AIDETEK VC99+ User Manual

User's manual for VC99+ 3 6/7 DMM
1.SUMMARY
This AIDETEK VC99+ multimeter is a steady
performance, battery-driven 3 6/7 digital multimeter. It uses
the LCD with 23mm-high figure to make the reading clear
and make operation more convenient.
The digital multimeter has the function of measuring DCV,
ACV, DCA, ACA, resistance, capacitance, frequency,
temperature, duty cycle, transistor and diode, continuity
performance test .The meter can provide functions including
analog bar and unit symbol display, data holding, relative
value measuring, maximal/minimal
auto/manual range switching (RANGE), auto power off and
warning functions .it adopts double integral A/D converter as
its core. It is an ideal tool for labs, factories and
radio-technology.
2.SAFTY NOTES ： ： ： ：
The instrument is designed according to IEC1010
standard (safety standard issued by International Electro
technical Committee). Please read the following before
operation.
1-1.Check the connection and insulation of test leads to avoid
electric shock.
1-2.Do not input a limited voltage higher than DC 1000V or
AC 750V when measuring ranges.
1-3.When measuring voltage higher than DC 60V, AC 40V,
please be careful.
1-4. Select correct function and range to avoid fault operation.
1-5.Please move the test leads away from test points when
switching the function.
1-6.Please don't input voltage value when measuring current.
1-7.Please don't modify the circuit.
1-8.Introduction for safety symbol:
" " exists high voltage; "
" " must refer to manual "
3. SPECIFICATION
1. General features
1-1. Displaying: LCD;
1-2.Max display: 6000(3 6/7) digits automatic polarity, unit
symbol and 61 section analog display;
value measuring,
1-3. Measurement method: double integral A/D conversion;
1-4. Sampling rate: approx.3 times/sec.
1-5. Over-range display: "OL" displayed in the highest digit.
1-6. Low battery display
1-7. Working environment: (0
<80%;
1-8.Store environment: (-10
<80%;
1-9.Power supply
1-10. Dimension: 185×93×35mm (length*width*height);
1-11. Weight: approx..290g
1-12.Accessories: test leads, user manual, temperature probe,
holster, gift box, and 2*1.5V battery.
2. TECHNICAL FEATURES
2-1. Accuracy: ± (a% × reading data + digits), environment
temperature at (23±5)
guarantee since production date.
2-2.DC Voltage
Range
" GND " " dual insulation
" Low battery.
： " "
～ 4 0) ℃ , relative humidity:
～ 40) ℃ , relative humidity:
： 2 pcs 1.5V battery （ " AAA"7# battery
（ ( including battery) ；
℃ , relative humidity<75%, One year
（ D CV ）
Accuracy Resolution
600mV
6V
±(0.5%+3)
60V
600V
1000V ±(0.8%+3)
Input impedance: approx. 10M
：
Overload protection 1 000V DC or 750V AC.
2-3.AC Voltage （ A CV ）
Range Accuracy
6V
60V ±(0.8%+5)
600V
750V ±(1.0%+5)
Input impedance: approx. 10M
Overload protection ： 1 000V DC or 750V AC.
Frequency response: （ 4 0 ～
range:(40 ～ 4 00 ） H z.
Sine wave RMS(Average value response).
2-4.DC Current （ D CA ）
Range Accuracy
600uA
6000uA
±(1.0%+3)
60mA
600mA
6A
±(2.0%+5)
20A
） ；
MAX measurement voltage drop:
A:100mV 。
Max input current: 20A (within 15 seconds)
Over load protection: 500mA/ 250V and 13A/250V
fast molten fuse.
（ ）
2-5.AC Current A CA
Range Accuracy
600uA
6000uA
±(1.2%+5)
40mA
600mA
6A ±(2.0%+10)
0.1mV
1mV
10mV
100mV
1V
Resolution
1mV
10mV
100mV
1V
2 00 ） H z under 750V ,other
Resolution
0.1µA
1µA
10µA
100µA
1mA
10mA
： f ull range mA :300mV ，
Resolution
0.1µA
1µA
10µA
100µA
1mA
