Summary of Contents for B-Qtech BQ-D9004 series
-
Page 2: Table Of Contents
CONTENTS 2.1 Front Panel ................................1 2.1.1 4-CH Front Panel (Details please refer to the real product) ..............1 2.1.2 8-CH Front Panel (Details please refer to the real product) ..............1 2.2 Rear Panel .................................2 2.2.1 4-CH Rear Panel (Details please refer to the real product) ..............2 2.2.2 8-CH Rear Panel (Details please refer to the real product) ..............2 2.3 Remote Controller(Only for reference)......................3 3.1 Hard Disk Installation .............................5... - Page 3 Safety Instruction General safety Use proper power source. Do not operate this product from a power source that applies more than specified voltage (100-240V AC). Never insert anything metallic into the DVR case. Putting something into the DVR case can be a source of dangerous electronic shock. Do not operate in wet &...
-
Page 4: Dvr Features
Chapter 1: DVR Features Real time monitoring With virtual output, Support real time surveillance function via Monitor Recording saving Allow DVR to save real-time recording image to HDD Recording backup Support DVR backup function via U flash disk, removable disk and hard disk etc. Recording playback Support DVR single CH and multiple CH playback recording file Supports remote surveillance up to multiple users simultaneously with licensed... -
Page 5: Front Panel
Chapter 2: Layout 2.1 Front Panel 2.1.1 4-CH Front Panel (Details please refer to the real product) Key title/Indicator Functions Item Marks On/off Power supply Power Switch If the “Green” indicator is on, that means power supply is Power indicator normal Receive IR signal input IR Receiver... -
Page 6: Rear Panel
Power Switch PLAY: Play / Zoom in(out) PWR:PWR Indicator FWD: Forward / Iris HDD: HDD Indicator STOP: Stop key SEARCH: Recording Search REC: Manual Recording MUTE: Mute key MENU/ESC/LEFT: Menu / ESC / Left key CH- :Switch to previous CH UP: Up key CH+ :Switch to next CH SEL/EDIT/RIGHT: Select / Edit / Right key... -
Page 7: Remote Controller(Only For Reference)
4-CH: RS485/Sensor/Alarm ports 8-CH: RS485/Sensor/Alarm ports definition(from right to left)： definition(from right to left)： Pin 1-2：PTZ Control port Pin 1-2：PTZ Control port Pin 1：RS-485A Pin 1：RS-485A / Pin 2：RS-485B Pin 2：RS-485B Pin 3-4： Sensor 1 input Pin 3-4： Sensor 1 input Pin 4-5：... - Page 8 Mouse Operation You could proceed mouse operation, except of front panel and remote controller. On menu lock mode, Enter into pop-up menu and clicking any sub menu to pop up Log-in window; on menu unlock mode, enter into pop-up menu, and then clicking left key to enter into any sub menu directly.
-
Page 9: Hard Disk Installation
Chapter 3: DVR Installation 3.1 Hard Disk Installation Caution： Please do not take out hard-disk when DVR is running! (1) Open DVR upper cover carefully; (2) Insert Power Cord and data cable into Pin of hard-disk tightly; (3) Put the upper cover back carefully. 3.2 Camera and Monitor Connection Connect camera signal to video input of DVR, and video output of DVR to Monitor via BNC connector (Refer to section2.2-Rear Panel);... -
Page 10: Chapter 4: Dvr Boot Up
Chapter 4: DVR Boot up 4.1 System Initialization After connecting the power adapter and turning on the power button, the system will boot-up and start initializing. System will automatically detect mouse, initialize file system and recording parameters etc. Note： 1. All the pictures shown as user manual are provided only for your ref. -
Page 11: Pop-Up Menu
Chapter 5： DVR Menu Pop-up Menu After finishing system initialization, click right key of mouse on main interface mode to enter into Pop-up Menu. Now you could proceed parameter setting and control for Main Menu, Menu lock, Recording search, PZT control and recording etc. Picture 5-1 5.1 Main Menu Preview Camera... -
Page 12: Main Menu
5.2 Main Menu After clicking right key of mouse, pop-up menu will be prompted to screen. At this moment, you could click [main menu] button on pop-up menu to enter into Main menu interface (Shown as below picture 5.3). On Main Menu mode, you will be allowed to freely proceed device management setting, such as Camera, Recording, Network, Recording search, HDD, Alarm, PTZ Control, 3G Network... -
Page 13: Recording
5.2.2 Recording Click [Main Menu Recording] to enter into [Recording] menu (Shown as Picture 5-5) Explanation： 1. The [Esc] button allows you come back to previous menu or main interface. 2. Recording time indicates maximum continuous time length of recording file (15、30、45、60). Picture 5-5 The [Recording] menu allow you set up recording on/off status, also allows you setup recording details, image quality and audio on/off;... - Page 14 After selecting net mode - such as DHCP、PPPOE and manual allocation and setup web port, you could visit DVR remotely via network. Picture 5-7 When selecting DHCP, DHCP server will allocate DVR IP address automatically. When selecting PPPoE, you need to input user and password provided by ISP supplier and set up web port (details please refer to the below picture 5-8).
-
Page 15: Recording Search
If you need to visit DVR via External net, you should setup the inflection of video port at the public Router located in the DVR (shown as Picture 5-11). Host Port: 9000 Web Port: 8080 Intranet IP address of DVR: 192.168.1.101 Please map host port and web port into the IP address and input http://routerIP:8080 and confirm, then you visit your DVR freely. - Page 16 Picture 5-13 Page one：Indicates the first page of recording history which you have searched. When you preview other pages, clicking [Page one] button make you come back to Page one quickly. Previous page: When previewing event list, clicking [Previous page] button will make you come back to previous page of current page (except of first page).
-
Page 17: Device Management
Picture 5-15 When you select the log date and type you want to search and click [Start Search] button, now you will find the relative log recording. 5.2.5 Device Management Object of device management will include Hard disk, External Alarm, PTZ control, 3G network, Motion Detection etc. -
Page 18: Alarm Set
Picture 5-18 HDD Total Size: indicates HDD total saving size. HDD Usable space: indicates current HDD available saving space. Available recording time: As per current image detail/quality and frame rate, system will show to you how much time you could continue to record. Auto-overwrite: When selecting “on”, that means system will auto-overwrite previous recording once HDD if full;... - Page 19 Alarm processing：Alarm Output（10s,20s,40s,60s） 、Buzzer time (10s,20,40s,60s) and Post Recording Time （0s 、30s，1minute，2minute，5minute） 。 Alarm Type Function When DVR can’t receive video signal (such as camera damage, cable broken or Video Loss damage or power supply malfunction), alarm will be triggered. When an object moving to motion detection area, alarm will be triggered.
-
Page 20: Motion Detection
Picture 5-22 Picture 5-23 5.2.5.5 Motion Detection Click [Main Device Management Motion Detection] to enter into the [Motion Detection] menu for relative parameter setting. The [Motion detection] Menu have three parameter items, including Channel Status, Sensitivity and Motion area. Picture 5-24 Channel Status: The option allow you open or close any channel respectively. -
Page 21: System Function
5.2.6 System Function The [System] Menu include the below sub-menu: Time Set, User Password, Audio/Video Setting, Language select, System Info and System Maintenance. After entering into the [System] menu, you could set the parameters freely as per your actual situation. Picture 5-26 5.2.6.1 Time Set Click the [Main menu System Time set] in turn to... -
Page 22: Language Select
5.2.6.3 Audio/Video Set Click [Main Menu System Audio/Video Set] in turn to enter into Audio/Video Set, and user could start to set VGA solution （ 800*600、 600*480、 1024*768） and Camera system（PAL、NTSC） Picture 5-30 If you want to adjust volume, please click [Adjust volume] button to control volume size (shown as Picture 5-31). Picture 5-31 5.2.6.4 Language Select Enter into [Language Select] menu to select the language... -
Page 23: Menu Locking
5.3 Menu Locking In consideration of system safety, please click [Menu Lock] menu to lock system interface at once when leaving DVR. If you want to unlock the locking, please input device code and user password (refer to the below Menu Locking interface- Picture 5-35). Explanation: General User only has the authority of recording search, but Administrator has all the authority of Main Menu operation... -
Page 24: Chapter 6： Netviewer Program
Chapter 6： NetViewer Program 6.1 Widget download and installation Open IE browser and input IP address and web port of DVR, such as http://172.18.6.202:8080/ and confirm to download and install widget. If your computer is connected to internet, computer will auto download and install the widget. -
Page 25: Menu Column
Picture 6-3 6.3.1 Menu column Menu column include [Live Display] menu, [Playback] menu and [Setting] menu. 6.3.1.1 Live Display After Logging-in system, system will default to enter into Live display (shown as Picture 6-3). 6.3.1.2 Recording Playback The option allows you click the [Playback] button to playback recording history of DVR remotely. Firstly please select the day, channel and type and proceed searching and refreshing;... - Page 26 264 TO AVI button: allows you convert file format-264 to AVI format. Default format for backup file should be 264 format User could convert 264 format into familiar AVI format. 6.3.1.3. Setting Click [Setting] menu to enter into its sub menu, including [Recording Mode] menu, [Alarm Mode] menu, [PTZ Control] Menu, [Network Setting] menu, [System Setting] menu and [Host Info] menu.
- Page 27 Picture 6-7 System allows you proceed motion detection setting for single channel of DVR remotely (shown as Picture 6-8). Picture 6-8 ○ 3 PTZ Control Click [PTZ control] to proceed PTZ setting. Details setting methods are same as local DVR setting Please refer to Section 5.2.5.3 (shown as Picture 5-9).
-
Page 28: Ptz Control
Picture 6-10 ○ System Setting Click [System setting] menu to enter into the menu interface (shown as Picture 6-11); Pull down to select network connection mode and proceed the relative setting. Click […] button to preview net-viewer recording saving path and screen capture saving path. The menu also allows you set user password, on/off daylight-saving time etc. -
Page 29: Live Play Control
6.3.3 Live play Control ○ .On / Off Live display[ ]：When Live display is on the status of “On”, Clicking the button means you close Live display; on the contrary, When “Off”, means you have open the Live display. .Capture[ ]：Capture Screen image. -
Page 30: Troubleshooting
HDD Port Support SATA interface System PAL/NTSC Alarm I/O 4-CH alarm inputs, 1-CH alarm output PTZ Control RS-485 USB Port USB2.0 Ethernet RJ-45 10M/100M self-adaptable Ethernet interface Network Connection Support TCP/IP、DHCP、UDP、DDNS、PPPOE network connection Web Interface IE 6.0，IE 7.0 IR Remote Control Support IR remote control Power Adaptor DC 12V&5A... -
Page 31: Usage Maintenance
A: On the consideration of safety, you could not clear part of recording. You could clear all the recording files by formatting HDD. Q: Why I can’t log-in Net-viewer? A: Please check if Net mode is correct RJ-45 port is connected well Log-in user and password is right 10. -
Page 32: Accessory (Optional)
8.4 Accessory (Optional) Power Cord Power Adaptor User Manual CD Disk Remote Controller USB Cable... - Page 33 The material in this document is the intellectual property of our department . No part of this manual be reproduced, copied, translated, transmitted, or published in any form or by any means without our department prior written permission. Our products are under continual improvement and we reserve the right to make changes without noti ce.
