Summary of Contents for Sunsky GSM REMOTE CAMERA

  • Page 1: User Manual

    Shenzhen SUNSKY Technology Limited GSM REMOTE CAMERA User Manual...
  • Page 2 Shenzhen SUNSKY Technology Limited GSM Remote Camera Thank you for purchasing the GSM Remote Camera. The GSM remote camera is a remote images capturing device with a detect sensor, microphone, infrared lights and high quality camera. With the camera, you can capture images remotely and send them to your multimedia messaging (MMS) enabled mobile phone with a color display, or an e-mail address.

  • Page 3: Table Of Contents

    Shenzhen SUNSKY Technology Limited Contents For Your Safety......................... 5 Declaration of Conformity ....................... 5 Chapter 1 Product Features......................6 Product Accessories........................6 Chapter 2 Terms Explanation....................... 7 User Authorization Level: ......................7 Set defense/ Automatic alarm ....................8 Cancel defense.......................... 8 Emergency number........................
  • Page 4 Shenzhen SUNSKY Technology Limited 12. Infrared light........................22 13. Capturing images......................22 14. E-mail ..........................23 15. Automatic alarm ......................24 16. Emergency Alarm......................26 17. Image parameter setting ....................26 18. Network parameter setting....................28 19. Timing send MMS......................28 20.

  • Page 5: For Your Safety

    Shenzhen SUNSKY Technology Limited 1、The GSM SIM card for need to activate calling line presentation & MMS functions. 2、Be sure to remember and keep the product’s password, SIM card number secret. Don’t disclose to others to ensure your privacy safety.

  • Page 6: Chapter 1 Product Features

    Shenzhen SUNSKY Technology Limited made in relation to the accuracy, reliability or contents of this document. We reserve the right to revise this document or withdraw it at any time without prior notice. Chapter 1 Product Features This product use GSM SIM card. It can send MMS images to MMS supported mobile phone with a color display or to an e-mail address.

  • Page 7: Chapter 2 Terms Explanation

    Shenzhen SUNSKY Technology Limited 4. User manual 1 unit Chapter 2 Terms Explanation Any MMS enabled mobile phone can receive the image with password command. Any SMS supported mobile phone can control the remote camera with password command. Keep the product’s password and SIM number secret. Don’t disclose to others to ensure your privacy safety.

  • Page 8: Set Defense/ Automatic Alarm

    Shenzhen SUNSKY Technology Limited Receive alarm calling Get images by e-mail Receive SMS Emergency Receive MMS alarm YES (Only emergency Receive emergency calling number) Wire taping, require for single image Get work status, images, help and instruction by sending SMS command...

  • Page 9: Capture Images

    Shenzhen SUNSKY Technology Limited firstly, then dial other emergency numbers (the default alarm mode of the camera is dial phone number). Only master has the authority to set emergency numbers. The maximum emergency numbers (including master number) are 10. Capture Images Master/ family / guest send SMS to the camera to get the MMS image.

  • Page 10: Remote Control Instruction

    Shenzhen SUNSKY Technology Limited 4． Micphone 10. Hanging hole 5． Indicator 11. Setting key 6． Power switch 12. Base board Important suggest: Tear the camera protected membrane and keep the lens of the camera clean to assure best imaging quality.

  • Page 11: Installation

    Shenzhen SUNSKY Technology Limited Red & Two color lights Loading sensor Green alternately Note: Slow flash 1 time per second, quick flash 2 times per second. Installation 1、 Install the SIM card Remove the rubber cover from the left side of host.Open the SIM card slot by pressing the small dot beside the SIM card slot with the tip of a pencil, and pop-up the slot.

  • Page 12: Chapter 4 Quick Start

    Shenzhen SUNSKY Technology Limited GSM network signal strength may affect the image and live voice quality and MMS transmission speed, therefore, the camera should be located at the place where has strong network signal. After installation, try to take several images and send to mobile to check the image quality, Re-locate the remote camera and adjust the host’s angle to get best image.

  • Page 13: Active Remote Control

    Shenzhen SUNSKY Technology Limited 3. Active remote control When the green indicator lightened constantly or flashed, Press and hold the “Set” key at the rear board of the host for 2 seconds. The indicator change to flash with orange color indicated the camera switched to learning state.

  • Page 14: Listen In Live Voice

    Shenzhen SUNSKY Technology Limited For guest：#03#Password#image quantity# If the image size is 160×128 or 320×240, the maximum number of the images can be requested at one time is 8, the image quantity number should be set from 1 to 8. As the same, the number should be set between 1 to 2 if the image size is 640×480.

  • Page 15: Reset The Camera

    Shenzhen SUNSKY Technology Limited If you need detail instruction, send following SMS command to camera: For master and families：#09#1# For guest：#09#password#1# 10. Reset the camera This function reset all settings to their original values, it will clean all setting including. The setting values of master number, remote control, and wireless sensor will be erased too so you need to use this function carefully.

  • Page 16: Change Password

    Shenzhen SUNSKY Technology Limited When first time using or after resetting the remote camera, it is need to set the master number to activate the camera according following methods: Method 1: Call remote camera with your cell phone, it will notify you the number is busy now.

  • Page 17: Add Or Delete Emergency Number

    Shenzhen SUNSKY Technology Limited Add family number： (Authority: Master) To be a family member, the master sends following SMS to store the family member’s cell phone number into the camera. Maximum 10 family numbers can be stored. #06#Family number# Add several family numbers: #06#family number # family number#…...

  • Page 18: Remote Control Instruction

    Shenzhen SUNSKY Technology Limited #106#telephone number# Add several emergency numbers: #106#emergency number#emergency number#… After set successfully the camera will reply “The emergency number ******* has been successfully added.”. If the emergency numbers are full, it will reply “The Emergency numbers are full.

  • Page 19: Add Or Delete Remote Control

    Shenzhen SUNSKY Technology Limited When press Cancel Defense key, the camera indicator turn green and flash slowly, and the camera enter the state of cancel defense. In these statues, the camera can alarm only by pressing the Emergency key. A “Di…” tone can be heard from the camera by pressing any remote control key.

  • Page 20: Cancel Defense

    Shenzhen SUNSKY Technology Limited Default defense status: Infrared light turn on, send MMS when alarm, motion detection activated, MMS image quality is QVGA, send 5 images when alarm. Cancel defense (Authority: Master, Family) In cancel defense status, camera won’t make any alarm (Unless press the emergency key in the remote control).

  • Page 21: Motion Detection

    Shenzhen SUNSKY Technology Limited “Di…” tone and exit the loading status. 5） If the camera failed to load the sensor or no sensor exist, the indicator of the camera will flash with red and green alternately for about one minute, then the camera will exit the loading status automatically and back to the previous defense or cancel defense status.

  • Page 22: Infrared Light

    Shenzhen SUNSKY Technology Limited After successful set, it will reply “motion detection open” Motion detection sensitivity: #36#grade# (Note: grade can be 1, 2, 3, 4, 5. the larger the number, the stronger the sensitivity. The default value is 4. In grade 4, the camera can detect human body motion) After successfully set, it will reply: “Motion detection sensitivity set successfully.”, if wrong...

  • Page 23: E-Mail

    Shenzhen SUNSKY Technology Limited Capturing several images one time: If user needs several images, send following SMS command to camera: For master and families: #03#image quantity# For guest：#03#Password#image quantity# When the image size set 160×128 or 320×240, camera can only max send 8 images one time.

  • Page 24: Automatic Alarm

    Shenzhen SUNSKY Technology Limited After successful set, it will reply: “Email address ***** has been changed successfully.”. The e-mail address should be exact. Master and family can set one e-mail to one number. If more than one e-mail set for one number, only the last one can be recognized.
  • Page 25 Shenzhen SUNSKY Technology Limited When camera alarm, user can’t receive MMS, but only can receive a SMS “*** alarm, image quantity 5”. Send MMS when alarm (Default): #12#1# After successful set, camera will reply “Set alarm with MMS successfully”. User can receive MMS images when camera alarm.

  • Page 26: Emergency Alarm

    Shenzhen SUNSKY Technology Limited 16. Emergency Alarm (Authority: Master, Family) If emergent state happening, the camera can make emergency call when the user presses the Emergency key of the remote control. Two ways of emergency key alarm: dial emergency number (including master) and send SMS (MMS).
  • Page 27 Shenzhen SUNSKY Technology Limited Set Image brightness: Master or family send following SMS command to set five different brightness. #34#value# The value should be 1,2,3,4,5 (1 is darkest, 5 is brightest), default value is 4. After successful set, it will reply “Set image brightness successfully”. If wrong parameter, it will reply “Wrong parameter, please check and try again”.

  • Page 28: Network Parameter Setting

    Shenzhen SUNSKY Technology Limited Capture image Interval: Master or family send following SMS command: #103#time# Interval time value should be 3 to 10, the unit is 0.1 second. Default value is 5, it’s 0.5 second. After successful set, camera will reply “Set capture image interval successfully”.If parameter wrong, it will reply “Wrong parameter, please check and try again”.

  • Page 29: English And Spanish Version Switch

    Shenzhen SUNSKY Technology Limited Note: Each period time should set by start time, end time, interval. Max allow 3 periods. The value of work day, hour, minute as following: Work day: (one digit, 0-8) 0 means everyday; 8 means from Monday to Friday;...

  • Page 30: Check Status

    Shenzhen SUNSKY Technology Limited 21. Check status (Authority: Master, Family, Guest) User want to know the present setting and work status of camera, just need to send one of following SMS to camera, it will reply MMS including all settings (Not including the password.).

  • Page 31: Reset The Camera

    Shenzhen SUNSKY Technology Limited For master and families： #09# For guest： #09#password# Camera will reply two SMS including normal commands as following: Active equipment: #00# Set defense: #01#Password# Cancel defense: #02#password# Require image quantity: #03#password#quantity# Change password: #04#old password#new password#...

  • Page 32: Chapter 6 Maintenance

    Shenzhen SUNSKY Technology Limited After successful set, it will reply “The GSM camera have successfully reset to its default settings”. The remote control is needed to reload too. Password is required with the SMS command, otherwise, it will reply “You forgot including 4 digit password to reset camera”.

  • Page 33: Chapter 8 Main Technical Parameters

    Shenzhen SUNSKY Technology Limited SIM card no install Indicator constant Can’t find or identify properly: Power off the light in red color. the SIM card; camera and check it again. Camera didn’t Switch off the power, response of any Host work abnormally.

  • Page 34: Appendix: Sms Command List

    Shenzhen SUNSKY Technology Limited Work temperature -10℃～+45℃ Store temperature -20℃～+60℃ Relative Humidity 10-90%，without condensation Working band EGSM900、DCS1800 (GSM850、PCS1900 Optional) Communication protocols GSM PHASE 2/2+(including data operation) Wireless sensor receiving code Wireless sensor receiving band 433MHz or 315 MHz Max wireless sensor...
  • Page 35 Shenzhen SUNSKY Technology Limited User Function SMS Command number Refer to Chapter 5. Advanced operation, 4. Add or delete family number. #106#telephone number# Add emergency Refer to Chapter 5. Advanced operation, 5. Add or number delete emergency number. #107# Delete...
  • Page 36 Shenzhen SUNSKY Technology Limited User Function SMS Command Guest Refer to Chapter 4. Qucik Start, 6. capturing images, and Chapter 5. Advanced operation, 13 Capturing images. #03#image quantity#1# Send image to Refer to Chapter 5. Advanced operation, 13 Capturing e-mail images.
  • Page 37 Shenzhen SUNSKY Technology Limited User Function SMS Command No SMS when #11#0# alarm Send SMS when #11#1# alarm(default) No calling when #13#0# alarm (Default) Calling when #13#1# alarm Not send MMS to e-mail when #110#0# alarm (Default) Send MMS to...
  • Page 38 Shenzhen SUNSKY Technology Limited User Function SMS Command #116#work day#period1 start time#period1 end time#period1 interval##period2 start time#period2 Set timing period time#period interval##period3 start to send MMS time#period3 end time#period3 interval# period Refer to Chapter 5. Advanced operation, 19. Timing send MMS.
  • Page 39 Shenzhen SUNSKY Technology Limited User Function SMS Command parameter setting. #103#time# Interval time should be 3-10, unit is 0.1 second, and Interval of default value is 5. capture image Refer to Chapter 5. Advanced operation, 17. image parametre setting. Add or modify...
