): NFSv2 over UDP and NFSv3 over TCP or UDP • Network Locking Manager (NLM) Security and Authentication • NT LAN Manager (NTLM) v1 (supported through Acopia Secure Agent. See the Secure Agent Installation Guide for information.) •...
  • Page 28 Product Overview Supported Protocols ARX®6000 Hardware Installation Guide...

  • Page 29: Chassis Hardware

    Chapter 3 Chassis Hardware This chapter describes the switch chassis components and hardware configuration. Topics include the following: • “Chassis Components” on page 3-2 • “Power Supply” on page 3-3 • “Disk Drives” on page 3-5 • “Fan Tray Module” on page 3-6 •...

  • Page 30: Chassis Components

    Chassis Hardware Chassis Components Chassis Components The Acopia ARX®6000 switch is a 6-slot chassis that mounts into a standard 19-inch rack. The first slot is reserved for switch management, control, and switch-fabric functions. The remaining five slots support interchangeable installation of I/O service modules.

  • Page 31: Power Supply

    Chassis Hardware Chassis Components The chassis utility bay accommodates two system disk drives and up to two power supplies. Figure 3-1. Chassis Front View Fan tray (houses 6 fans) Utility bay management houses module (slot 1) disk drives and power supplies Service modules in any of slots 2–6...

  • Page 32: Figure 3-2. Disk Drive And Power-Supply Locations

    Chassis Hardware Chassis Components • Separate AC Fail and DC Fail fault indicators per power supply unit • Power Fail and over-temperature alarms displayed on system console • Hot swappable and front accessible components Chapter 5 for power requirements and specifications. Figure 3-2.

  • Page 33: Logical Unit Numbers (Luns)

    Chassis Hardware Chassis Components Disk Drives The switch requires two system disk drives for operation. Together the two disk drives provide RAID Level 1 redundancy. The drives contain software images, reports, scripts, log files, and configuration files. The disk drives are connected through a SCSI bus to the System Control Module (SCM) in the chassis.

  • Page 34: Status Leds

    Chassis Hardware Chassis Components Status LEDs The disk drives provide three status LEDs: • Red — indicates Activity • Green — indicates Power • Orange — indicates Failure Fan Tray Module The chassis fan tray module is an environmentally controlled fan system with an intelligent fan controller.

  • Page 35: Chassis Configurations

    Chassis Hardware Chassis Configurations • Failure indications include: • Single fan failure • Multiple fan failure • Low/high RPM on any fan • High temperature • Lost SCM-to-fan tray communication Chassis Configurations The ARX®6000 can accommodate up to six modules in its chassis, and these modules can be configured to maximize throughput or to maximize high availability between switches.

  • Page 36: Redundant Pairs

    Chassis Hardware Redundant Pairs Basic System Maximum Capacity Slot Module Slot Module Utility Bay 2 disk drives: D1, D2 2 disk drives: D1, D2 2 power supplies 2 power supplies: PS1, PS2 The SCM always uses slot 1. Service modules may use any of slots 2–6. For in-chassis high availability, redundant modules are installed in adjacent slots, for example, ASMs in slots 3 and 4, and NSMs in slots 5 and 6.
  • Page 37 Chassis Hardware Resilient Overlay Network (RON) See the CLI Network-Management Guide CLI Reference Guide for information about configuring RON tunnels. ARX®6000 Hardware Installation Guide...
  • Page 38 Chassis Hardware Resilient Overlay Network (RON) 3-10 ARX®6000 Hardware Installation Guide...

  • Page 39: Hardware Modules

    Chapter 4 Hardware Modules This chapter describes the switch modules, including their hardware features, functions, and front panel interfaces. For information about module connectors and pinout assignments, see Appendix A, Cable Connectors. ARX®6000 modules include the following management and service modules: •...

  • Page 40: System Control Module (Scm)

    Hardware Modules System Control Module (SCM) System Control Module (SCM) The System Control Module (SCM) provides the management and control functions for the other modules in the chassis. The SCM communicates with the slots in the chassis over a system status bus, which enables the SCM to manage, monitor, and control module activity.

  • Page 41: Features

    Hardware Modules System Control Module (SCM) Features The SCM provides or supports the following features and functions: Switch Fabric • Non-blocking architecture for 40-Gbps full duplex non-blocking aggregate throughput • 10-Gbps full duplex throughput for each service module slot • Switch control-plane and data-plane functions •...

  • Page 42: Dual-Channel Scm

    Hardware Modules Adaptive Services Module (ASM) • Power draw for each module • Fan tray control interface Dual-Channel SCM The SCM’s dual-channel bus architecture enables it to communicate over two separate buses to the system disk drives. This configuration provides an additional level of redundancy by providing a second SCSI bus and permits each SCSI drive to be connected to the SCM in slot 1.
  • Page 43 Hardware Modules Network Services Module (NSM) • NSM-TX — 6-port copper connections • NSM-FX — 6-port fiber-optic connections, multi-mode ARX®6000 Hardware Installation Guide...

  • Page 44: Nsm-Tx

    Hardware Modules Network Services Module (NSM) NSM-TX Figure 4-1 shows the NSM-TX module front panel, which provides six RJ-45 connections. Figure 4-1. NSM-TX Front Panel Alert and Status LEDs (See Chapter 8 for LED information.) Ports 1–6, Link status Ports 1– 6, RJ-45 ARX®6000 Hardware Installation Guide...

  • Page 45: Nsm-Fx

    Hardware Modules Network Services Module (NSM) NSM-FX Figure 4-2 shows the NSM -FX module front panel, which provides six small form-factor pluggable (SFP) optical connectors, 850nm multi-mode. These connectors can reach distances up to 500m over 50/125um MMF. Figure 4-2. NSM-FX Front Panel Alert and Status LEDs (See Chapter 8...

  • Page 46: Features

    Hardware Modules Network Services Module (NSM) Features The NSM provides or supports the following features and functions: • Network connectivity • Auto-negotiation for 100/1000 Ethernet transmission • Standard Ethernet and jumbo-frame (9K) packet sizes • Full-duplex switching at line rates for Layer 2 processing •...
  • Page 47 Chapter 5 System Specifications This chapter describes technical system specifications, power requirements, and cable requirements for the ARX and its components. This chapter also describes regulatory information. Topics include: • “System Specifications” on page 5-2 • “System Power Requirements” on page 5-4 •...

  • Page 48: Table 5-1. System And Module Specifications

    System Specifications System Specifications System Specifications Table 5-1 describes the ARX system specifications. Table 5-1. System and Module Specifications Component Specification Chassis Dimensions Height: 22.75 in. (includes fan tray and front bezel) Width: 19.00 in. (including the fixed mounting ears) Depth: 23.00 in.
  • Page 49 System Specifications System Specifications Table 5-1. System and Module Specifications (Continued) Component Specification Fan Tray Power Input voltage: 48 Vdc (6 fans) Max. input current: 4 A Airflow Clearance Minimum clearance of 12 inches (30.48 cm) required for air intake from bottom front of chassis and exit through the top back (and side) of chassis to maintain proper venting and prevent overheating.

  • Page 50: System Specifications

    System Specifications System Power Requirements System Power Requirements The ARX®6000 chassis uses one or two power supplies. When two power supplies are installed, the power load is shared. The power supplies require a 20 A/220 Vac input cord, which is provided with the chassis. The AC outlet to the switch must be properly grounded.

  • Page 51: Power Cord And Cable Requirements

    System Specifications Power Cord and Cable Requirements If you want to plan for future expansion, you can budget for a total of 1704 Watts power dissipation. This is equivalent to 5812 BTUs/hour. Power Cord and Cable Requirements Table 5-3 lists the required cables and power cords for the switch. All cables except the AC power cord and console cable are customer-supplied.

  • Page 52: Regulatory Compliance

    System Specifications Regulatory Compliance Gigabit Ethernet ports support automatic MDI/MDIX cross-over. This feature automatically corrects the polarity of the attached CAT5 cable, regardless if it is a cross-over or straight-through type. However, for this feature to work, the port speed must be set to auto (auto-negotiate) through the CLI. When the port speed/duplex is forced (auto-negotiate is disabled), automatic MDI/MDIX cross-over is disabled, and you must cable the port using standard cross-over or straight-through cabling.

  • Page 53: Fcc Compliance

    System Specifications FCC Compliance FCC Compliance This is a Class A product. In a domestic environment this product may cause radio CAUTION interference, in which case the user may be required to take adequate measures. Changes or modifications not expressly approved by the manufacturer could void the user’s FCC granted authority to operate this equipment.
  • Page 54 System Specifications FCC Compliance ARX®6000 Hardware Installation Guide...
  • Page 55 Chapter 6 Unpacking and Installing the Chassis This chapter describes the following topics and tasks: • “Safety Instructions” on page 6-2 • “Required Tools and Equipment” on page 6-2 • “Verifying Shipment” on page 6-3 • “Unpacking the Chassis” on page 6-4 •...

  • Page 56: Unpacking And Installing The Chassis

    Unpacking and Installing the Chassis Safety Instructions Safety Instructions Observe the following safety guidelines to avoid personal injury or damage to equipment when installing or operating the switch: The chassis is both heavy and difficult to maneuver. Two or more people are required to DANGER move and lift the chassis.

  • Page 57: Verifying Shipment

    Unpacking and Installing the Chassis Verifying Shipment Verifying Shipment The ARX®6000 shipment includes: • Chassis and hardware components • Accessory kit Check the contents of the shipping crate and any additional boxes to verify complete shipment. Table 6-1 lists the contents you should receive. Table 6-1.

  • Page 58: Unpacking The Chassis

    Unpacking and Installing the Chassis Unpacking the Chassis Unpacking the Chassis The chassis is shipped with all ordered components installed. The chassis shipping carton is attached to a reinforced pallet for easy transfer (using a handcart or pallet jack) to the installation site. The accessory kit is packaged with the chassis. Figure 6-1.
  • Page 59 Unpacking and Installing the Chassis Unpacking the Chassis Before unpacking the chassis, inspect the carton for any shipping damage. Using a wire cutter, cut and remove the package strapping from the shipping carton. Remove the carton top cover and open the box. Remove the small box inside.

  • Page 60: Removing The Fan Tray

    Unpacking and Installing the Chassis Removing the Fan Tray Removing the Fan Tray Loosen the captive screws on either side of the fan tray, grasp the handle, and slowly pull the fan tray toward you (see Figure 6-2). Figure 6-2. Removing Fan Tray captive screws Carefully slide the fan tray out of the top of the chassis and set aside.

  • Page 61: Removing A Power Supply

    Unpacking and Installing the Chassis Removing the Fan Tray Removing a Power Supply In the utility bay, remove the power supply by carefully inserting a flat-head screwdriver into the center notch and pulling up and out. The power supply handle will release toward you. Figure 6-3.

  • Page 62: Rack-Mounting The Chassis

    Unpacking and Installing the Chassis Rack-Mounting the Chassis Rack-Mounting the Chassis An EAI standard rack has holes that you must align with the holes in the chassis flange. A set of ARX®6000 rack-mount-alignment templates are included in the accessory kit to help with this alignment. These are long, white stickers with holes in the same pattern as the chassis flange.

  • Page 63: Installing The Front Bezels

    Unpacking and Installing the Chassis Installing the Front Bezels Installing the Front Bezels After you have reinstalled the fan tray and power supplies in the chassis, you can install the front bezels over the fan tray and utility bay. The bezels are shipped in the accessory kit.

  • Page 64: Utility Bay

    Unpacking and Installing the Chassis Installing the Front Bezels Utility Bay Align the bezel over the utility bay, holding the bezel by the indentation on the left side for an easier grip. Align the clips (on back of bezel) with the pins at the top and bottom on the utility bay.

  • Page 65: Attaching The Power Cords

    Unpacking and Installing the Chassis Attaching the Power Cords Attaching the Power Cords To attach the AC power cords to the chassis: Locate the power ON/OFF toggle switch(es) on the back of the chassis and ensure they are set to the OFF position. For a chassis with only one power supply, attach the power cord to the right plug.

  • Page 66: Powering Up The Chassis

    Unpacking and Installing the Chassis Powering Up the Chassis Powering Up the Chassis The switch requires a dedicated 20A circuit for each AC/DC power supply. NOTE Before applying power, ensure that the AC outlet to the switch is properly grounded. WARNING To power up the chassis, turn the ON/OFF toggle switch(es) to the ON position.

  • Page 67: Cabling The Modules

    Unpacking and Installing the Chassis Cabling the Modules Cabling the Modules You can cable the modules before or after the switch is connected to the network. For console connection and switch-boot information, see Chapter 7, Connecting the Switch to the Network.

  • Page 68: Installing The Air-Filter Panel And Cable Guide

    Unpacking and Installing the Chassis Air Filter and Cable Management Figure 6-8 shows the air filter and cable guide location on the bottom front of the chassis. Figure 6-8. Air Filter/Cable Guide Location Air filter and cable guide location Installing the Air-Filter Panel and Cable Guide Customers are required to maintain the switch’s air filter at regular intervals.
  • Page 69 Unpacking and Installing the Chassis Air Filter and Cable Management Remove the air-filter front panel/cable guide from the accessory kit. Remove the tape from the air filter opening and verify the air filter is seated properly in the chassis. Insert the cable guide into the opening, aligning the captive screws on either side with the holes in the chassis.
  • Page 70 Unpacking and Installing the Chassis Air Filter and Cable Management 6-16 ARX®6000 Hardware Installation Guide...
  • Page 71 Chapter 7 Connecting the Switch to the Network This chapter describes how to connect the ARX to a console terminal and boot the switch for the first time. Topics and tasks include: • “Management Interfaces” on page 7-2 • “Connecting the Console Terminal” on page 7-3 •...

  • Page 72: Connecting The Switch To The Network

    Connecting the Switch to the Network Management Interfaces Management Interfaces The System Control Module (SCM) provides the following management ports: • Console - a serial Console port for connecting a console terminal, and • MGMT - a 10/100 Ethernet port for an out-of-band (OOB) management station. OOB management (RJ-45) serial Console (RJ-45) During the initial-boot process described in this chapter, you can only access the serial...

  • Page 73: Connecting The Console Terminal

    Connecting the Switch to the Network Connecting the Console Terminal Connecting the Console Terminal Set the following console-terminal parameters to match those on the SCM’s Console port: • 9600 baud rate (default) • XON-XOFF flow control • 8 data bits •...
  • Page 74 Connecting the Switch to the Network Booting the Switch • this replaces a defunct switch, • this will join a running switch as its redundant peer, or • this switch is being re-installed after Acopia personnel performed a “Manufacturing Installation” on a previously-running switch. Later sections discuss these contingencies and how to handle each of them.
  • Page 75 Connecting the Switch to the Network Booting the Switch 2. Enter 'yes' to accept these terms and conditions in the format 'yes' or 'no'. # yes The switch's management port requires an IP address and mask. 3. Enter the management port IP address in the format nnn.nnn.nnn.nnn or 'none'.
  • Page 76 Connecting the Switch to the Network Booting the Switch Configuration Summary Management IP Address 10.1.1.7 Management IP Mask 255.255.255.0 Management Gateway 10.1.1.1 Power Configuration Private IP Subnet 169.254.6.0 Private IP Mask 255.255.255.0 Private VLAN 1002 Private Metalog VLAN 1003 Chassis GUID d9bdece8-9866-11d8-91e3-f48e42637d58 Switch Password #######...

  • Page 77: Preparing For Switch Replacement

    Connecting the Switch to the Network Booting the Switch User Access Authentication Username: admin Password: mypassword SWITCH> The switch is now ready for configuration through the GUI or the CLI. See the Quick Start: Network Setup manual for instructions on using the GUI to set up network parameters, or the CLI Network-Management Guide for detailed...

  • Page 78: Matching The Private Subnet

    Connecting the Switch to the Network Booting the Switch Matching the Private Subnet The next set of questions ask for the switch’s private subnet, the private VLAN for that subnet, and the VLAN for a private metalog subnet. If the failed switch was in a redundant pair and/or RON network, the private subnets of the replacement switch should match those of the switch that failed.

  • Page 79: Finding The Uuid Of The Failed Switch

    Connecting the Switch to the Network Booting the Switch The private subnet VLAN is used externally for redundancy traffic. Be sure this value does not conflict with existing VLAN IDs. 9. Enter the chassis's private subnet VLAN in the format integer [1-4095].(default=1002) # <Enter> The private subnet metalog VLAN is used for storing file-change logs on battery-backed NVRAM, possibly on a redundant peer.

  • Page 80: Applying The Uuid

    Connecting the Switch to the Network Booting the Switch Switch Name HA Peer Switch Uptime Status UUID Management Addr ------------------------------------------------------------------------------ bstnA6k (None) 0 days, 01:56:58 OFFLINE d9bdece8-9866-11d8-91e3-f48e42637d58 10.1.1.7 provA5c (None) 0 days, 01:55:15 ONLINE db922942-876f-11d8-9110-8dtu78fc8329 10.1.38.19 prtlndA1k prtlndA1kB 0 days, 00:25:04 ONLINE 876616f6-79ac-11d8-946f-958fcb4e6e35 10.1.23.11...

  • Page 81: Preparing To Install A Redundant Peer

    Connecting the Switch to the Network Booting the Switch Preparing to Install a Redundant Peer The initial-boot script requires some additional information if you are installing the second switch in a redundant pair. Both members of a redundant pair share a common master key.

  • Page 82: Applying The Master Key

    Connecting the Switch to the Network Booting the Switch 2oftVCwAAAAgAAAApwazSRFd2ww/H1pi7R7JMDZ9SoIg4WGA/XsZP+HcXjsIAAA ADDRbMCxE/bc= bstnA6kB# ... Applying the Master Key As shown in an example earlier, there is a prompt for the master key in the initial-boot script. You can answer this prompt with the encrypted master key; the script then prompts for the wrapping password.
  • Page 83 Connecting the Switch to the Network Booting the Switch Acknowledge acceptance of the following terms and conditions by entering 'yes' at the next question. 1. Press <Enter> to continue. # <Enter> LICENSE AGREEMENT 2. Enter 'yes' to accept these terms and conditions in the format 'yes' or 'no'.
  • Page 84 Connecting the Switch to the Network Booting the Switch in the format nnn.nnn.nnn.nnn.(default=255.255.255.0) # <Enter> The private subnet VLAN is used externally for redundancy traffic. Be sure this value does not conflict with existing VLAN IDs. 9. Enter the chassis's private subnet VLAN in the format integer [1-4095].(default=1002) # <Enter>...
  • Page 85 Connecting the Switch to the Network Booting the Switch The master key is used to encrypt critical security parameters. 15. Enter the master key in the format base64-encoded key or keyword 'generate'.(default=generate) # 2oftVCwAAAAgAAAApwazSRFd2ww/H1pi7R7JMDZ9SoIg4WGA/XsZP+HcXjsIAAAADDRbMCxE/bc= The wrapping password in use to encrypt and decrypt the master key. 16.
  • Page 86 Connecting the Switch to the Network Booting the Switch the crypto-officer's username and password. Closing configuration file. Processing configuration file. (boot-config) User Access Authentication Username: admin Password: mypassword SWITCH> The switch is now ready for configuration through the GUI or CLI. To join it with its redundant peer, you can use the standard practice of copying and applying the failed switch’s running config: SWITCH>...

  • Page 87: Connecting The Ethernet Management Port

    Connecting the Switch to the Network Connecting the Ethernet Management Port SWITCH# ; SWITCH# config SWITCH(cfg)# logging level all info SWITCH(cfg)# exit SWITCH# SWITCH#;================================= vlan ================================== SWITCH# config bstnA6k(cfg)# ... SWITCH(cfg)# hostname bstnA6k bstnA6k(cfg)# ... bstnA6k(cfg)# exit If you copied the private subnet and mask from the defunct switch, this completes the switch replacement.
  • Page 88 Connecting the Switch to the Network Connecting the Ethernet Management Port 7-18 ARX®6000 Hardware Installation Guide...

  • Page 89: Operational Status And Troubleshooting

    See the following sample output. chassis Figure 8-1. Show Version Sample bstnA6k> show version Copyright (c) 2002-2007 by Acopia Networks Inc. All rights reserved. Running Release test1.rel : Version 2.05.000.09940 (Feb 8 2007 17:40:53) [nbuilds] Armed Release test1.rel :...

  • Page 90: Figure 8-2. Show Chassis Sample

    Operational Status and Troubleshooting POST Diagnostics bstnA6k uptime is 0 weeks, 0 days, 0 hours, 49 minutes. Slot Admin ModuleType ModuleState FW Upgrade ---- ------- ------------ ---------------- ---------- Enabled Online Disabled Enabled Empty Disabled Enabled Online Disabled Enabled Empty Disabled Enabled Online Disabled...
  • Page 91 Operational Status and Troubleshooting POST Diagnostics 00:0a:49:00:0a:00 Failed Partial Online (low) Normal 26 C Power Details: Power State Voltage ------ ----- ------- Online Failed Logical Disk Details: Disk Status Verification Mode Verification Rate ------ --------------------- ----------------- ----------------- Verifying 10 % Manual 50 % Disk Details:...
  • Page 92 Operational Status and Troubleshooting POST Diagnostics NSM_TX 700 MHz 2048 MB 00000032 ASM_FC 1.6 GHz 4096 MB 00000016 Slot MAC Address HW Version Rework Deviation ---- ---------------------------- ---------- ------ --------------------- 000A49000A09 to 000A49000A09 A 19 000A49000A1B to 000A49000A26 A 24 000A49000A39 to 000A49000A3A A 16 Slot Boot Version...

  • Page 93: Led Status Indicators

    Operational Status and Troubleshooting LED Status Indicators Temperature Details: Sensor 1 (C) Sensor 2 (C) Sensor 3 (C) Sensor 4 (C) Slot Module Local Remote Local Remote Local Remote Local Remote ---- ------ ----- ------ ----- ------ ----- ------ ----- ------ NVR: NVR Battery ECC State...

  • Page 94: Table 8-1. Module Operational States And Led Patterns

    Operational Status and Troubleshooting LED Status Indicators Table 8-1 describes the LED colors and blinking patterns that occur during various module operational states, such as booting, diagnostics (pass/fail), when a module is inserted into a slot, and so on. You can find more details on the from the Module State output of the...

  • Page 95: Ethernet-Port Link Status Leds

    Operational Status and Troubleshooting LED Status Indicators Ethernet-Port Link Status LEDs MGMT Port on the SCM The out-of-band management port on the System Control Module (SCM), labeled “MGMT,” has two LEDs: • Top – Link-status LED: steady green indicates that the port is enabled and a link is established.

  • Page 96: Fan Tray Leds

    Operational Status and Troubleshooting LED Status Indicators Fan Tray LEDs The fan-tray module front panel provides two status LEDs, ALERT (top) and STATUS (bottom). Table 8-2 describes the fan tray LED indicators and associated conditions. Table 8-2. Fan Tray Status LEDs ALERT STATUS Condition...

  • Page 97: Cable Connectors

    Appendix A Cable Connectors This appendix describes the cable connectors used on the ARX®6000 modules (see Table A-1). Table A-1. Module Cable Connectors Module Connector Purpose • Ethernet management port System Control Module (SCM) RJ-45 • Mirror port for port mirroring and diagnostics •...

  • Page 98: For The Serial-Console Port

    Cable Connectors For the Serial-Console Port For the Serial-Console Port The serial-Console port requires a rollover cable (RJ-45 to RJ-45) that is included with the ARX-installation kit. This cable is sufficient for connecting to a Terminal Server. For a direct connection to the serial port on a management station (such as a laptop), an RJ-45 to DB9 adapter is also included in the kit.

  • Page 99: Table A-2. Scm Console Port Signaling/Cabling Using A Cross-Over Cable

    Cable Connectors For the Serial-Console Port Table A-2. SCM Console Port Signaling/Cabling Using a Cross-over Cable SCM/ACM Cross-over Cable Terminal Adapter Console Console Port Device DTE Signal RJ-45 USOC RJ-45 RJ-45 T568 DB9F Pinout Color Pinout Pinout Color Pinout Signal yellow yellow green...

  • Page 100: Sfp Optical Connector

    Cable Connectors SFP Optical Connector SFP Optical Connector The Network Services Module (NSM) optical version uses small form-factor pluggable (SFP) optical connectors for connection to Ethernet over fiber-optic cable. Figure A-3 shows an example SFP connector. Figure A-3. SFP Optical Connector Fiber-optic ports are shipped with cable connectors installed.

  • Page 101: Removing And Replacing Frus

    Appendix B Removing and Replacing FRUs This chapter describes how to remove and replace the following field replaceable units (FRUs) in the ARX®6000 chassis: • “Removing and Replacing Modules” on page B-2 • “Removing and Replacing a Disk Drive” on page B-3 •...

  • Page 102: Removing And Replacing Modules

    Removing and Replacing Modules Removing and Replacing Modules Removing a non-NSM module (or the only NSM) causes the switch to reboot. CAUTION In a redundant pair where this switch is active, services fail over to the junior switch. In a redundant pair where this switch is in the Backup/junior role, service is unaffected. A standalone switch does not offer any service for the duration of the reboot.

  • Page 103: Removing And Replacing A Disk Drive

    Removing and Replacing a Disk Drive Figure B-1. Ejector Tabs on Modules down and locked Removing and Replacing a Disk Drive Static electricity can damage switch components. Be sure to wear antistatic wrist straps WARNING before handling disk drives and modules. To remove and replace a disk drive: Insert a key and turn the lock to the right to release the drive handle.

  • Page 104: Removing And Replacing The Fan Tray

    Removing and Replacing the Fan Tray Figure B-2. Removing a Disk Drive Unlock key, then pull handle (hinged) out toward you Keys: Notch up - drive locked Notch to the right - drive unlocked Removing and Replacing the Fan Tray Remove the fan tray as described in “Removing the Fan Tray”...

  • Page 105: Removing And Replacing A Power Supply

    Removing and Replacing a Power Supply Removing and Replacing a Power Supply Remove a power supply as described in “Removing a Power Supply” on page 6-7. To replace a power supply, reverse the steps. A chassis configured with two power supplies has two power cords. In the event that DANGER AC power must be removed from the system, disconnect both power cords before servicing the unit to avoid electric shock.
  • Page 106 Removing and Replacing the Air Filter ARX®6000 Hardware Installation Guide...
  • Page 107 Copyrights Copyright (c) 1990, 1993, 1994, 1995 The Regents of the University of California. All rights reserved. Copyright 2000 by the Massachusetts Institute of Technology. All Rights Reserved. Export of this software from the United States of America may require a specific license from the United States Government.
  • Page 108 Copyright-2 ARX®6000 Hardware Installation Guide...
  • Page 109 Index baud rate connecting connector Adaptive Services Module features front panel LEDs 6-13 Air filter 6-14 installing replacing Diagnostics at switch bootup Audience for this manual Disk drives (fig.) configuration dual-channel bus , 3-6, LEDs locking down with key Bezel LUNs , 6-12, 7-3, Booting the switch...
  • Page 110 air filter , B-1, and static electricity disk drive Network protocols fan tray Network Services Module modules features power supply Operational status LEDs Hard disks in an ARX6000 Hardware Ports LEDs management, console LEDs NSM (fig.) disk drives POST diagnostics fan tray Power consumption module status and alert...
  • Page 111 Removing and replacing a disk drive Removing and replacing modules Removing fan tray Removing the power supply Resilient Overlay Network (RON) , 7-3, Running the boot wizard Safety instructions Serial console port Site installation requirements Slot assignments Specifications air filter airflow clearance chassis modules...
  • Page 112 ARX®6000 Hardware Installation Guide...
