PCE122 HDMI Over Single Coaxial Splitter/Extender User Guide WWW.AAVARA.COM AAVARA INNOVATION CORP. ALL RIGHTS RESERVED Rev 1.0... - Page 2 TABLE OF CONTENTS Chapter 1............. 3 Introduction ............3 1.1 F eatures ............3 1.2 C ontent of Package ........3 1.3 Technical Specifications......... 4 Chapter 2............. 5 Installation ............5 ...
- Page 3 Coaxial cable is very suitable for both in-door and out-door deploy, plus PCE122 ultra long distance ultra high video quality transmission makes PCE122 the perfect solution for signage and residential AV application. The PCE122 also boasts built-in 1 to 2 Coaxial Splitter in Sender and One Coaxial Cascade output in Receiver which brings greater flexibility as it supports up to 5 layers Cascadable across 600M 1080p video with 7.1 channel...
- Page 4 1.3 Technical Specifications Sender Receiver Item Name PCE122-S PCE122-R Input Connector HDMI Type A x 1 Coaxial BNC x 1 Output Connector Coaxial BNC x 2 (1 to 2 Splitter) HDMI Type A x 1 Coaxial BNC x 1 (Cascade Out) Video Bandwidth 2.97Gb/s data rates...
- Page 5 Connect HDMI cable between HDMI output port of video source and HDMI input port of PCE122 Sender. Connect one 75 Ohm RG6U Coax cable between Coax 1 or Coax 2 output port of PCE122 Sender and Coax in input port of PCE122 Receiver.
