- Page 1 UTRACK MVT600 User Guide Version 3.0 UTRACK® GPS Vehicle Tracker MVT600 User Guide Copyright © 2013 Extra Miles Solutions Pte Ltd. All rights reserved. - 1 -...
-
Page 2: Table Of Contents
7.1.8 Install Micro SD...........................- 21 - 7.1.9 Install RFID Reader (Wiegand Interface)...................- 21 - 7.2 Install GPS/GSM Antennas ..........................- 21 - 7.3 Mount the MVT600 unit ..........................- 22 - Copyright © 2013 Extra Miles Solutions Pte Ltd. All rights reserved. - 2 -... -
Page 3: Copyright And Disclaimer
In no event shall Extra Miles Solutions be liable for direct, indirect, special, incidental, or consequential damages (including but not limited to economic loss, personal injury, and loss of asset and property) arising out of the use or inability or illegality to use the product or documentation. -
Page 4: Specifications
GPS Chip Latest GPS SIRF-Star III chipset GPS Sensitivity -159dB Positioning 10 meters, 2D RMS Accuracy 3 Digital Input ( 1 positive triggering and 2 negative triggering) Copyright © 2013 Extra Miles Solutions Pte Ltd. All rights reserved. - 4 -... -
Page 5: Mvt600 And Accessories
2 cameras) show SMS) View GPS LED Mic./Speaker GSM LED GPS Antenna GSM Antenna USB Port Micro SD On/Off Power, I/O Handset Camera Camera RS232 RFID Reader Copyright © 2013 Extra Miles Solutions Pte Ltd. All rights reserved. - 5 -... -
Page 6: First Use
Flashing (1 second on and 2 seconds off) MVT600 has no GPS fix GSM LED (Green) A call is coming in / a call is being made Flashing ( every 0.1 second) Initializing Copyright © 2013 Extra Miles Solutions Pte Ltd. All rights reserved. - 6 -... -
Page 7: Track By Calling
82329&ie=UTF8&z=1 6&iwloc=addr&om=1 If your mobile cannot visit HTTP websites, input the latitude and longitude into Google Maps as the following picture shows to get the position: Copyright © 2013 Extra Miles Solutions Pte Ltd. All rights reserved. - 7 -... -
Page 8: Multiple Phone Numbers- A71
Example: 0000,A71,13811111111,13822222222,13833333333 SMS Get: 353358017784062,A71,OK 6.4.2 Listening-in (Voice Monitoring)–A72 Command: 0000, A72, phone number 1, phone number 2 SMS Get: IMEI, A72, OK Note: Copyright © 2013 Extra Miles Solutions Pte Ltd. All rights reserved. - 8 -... -
Page 9: Sleep Mode - A73
Out = 0, turn off the alarm when the tracker exits the waypoint; Out = 1, turn on the alarm when the tracker exits the waypoint. Copyright © 2013 Extra Miles Solutions Pte Ltd. All rights reserved. - 9 -... -
Page 10: Set Anti-Theft - B21
This part shows you the basics in how to use the Parameter Editor. Note: Don’t connect MVT600 to external battery when configuring. Please refer to the Parameter Editor User Guide for more detailed information regarding configuration and functions. Copyright © 2013 Extra Miles Solutions Pte Ltd. All rights reserved. - 10 -... - Page 11 Note: Remember this Com number. It needs to be input into the Parameter Editor. It is COM3 in this example and it would be COM4 or COM5… in your computer. Run ‘Parameter Editor .exe’ and the following configuration window will pop up: Copyright © 2013 Extra Miles Solutions Pte Ltd. All rights reserved. - 11 -...
-
Page 12: Sms Tracking
Set time interval for SMS location report. = 0, stop tracking by time interval (default); = [1,65535], track by interval in minute. Auto Report T imes = 0, unlimited times for report. Copyright © 2013 Extra Miles Solutions Pte Ltd. All rights reserved. - 12 -... - Page 13 II GPRS Tracking. Other events description, please refer to below chart. Read Read current tracker’ s settings for above items. Write Write above settings to the tracker . Copyright © 2013 Extra Miles Solutions Pte Ltd. All rights reserved. - 13 -...
- Page 14 Make a call to authorized phone number when press input 1 (SOS). Press Input 2 to call Make a call to authorized phone number when press input 2. Copyright © 2013 Extra Miles Solutions Pte Ltd. All rights reserved. - 14 -...
-
Page 15: Gprs Tracking
Max time interval = 65535*10 seconds GPRS Report T imes = 0, report without limit. = [1,65535], set report times, MVT600 will stop reporting when reaching Copyright © 2013 Extra Miles Solutions Pte Ltd. All rights reserved. - 15 -... - Page 16 Sleep mode can be changed on tap III Main Settings. GPS Antenna Cut Alarm when the GPS antenna is disconnected or cut Device Reboot Report when MV600 is rebooting. Copyright © 2013 Extra Miles Solutions Pte Ltd. All rights reserved. - 16 -...
-
Page 17: Installation
Output1. It can be used to connect with relay for engine immobilization. Low voltage (0V) when effective and open drain when ineffective. Output open drain sink voltage (ineffective): 45V max. Copyright © 2013 Extra Miles Solutions Pte Ltd. All rights reserved. - 17 -... -
Page 18: Power/Gnd (Pin1 /Pin2)
Connect GND (-Black) and Power (+Red) wires to the battery of vehicle. 7.1.2 Digital Input (PIN4 / 5, negative triggering) 7.1.3 Digital Input (PIN3, positive triggering) Copyright © 2013 Extra Miles Solutions Pte Ltd. All rights reserved. - 18 -... -
Page 19: Output
* 100% 4096 X 2 – 1.1*AD value The value must be converted into decimal, for example, 0x0313 is 787 in decimal, the results is 11.82%. Copyright © 2013 Extra Miles Solutions Pte Ltd. All rights reserved. - 19 -... -
Page 20: Install Handset Phone (Rs232 Interface)
UTRACK MVT600 User Guide Version 3.0 7.1.6 Install Handset Phone (RS232 Interface) PIN Number Color Description Power Output. Output Voltage: 5V Black Ground White Handset Phone RS232 TX (MVT600 RX) Yellow Handset Phone RS232 RX (MVT600 TX) Orange Microphone Positive... -
Page 21: Install Micro Sd
UTRACK MVT600 User Guide Version 3.0 GPS RS232 Data Interface PIN Number Color(Suggested) Description Power Output. Output Voltage: 5V Black Ground Yellow RS232 Interface TX (MVT600 RX) Green RS232 Interface RX (MVT600 TX) Note: Micro SD is required for taking photos. -
Page 22: Mount The Mvt600 Unit
If mounting required, there are 4 screw holes on the MVT600, 2 along either side that act as fixing points to the vehicle Please do not hesitate to email us at support@extramiles.asia if you have any questions. Copyright © 2013 Extra Miles Solutions Pte Ltd. All rights reserved. - 22 -...
