Summary of Contents for Radiancy FSD+
-
Page 1: User Manual
Facial SkinCare Device User Manual... - Page 2 Fax: 32 (0) 2 732 6003, GSM 07545 4660, e-mail: mail@obelis.net Contact Information Customer satisfaction is a Radiancy priority. To help us in providing you with the best possible product and support, please send us your comments and suggestions. Contact us at the addresses and telephone numbers below: Israel Radiancy Inc.
-
Page 3: Table Of Contents
Table of Contents Introduction to FSD Plus � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4 Safety Instructions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5 Device Description �... -
Page 4: Introduction To Fsd Plus
With LHE MicroPhototherapy at its core, FSD Plus can be used either for stand-alone ® treatments or as a part of a more comprehensive skin care program� FSD Plus is based on Radiancy’s patented LHE Technology� LHE has been a ®... -
Page 5: Safety Instructions
2. Safety Instructions As with any electrical device, certain precautions must be taken in order to ensure your safety� READ ALL INSTRUCTIONS BEFORE USE� ALL WARNINGS AND CAUTIONS SHOULD BE STRICTLY FOLLOWED� WARNINGS - To reduce the risk of injury Use this device only for its intended use as described in this manual�... - Page 6 Cautions Do not apply to tanned skin� Cover birthmarks prior to treatment� Never look directly at the light coming from the handpiece as this may cause eye injury� Do not use this device on the eyelids or eye socket area� Always use protective eyewear�...
- Page 7 Contraindications Do not use this device if your client: Is skin type 6� Is pregnant or lactating� Was exposed to strong sunlight or an artificial tanning machine in the past 21 days� Has a tattoo or permanent makeup in the treatment area� Has used medications, herbal preparations, lotions or other chemicals that cause photosensitivity within the past 6 weeks�...
-
Page 8: Device Description
3. Device Description FSD Plus is made up of three main components; the main unit, the handpiece, and the power cord� Main Unit: Pulse Counter Control Panel On/Off Switch Hand Piece... -
Page 9: Control Panel
Control Panel: The control panel contains indicator lights for power, ready and charging� There is also a mute switch, and energy level settings for low, medium and high� Energy Levels Mute Button Ready Indicator Light Charging Indicator Light Power On Light Hand Piece: Accessories: Treatment Head... - Page 10 Device Set Up Use of accessories and cables other than those specified, with the exception of cables sold by the manufacturer as replacement parts for internal components, may result in increased emissions or decreased immunity of the device� Before you plug in the device, verify that the LUA lamp is correctly inserted into the handpiece�...
-
Page 11: Know Before You Start
4. Know Before You Start The Counter FSD Plus features a pulse counter window� This will help you to better plan your treatments and advise you when to replace the LUA lamp� Treatment Pulses (Treat): This line counts the amount of pulses per treatment� Reset the treatment counter by turning the unit off between clients�... -
Page 12: General Guidelines
General Guidelines FSD Plus can be used as a stand alone treatment, or may be combined with other skin care routines� While you should rely on your experience and expertise in this area, we recommend the following treatment regimen as to the best way to incorporate FSD Plus into a comprehensive skin care program�... -
Page 13: Important Notes
• Differences in skin type, biology and comfort levels usually dictate that you must initially treat at the lower energy level settings� After the first 1-2 treatment sessions, however, the skin generally becomes less sensitive, which will allow you to gradually increase the energy level during subsequent uses�... -
Page 14: Operating Instructions
Scheduling For optimal results, FSD Plus treatments should be performed twice a week for 4 to 5 weeks� Maintenance treatments can be performed once a month or as needed� 5. Operating Instructions Test Always test your client’s reaction to FSD Plus before beginning the actual treatment� Deliver 1-3 pulses in discreet areas and wait at least 24 hours (up to 48 hours for skin types 4-5) for any possible negative reactions�... - Page 15 Treatment Thoroughly cleanse and dry the skin� Apply a hygienic ring to the treatment head� You may reuse a hygienic ring for each client� Use a different hygienic ring for each client� Press the power switch found on the top of the device� When the Ready indicator lights up, start treatment�...
- Page 16 Press and hold the pulse switch to trigger a sequence of therapeutic light pulses� This sequence takes a few seconds, depending on the energy level setting (see specifications)� If during the pulse sequence the Light Unit Assembly feels too hot on the skin, remove it immediately and wait until the ready indicator lights up again�...
- Page 17 After covering the entire area, wait one to two minutes to allow the skin to cool down then repeat the procedure making sure to begin at the initial starting point with the handpiece held vertically� When treatment is complete, turn the device off by pressing the power switch� Notes: • Wait 5 minutes between two consecutive uses�...
-
Page 18: Maintenance
Post Treatment • Avoid sun exposure or protect skin with sunscreen throughout the treatment process and for at least for 3 weeks following the last use� • Use a moisturizing sunscreen (SPF 30 or higher) for at least 3 weeks after treatment� • Some device users may experience hyperpigmentation resulting from the treatment�... -
Page 19: Fuse Replacement
To insert or replace the LUA: Picture A Picture B Turn the device off and unplug the cord from the electrical outlet� Grasp the LUA by both ends and pull it out of the socket (Picture A)� Line up the holes in the socket with the metal and plastic posts in the LUA and push it gently into place (Picture B)�... -
Page 20: Troubleshooting
Wait until the ready indicator light turns on again, and only then replace the handpiece on the skin� • If any problem persists, contact FSD Plus service through Radiancy or your point of purchase� Radiancy is responsible for the effects on safety, reliability and performance of the... -
Page 21: Standards, Safety And Specifications
8. Standards, Safety and Specifications Design and technical specifications are subject to change without notice� International Standards FSD Plus complies with the following international standards and directives: Electrical Safety Medical Electrical Equipment – Part 1: General Requirements for Basic Safety and Essential Performance, 3rd Ed: IEC60601-1:2005/ EN60601-1:2006 Electromagnetic Compatibility IEC 60601-1-2:2007... - Page 22 Declaration of Electromagnetic Compatibility (EMC) FSD requires special precautions regarding EMC and needs to be installed and put into service according to the EMC information provided in the accompanying documents� FSD complies with international standards for: Electromagnetic Emissions Levels. FSD is intended for use in the electromagnetic environment specified below. The customer/user of FSD should assure that it is used in such an environment.
- Page 23 FSD complies with international standards for: Electromagnetic Immunity Levels (1). FSD is intended for use in the electromagnetic environment specified below; The customer or the user of FSD should assure that it is used in such an environment. Immunity test IEC 60601-1-2 Compliance level Electromagnetic Environment -...
- Page 24 FSD complies with international standards for: Electromagnetic Immunity Levels (2). FSD is intended for use in the electromagnetic environment specified below. The customer or the user of the FSD should assure that it is used in such an environment. Immunity test IEC 60601-1-2 Compliance level Electromagnetic Environment - Guidance Test level...
- Page 25 Recommended separation distances between: Portable and Mobile RF Communications Equipment and FSD FSD is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of t FSD can help prevent electromagnetic interference by maintaining a minimum distance between port able and m obi le RF communications equipment (transmitters)and the FSD as recommended below, according to the maximum out put power of t he communications equipment.
-
Page 26: Technical Specifications
Electrical Safety Degree of protection against ingress water: ordinary� This device is not suitable for use in the presence of flammable anesthetic mixture with air or with Oxygen or Nitrous Oxide� Technical Specifications Light Source: Pulsed light Technology: (Light and Heat Energy) ®... - Page 27 Operation Conditions 30ºC Temperature 5ºC 80%RH Humidity 30%RH Transport & Storage 80ºC Temperature -20ºC 95%RH Humidity 0%RH 1.5 atm Atmospheric Pressure 0.1 atm...
- Page 28 Labels This section describes the labels affixed to the FSD Plus� It is recommended that users review the meaning of these labels for everyday usage and in case any details are needed for service� The table below briefly reviews a number of internationally recognized symbols that are found on the FSD Plus main unit and its external package�...
- Page 29 In addition, these stickers are found on the main unit and LUA’s� These include serial numbers of the system parts and some usage warnings� Label Location Located at the bottom of the system, this label includes manufacturer’s details, voltage information and the system’s serial number. Located on the rear pane, above the power inlet.
-
Page 30: Service Information
9. Service Information In case you need service, contact Radiancy� Do not attempt to service the unit yourself� This will void your warranty� Radiancy Inc. Radiancy Israel Ltd. 40 Ramland Road South, Suite 10 5 Hanagar Street Orangeburg, NY 10962, USA... - Page 31 FSD Plus - Facial SkinCare Device Warranty Card: User Information: System Details: Name: Serial Number: Street: Purchase Date: City: Comments: State/Province: Country: Zip Code: Tel: Fax: Mobile: E-mail: Was the system received without visible external damage? No� Please describe: Did the system operate properly immediately after installation? No�...
- Page 32 Smart Skin Solutions...
