Minicom DS Vision 3000 Quick Installation Manual

DS Vision 3000 Receiver and Receiver Long
This guide explains how to connect and mount the DS Vision 3000
1. The Receiver and Receiver Long ports
The figures below illustrates the Receiver and Receiver Long ports
2007 © Copyright Minicom Advanced Systems

Quick Installation Guide

Receiver / Receiver Long units.
SERIAL
To Serial device/
connection
Figure 1 Receiver and Receiver Long – side 1
System
cable
5VDC
SYSTEM
Power connector
Figure 2 Receiver – side 2
To speakers
L
L&R R
VIDEO
To screen
Tuning
adjuster
TUNING
1 5UM40169 AD1 V1
