Kodak Picture Saver Scanning System Reference Manual

Cleaning the imaging area
Supplies and Accessories
CAT No. Description
148 4864 Kodak Feed Rollers
169 5097 Kodak Gentle Photo Separation Module
196 0426 Kodak Picture Saver Standard Separation
Module
853 5981 Kodak Roller Cleaning Pads
169 0783 Kodak Transport Cleaning Sheets
826 6488 Brillianze Detailer Wipes
119 9470 Kodak A4 Legal Flatbed Accessory
818 2271 Kodak A3 Flatbed Accessory
Indicator Lights and Error Codes
Code Message/Remedy
0 Check USB cable
Indicates that there is no USB connection or
the USB cable is not securely attached.
Power saver mode
No action required.
Scanning....
The scanner is scanning documents.
U5, E3 Rescan documents
USB cable has been disconnected while the
scanner was running.
U6 Clear paper path and close cover
Open the scanner cover and verify that all
documents are removed from the paper
path. Then close the scanner cover.
Multifeed
U8
• A multifeed document has been detected.
Clear the multifeed condition.
• The document you are trying to scan is too
long.
U9 Paper jam
Document jam or the paper path is blocked.
Clear the documents from the paper path.
E1, E2
• Be sure all cables are connected properly
• Turn power off and then on again. If the
problem persists, call Service
• Turn power off and then on again. If the
E2,
problem persists, call Service.
E4, E7
EASTMAN KODAK COMPANY
343 State Street
Rochester, New York 14650 U.S.A.
A-61636 / Part #5K1322 June, 2012
© Eastman Kodak Company, 2012
TM: Kodak
Picture Saver Scanning System
Reference Guide
Kodak Service & Support
www.kodak.com/go/disupport
1.800.822.1414
(US&C only; all other regions, contact your local
Kodak Support Center)
When contacting support, have the following available:
A description of your problem
•
Scanner model and serial number
•
Computer configuration
•
Software application you are using
•
