DXS-8 Matrix switch
applies to DXS-44, DXS-48, DXS84 and DXS-8
Installation instructions & technical manual
Congratulations! You purchased a powerful DVI digital matrix switch, capabable of switching up to 8 DVI signal
sources to up to 8 displaying devices like beamers, LCD monitors or other displaying units.
This manual will describe the installation procedure and give operating instructions. The explanations will help
you to understand the usage of the unit and give you all necessary informations to combine the DSX matrices
Please read this manual carefully. It will contain necessary information you will need for
safe and secure operation of the unit!
©2008 SPATZ All rights reserved.
with your existing environment.
Advertisement
Table of Contents
Summary of Contents for Spatz DXS-8
- Page 1 DXS-8 Matrix switch applies to DXS-44, DXS-48, DXS84 and DXS-8 Installation instructions & technical manual Congratulations! You purchased a powerful DVI digital matrix switch, capabable of switching up to 8 DVI signal sources to up to 8 displaying devices like beamers, LCD monitors or other displaying units.
-
Page 2: Table Of Contents
OVERVIEW ABOUT FEATURES ......................4 SETUP AND CABELING INSTRUCTIONS ..................5 ............................5 NPACKING ............................ 5 ACKING LIST ..................... 5 PERATION LOCATION REQUIREMENTS ......................... 5 ETUP AND MOUNTING ........................5 LECTRICAL CONNECTIONS 2.5.1 mains connection ........................5 2.5.2 Attaching DVI video sources ..................... 6 2.5.3 Attaching DVI displaying devices .................... - Page 3 TECHNICAL MANUAL ........................24 ..........................24 ROUTING EDID ..........................24 HANDLING ........................26 ABELS AND YMBOLS 7.3.1 Markings on the faceplates ..................... 26 TECHNICAL DATA ......................... 28 DXS-XX ............................28 8.1.1 Mechanical data........................28 8.1.2 Electrical data ........................28 8.1.3 Approvals ..........................
-
Page 4: Overview About Features
1 Overview about features DXS-XX is a pure digital crosspoint switch (resp. matrix switch) for digital DVI video signals. It simultaniously connects up to eight DVI sources to up to eight displaying devices. For each video source, you can either use a “point-to-point”... -
Page 5: Setup And Cabeling Instructions
2 Setup and cabeling instructions 2.1 Unpacking Please take DXS-XX out of the shipping box, take away plastic shock protection and transportation bag. Strip of front panel protection tape, starting at one corner of the front panel. Unpack power cord and all other material supplied with the shipment, and keep it ready for use. -
Page 6: Attaching Dvi Video Sources
2.5.2 Attaching DVI video sources Next step in setup procedure is attaching video sources. To avoid damages is DXS-XX and your existing video sources, all connections between com- ponents are to be done when ALL units are powered off. Now ensure that you have powered off all video sources and the DXS-XX. -
Page 8: Checking Your Cabeling
2.5.6 Checking your cabeling After doing all connections, you overall system (containing the DXS-XX) should look like this: Figure 2: DXS-XX cabeling... -
Page 9: Operating Instructions
3 Operating instructions 3.1 Powering on/off, Standby-operation When DXS-XX is connected to a hot wall socket, it will start and boot automatically. All button LEDs will flash for a short period of time and the text display will show a short welcome message (from the bootloader). After that, the unit trys to reach a TCP/IP network (if cable connected). -
Page 10: Save And Recall Of Presets
turn off the LED. The text diplay will show a minus sign under the selected output number, to show the “off”- connection. 3.4 Save and recall of presets You can save or recall a routing setup any time you like. By saving a preset, you can preserve a complex setup for later use. -
Page 11: Menu Functions
3.5 Menu functions 3.5.1 Menu system Using the built in menu system, more complex system functions are available. To handle the menu system, you have to use the four cursor buttons (arrows up, down, left, right) and the “en- ter” button, located right of the “right” cursor button. With those buttons, you can navigate through a menu tree, to access more complex system functions. -
Page 12: Menu Tree
3.5.2 Menu tree DXS-XX MAIN MENU Routing Leads back to the switching matrix Presets Load Recalls / Loads a saved preset from a bank Save Saves a preset to a preset bank Clear Clears a single preset bank Clear ALL clears ALL preset banks (after promt message) DDC/EDID Input Config Adjust EDID behaviour of an input... -
Page 13: Console And Telnet Access
3.6 Console and TELNET access 3.6.1 Introduction to Console/Telnet Console and Telnet connection to the unit is different in terms of electrical connectivity, but both access methods share the same command set and handling. For serial remote control, please use the serial cable shipped with the unit. The cable is to be connected to any available serial port (i.e. -
Page 14: Edid_Mode
the web interface of the unit, you can even assign a own name of the bank, but this is not avalable via Console or Telnet. 3.6.2.3 edid_mode Format 1: edid_mode Displays the behavoir of EDID/DDC for each input. This is a typical printout (factory setup): IN: 1 2 3 4 5 6 7 8 DDCM:S S S S S S S S When reading the example, the first row will list all inputs available at the unit and the second row will show a... -
Page 15: Edid_Write
This is a typical printout: >edid_read 11 Reading internal DDC from input #1 0000: 00 ff ff ff ff ff ff 00 08 ed 10 01 00 00 00 00 0010: 25 11 01 03 80 00 00 00 6d ee 91 a3 54 4c 99 26 0020: 0f 50 54 af cf 00 61 59 71 4f 81 80 81 40 31 59 0030: 45 59 a9 40 01 01 48 3f 40 30 62 b0 32 40 40 c0 0040: 13 00 67 1f 11 00 00 1e 00 00 00 fd 00 32 78 1e... -
Page 16: Exit
3.6.2.6 exit Format: exit Quits the console application. For serial console, the user is logged off. For Telnet terminal session, the session is closed. To reconnect, you have to start a new telnet session again. 3.6.2.7 gettime Format: gettime Displays actual system’s clock time. 3.6.2.8 help Format 1: help Lists all commands available. -
Page 17: Ip_Setadr
3.6.2.10 ip_setadr Format: ip_setadr DHCP IPAdr Netmask Gateway Parameter: DHCP = [0..1] IPAdr = aaa.bbb.ccc.ddd Netmask = aaa.bbb.ccc.ddd Gateway = aaa.bbb.ccc.ddd Sets the parameters of IP network interface. Setting DHCP=1, you determine the unit to try to adress a DHCP server in your local network after boot/reset. If there is a DHCP server, and it is responding, the unit will assign the network configuration (reported by DHCP server) to it’s network interface. -
Page 18: Pre_Clear
PING#3, Reply from 10.0.1.2 :rtt < 50 ms PING#4, Reply from 10.0.1.2 :rtt < 50 ms Ping Stats: Sent:4 Recvd:4 Success:100% Avg RTT(Approx):0.00 sec You can use this command to test network connectivity. 3.6.2.12 pre_clear Format 1: pre_clear N Parameter: N = [1..8] Erase routing preset #N and free memory usage. -
Page 19: Reboot
Remark: The preset stored the last before system power down will be used as boot configuration after power reset. This means, that if you modify the routing AFTER the last “pre_save” command (or a similar menu/web command), you will loose your modifications after power down. 3.6.2.15 reboot Format: reboot Reboots the systeme immediately. -
Page 20: Sys_Addusr
3.6.2.18 sys_addusr Format: sys_addusr name password Parameter: name = user name, 15 characters max. password = passwort, 15 characters max. Adds a new user to user management. After successfull command execution (no message) the new user can connect to the unit using the new name and password. If entered name or password do not fullfill length and format reqirements, an error message is displayed. -
Page 21: Sys_Temp
3.6.2.21 sys_temp Format: sys_temp Displays system’s temeperature sensors readings. Unis are degrees Celsius. Example: >sys_temp Temp(0) = +37.875 Temp(1) = +28.000 Sensor 0 is located near main DVI procressor and in thermal contact with it. Sensor 1 is located near the unit’s internal power supply. -
Page 22: Webserver
3.7 Webserver The built-in webserver can be reached using any browser: http://(ip-adr) If DXS-XX is connected to a TCP/IP network, you can query the current IP adress using the menu tree unter: STATUS/ NETWORK STATUS/ IP Because DXS-XX uses “Javascript” as http extension, your browser must support Javascript. Manufacturer quali- fies current versions of Microsoft Internet Explorer, Opera and FireFox. -
Page 23: Safety Requirements
4 Safety requirements DXS-XX unit only may be operated on mains systems having power earth (PE) for grounding the system chassis. The power earth contact of the power cord never must be covered or de- stroyed when plugged to the unit or the mains outlet. 5 Electromagentic compatibility (EMC) DXS-XX was tested and qualified sucessfully according CENELEC EN 60601-1-2 (1993). -
Page 24: Technical Manual
7 Technical manual 7.1 DVI routing DXS-XX is build to route DVI video signals (and their implicit display info) from inputs to outputs. It approves DVI1.0 standard, having the maximum transfer rate of 1.65GBit/s on every video data differential line. With that, you can have video resolutions of up to 1920x1200 Pixels (at 60Hz repetition rate) on each of the inputs and outputs. - Page 25 respect to the input), the new EDID is copied to that input and the source will receive a hotplug event to read the new EDID data. If the input is unused (i.e. not routed to ANY output), then consequently there is no EDID available at that input, and the presence signal (hotplug) is removed for that input.
-
Page 26: Labels And Symbols
7.3 Labels and Symbols 7.3.1 Markings on the faceplates On DXS-XX’s fron faceplates you can read these symbols and buttons, this is the meaning: label meaning Arrow buttons: Navigate through menu functions. “up“, “down”, “left” and “right” Enter button Enter key, acceptance functionality in menu and value entry. (right of “right”... - Page 27 The rear faceplate has these labels: label meaning TCP/IP TCP/IP interface for control via ethernet 10/100MBit/s RS232 Serial interface for control of DXS-XX via RS-232 INPUT 1 ... INPUT 8 DVI input ports for up to 8 DVI video sources OUTPUT 1 ...
-
Page 28: Technical Data
8 Technical data 8.1 DXS-XX 8.1.1 Mechanical data Width 436 mm Depth 260 mm Height 44 mm (1HE) Weight Ca. 2400 g Colour Black (powdered) with white printing mounting orientation desktop horizontal on rubber stands rack mount 19-inch with additional brackets 8.1.2 Electrical data Supply voltage 100-240V AC, 47-63Hz... -
Page 29: Supported Input Signals
8.1.4 Supported input signals Video formats all DVI1.0 compliant Pixel rate 18-165 MPixel/s Supported video resolutions DOS (640x480@60Hz) up to WUXGA (1920x1200@60Hz) DDC standard EDID 1.3 8.1.5 “RS232” connector Connector DSUB 9 pin, female Protocol RS-232 compatible, 57600 Baud, 8N1, RXD/TXD-2-wire mode with XON/XOFF-Handshake Application User: remote control... -
Page 30: Environmental Conditions
8.2 Environmental conditions 8.2.1 Storage conditions DXS-XX and each of it’s parts can be stored following these conditions: Parameter Valid range Temperature 0°C to 65°C Relative Humidity 20% to 80% Air pressure 700hPa to 1060hPa 8.2.2 Operation confitions DXS-XX and each of it’s parts can be operated following these conditions: Parameter Valid range Temperature... -
Page 31: Bill Of Materials
9 Bill of materials DXS-XX is sold as a set/kit, containing these items: Quantity Part Part code DXS-XX unit (19-inch) power cord (IEC 320 to your local wall outlet), 2m serial cord, DSUB9 female to DSUB9 male, connected 1:1 19-inch mounting bracket set, constist- ing of two brackets and 8 screws (M4x5) rubber stickers (used as units stands)
