Page 1: Table Of Contents
Owner’s Manual Table of Contents Welcome/Records Specifications/Warnings Product Introduction Three Technologies Diagrams Setup Operations Dissassembly/Assembly 10-11 Cleaning Troubleshooting... -
Page 2: Welcome/Records
The combination of three innovative technologies, Photo Catalytic Oxidation (PCO), Needlepoint Ionization, and Scalable Purification, sets the Triad Aer apart from similar air purifiers on the market. The Triad Aer uses these technologies to reduce particles and inactivate microbes in the output radius creating a healthier living space with pristine air quality. -
Page 3: Specifications/Warnings
Specifications/Warnings Specifications Unit Size: 12” high x 9” wide x 10 3/4” deep Weight: 8.8 lb. Coverage: 250ft² to 3000ft² (23m² to 279m²) * * Depending on variables such as the severity and frequency of pollution, flow of air in the environment, humidity and temperature. Input: 120V/60Hz .63A PCO Cell Normal Mode Output: <... -
Page 4: Product Introduction
The whisper quiet five-speed fan disguises the power encapsulated in the advanced air purification system. Having the Triad Aer in your space will not only improve the quality of air, but, most importantly, it will improve the quality of life. -
Page 5: Three Technologies
Unlike HEPA filters that can only filter out particles of .5 microns or larger, the ionizer in the Triad Aer can reduce ultra-fine, even nano particles, that are much more dangerous than the larger particles you can actually see. -
Page 6: Diagrams
Unit Rear Control Panel Power Adapter Inlet Unit Front Rear of Unit Rear of Unit (Rear Cover Removed) (Filter Assembly Removed) Brass Thumbscrews PCO Cell PCO Cell Nuts Filter Assembly PCO Cell Connector Purification Plate ©Triad Aer 2012: All Rights Reserved... -
Page 7: Diagrams
Diagrams (Controls) Remote Control Panel REMINDER POWER RESET RESET SANI+ BOOSTER PURIFIER SANI + BOOSTER PURIFIER POWER PURIFIER Power Button Power Button Fan Speed Control Fan Level Control Reminder Reset Button Purifier Level Control Sani + Booster Control Sani + Booster Level Sani + Booster Toggle Purification Level Control Infrared Receiver... -
Page 8: Setup
• Place the unit on top of something tall such as a bookcase, a shelf or a mounting bracket, leaving only 12 to 24 inches between the unit and the ceiling. • To ensure the unit works properly, there should be as much space as possible in front of your Triad Aer so that it can efficiently process the air in the area. -
Page 9: Operations
Operations Operating the Unit LCD Reminders Turning the Unit On/Off Replace Plate Press the Power Button on the Control Panel or Remote When “Replace Plate” appears, the Purification Plate has to turn the unit on. The unit will initially be set to reached the end of its useful life and must be replaced. -
Page 10: Dissassembly/Assembly
2. Grasp the top of the Filter Assembly and tilt away from the unit. Clean if necessary (see “CLEANING: Filter Assembly” page 12) and set the Filter Assembly aside. ©Triad Aer 2012: All Rights Reserved... - Page 11 Assembly Tools Required 2. Insert the bottom of the Filter Assembly into You will need a #2 Phillips screwdriver. the tabs on the rear of the unit and then seat the Filter Assembly on the rear of the unit. (NOTE: Installing the PCO CELL: If the user fails to insert the Filter Assembly 1.
-
Page 12: Cleaning
Cleaning the Unit (Interior) Using a damp cloth, a clear alcohol-based cleaner, compressed air or a vacuum cleaner, carefully clean the walls and components inside of the unit only after completing the Disassembly procedures. ©Triad Aer 2012: All Rights Reserved... -
Page 13: Troubleshooting
Outlet (see “DISASSEMBLY/ASSEMBLY” pages 10-11). 2. If the PCO still fails to operate, it needs to be replaced. Contact your Triad Aer distributor. The Ionization Needle Creates an Electrical Arc: The Ionization Needle needs to be cleaned (see “CLEANING: Ionization Needle” page 12). Be sure to complete all of the cleaning procedures (see “CLEANING”... - Page 14 Notes ©Triad Aer 2012: All Rights Reserved...
- Page 15 Notes...
- Page 16 Copyright © Triad Aer - Triad Aer OM v1 (120118)
