Elcomax Elux User Manual

Stb
Hide thumbs
Table of Contents

Advertisement

Quick Links

Table of Contents

Safety Precaution ........................................................................................................2
1.1 General Features ...................................................................................................3
1.2 Accessories ............................................................................................................4
2.1 Front Panel .............................................................................................................5
2.2 Rear Panel .............................................................................................................6
2.3 Remote Control Unit ...............................................................................................7
3.1 Connecting to Dish LNB and TV .............................................................................9
4.1 Installation..........................................................................................................10
4.2 Edit Channel........................................................................................................15
4.3 Setting ................................................................................................................17
4.4 Times..............................................................................................................19
4.5 Expansion.............................................................................................................20
4.6 Other Useful Information ......................................................................................21
5.1 Trouble Shooting..................................................................................................24
5.2 Technical Specifications.........................................................................25
5.3 Glossary ..............................................................................................................26
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Elux and is the answer not in the manual?

Questions and answers

Summary of Contents for Elcomax Elux

  • Page 1: Table Of Contents

    Table of Contents Safety Precaution ......................2 1. Reference 1.1 General Features ....................3 1.2 Accessories ......................4 2. Basic Function 2.1 Front Panel ......................5 2.2 Rear Panel ......................6 2.3 Remote Control Unit ....................7 3. Installation and Connection 3.1 Connecting to Dish LNB and TV ................9 4.

  • Page 2: Safety Precaution

    Safety Precaution This STB has been designed and manufactured to satisfy the international safety standards. Please read the following safety precautions carefully before operating this receiver. Main Supply: Before operating, please check the units operating voltage is 100~240V AC 50/60Hz. Overload: Do not overload a wall outlet, extension cord or adapter, neither use damaged power cord or touch it with wet hand as this may result in electric shock.

  • Page 3: Reference

    1. Reference 1.1 General Features DVB-S/DVB-S2 Satellite Compliant (MPEG-II/ MPEG-IV/ H.264). DiSEqC 1.0, 1.1, 1.2 & 1.3 (USALS) Compatible. SCPC & MCPC Receivable from C/Ku Band Satellites LNB Supported. Universal, Single, Single S & C Band Wide band LNB. Sensitive Tuner with Loop-Through. PAL / NTSC Conversion.

  • Page 4: Accessories

    1.2 Accessories Unpack the unit and check to make sure that all of the following accessories are included in the packaging. 1 x User manual 1 x Remote Control Unit (RCU) 2 x AAA Batteries 1 X HDMI CABLE...

  • Page 5: Basic Function

    2. Basic Function 2.1 Front Panel 1. Display (13 VFD) 13 digit VFD display, vacuum fluorescent display 2. Power Button The POWER button is used to turn the power on or to make it on Standby Mode. 3. CH Buttons Change channels or items from top to bottom on the menus.

  • Page 6: Rear Panel

    2.2 Rear Panel 1. LNB IN 13/18V 500mA Max Connect the Satellite Dish LNB. 2. LNB OUT Output the Dish LNB IN signal. 3. TV SCART Connect to TV set player with Scart cables. 4. VIDEO/AUDIO RCA output for CVBS format. 5.

  • Page 7: Remote Control Unit

    2.3 Remote Control Unit (RCU) You can control this receiver by this remote controller with full function. 1. POWER: Power on / off button, can set to Standby mode. 2. MUTE: Turn the sound On/Off. 3. SLEEP: Setting the time for turning the receiver off 4.
  • Page 8 14. EXIT: Exit current menu step by step. 15. AUDIO: Select or change the Audio. 16. ZOOM: To zoom out the current TV channel 17. PAUSE: To stop the current TV channel playing 18. PAGE+/-: Page up/down in menu or channel list 19.

  • Page 9: Installation And Connection

    3. Installation and Connection The following diagram shows you how to connect the HD receiver, TV, LNB and other equipment, please read this first if you are not sure about the connection, and it will guide you to the correct connection. 3.1 Connecting to Dish LNB and TV You can connect one fixed dish LNB directly to the LNB IN, or connect at least two dish LNB by DiSEqC Switch, you can also connect to HH mount...

  • Page 10: Installation And Operation

    4. Installation and Operation After connecting the receiver to other required equipment, turn on the receiver, there should be no channel information available at first. You need to follow the procedure to setup your receiver to search the channel. Main Menu Press MENU button to activate main menu, main menu consists of Installation, Service organization, Output, System, Timer, USB.
  • Page 11 Add satellite by using the Red key. Here you can input new Satellite angle, Satellite Direction (east, west), Band (ku,c). OK to confirm the setting and this new satellite will be added to the end of the Satellite list.  E dit Select the satellite then press green button.
  • Page 12 Transponder List If you change the satellite, the transponder will be changed automatically. You will find the transponder list of selected satellite here. Press the sat button can switch the TP and SAT list. In this menu Add, Edit, Delete, Transponder.
  • Page 13  　 Move Auto [W/E] Press RIGHT/LEFT button, the dish will be motorized to East/West continuously, it will stop until it find the best signal. 　 Move Continue Press RIGHT/LEFT button, the dish will be motorized to East/West continuously until you press LEFT/RIGHT again. 　...
  • Page 14 G: Start Search Channels After set above step, press ok you will be asked whether delete all exist channels if there are existing channels on selected satellites or TPs, you can choose yes or no, will start searching. During searching the TV Channel and Radio Channel will be listed separately.

  • Page 15: Edit Channel

    4.2 EDIT CHANNEL In this menu you can set program edit like delete, lock, rename, move and swap the selected channel, set FAV and so on.  T V Channels Here you can Select Channel, Delete Channel, Skip Channel, Move Channel, Lock Channel.
  • Page 16 Rename Select channel that you want rename from channel list, press F1 button, then using the UP/ DOWN /LEFT /RIGHT keys to select characters which you want to edit. Press OK to confirm your selection. In this menu, you can set the word with the extend. Caps on or off.

  • Page 17: Setting

    4.3 SETTINGS Here you can setup TV output and Video output according to the standard of your country. System Settings In this menu, you can choose MENU LANG, set AUDIO LANG, setting Digital Audio, menu transparency, transparence, Display MODE, TV Type, SCREEN MODE, SCART OUTPUT etc…...
  • Page 18 USALS Setup In this menu, you can set up USALS setting, and then you can use your DISH motor. CA MENU In this menu, insert the smart card, and you will get smart card info, and you can watch the scrambled channels.

  • Page 19: Times

    4.4 TIMES Time Settings In this MENU, you can change the TIME MODE and setting time manually, or adjust GMT time. The default time setup is auto, but you can select manual and input manually, select the time zone of your country and you will get the correct current time which is based on TDT (Time and Data Table) in the stream of the current channel service.

  • Page 20: Expansion

    4.5 EXPANSION Games Some classic games which will give your some happy times to play with !! Multi Pictures In this menu, user can watch 9 different small TV in one windows, we called it MULTI PICS USB ( Worked with a USB Device ) USB menu only working when a USB device is connected with your STB !! A.

  • Page 21: Other Useful Information

    B. Play Mode Press GREEN button, you will have Loop, and Slideshow Interval, and Photo view mode, to gain the viewing experience of your multimedia pleasure C. Upload Press YELLOW button, you will have upload function, and you can upload data to your USB or to your ftp.
  • Page 22 In this view, you can get the electronic program guide if applicable. You can get the detailed information about that program by pressing OK button Book You can Switch Pre/Next Day EPG by Pressing Red/Yellow Key. In this menu, Press Blue key go to Book.
  • Page 23 TXT: Show the teletext content teletext transmitted Subtitle Press SUB button to show subtitle.

  • Page 24: Additional Information

    5. Additional Information 5.1 Trouble Shooting You might meet abnormal working of this STB with various reasons. Check the following which may help you. Problem Possible causes What to do LED on the front panel fail Main supply cable is not Check if the main supply cable is plugged into the to light up/is not lit.

  • Page 25: Technical Specification

    5.2 Technical Specification Tuner & Demodulator Frequency Range 950 MHz to 2150 MHz Input Connector F-type, IEC 169-24, Female Signal Level -25 to -65 dBm RF Impedance 75Ω¸unbalanced IF Band width 55 MHz/8Hz(Per 5Msps) LNB Power & Vertical : +13 V, 14V +/-5% Polarization Horizontal : +18 V, 19V+/-5% Current : 500 mA Max.

  • Page 26: Glossary

    5.3 Glossary Antenna A device collects and radiates electromagnetic waves. Includes a satellite dish and broadband antenna. DiSEqC DiSEqC(Digital Satellite Equipment Control)system, it is a communication bus between satellite receivers and peripheral equipment using the only existing coaxial cable. The Digital Video Broadcast group was created to establish a technical framework for the introduction of digital video broadcasting systems.
  • Page 27 Forward Error Correction (FEC) A system of error control for data transmission. PID(Packet Identifier) A set of numbers that identifies transport stream packets containing data from a single data stream. Polarization Polarizations allows several programmers to be fit into the same frequency band.
  • Page 28 SCART A 21-pin connector used for connection of the receiver, VCR and TV. Also named Euro connector or Parietal connector. S/PDIF Sony/Philips Digital Interface Format. Digital audio output. Coaxial connector used to connect the receiver to an external amplifier.

This manual is also suitable for:

Elux x2
