1700 ALARM CONTROL SYSTEM SYSTEMS FITTED ENGLISH TEXT (LIQUID CRYSTAL) DISPLAYS OPERATING INSTRUCTIONS This information is relevant to systems fitted with Issue 2.6 (or later) System Software Castle Care-Tech Ltd. -
Page 2: Table Of Contents
1700 Alarm System (LCD) Operating Instructions Section Page 1. Introduction ........... . 1.1. -
Page 3: Introduction
Castle Care-Tech Ltd. Introduction The Care-Tech 1700 control unit has been designed and manufactured in England to provide the facilities necessary to form the heart of a sophisticated alarm system for the protection of persons and property. Many of the facilities are programmed by the installing company, who will be able to advise you on the availability of certain of the features referred to in this manual. -
Page 4: Using The System - Summary
1700 Alarm System (LCD) Operating Instructions USING THE SYSTEM - SUMMARY For full details, refer to Section 2. SETTING THE SYSTEM Enter your four digit code (eg 1234) and * to set the system to 'PART' set 'B' Enter your four digit code (eg 1234) and # to set the system to 'FULL' on OR use the keyswitch (if fitted) to select 'FULL' or 'PART B' on. -
Page 5: Terms Used
Castle Care-Tech Ltd. Terms Used Certain terms used to describe features and operation of the system may be unfamiliar, the principal ones are as follows: DAY MODE The 'normal' state of the alarm system whilst the premises are occupied, and the alarm switched 'OFF.' 'Personal Attack' facilities remain functional, and the system will continue to monitor itself for evidence of tampering. -
Page 6: The Display
1700 Alarm System (LCD) Operating Instructions TAMPER A fault existing in the wiring, or securing of the housing of part of the system, preventing normal operation. PERSONAL An alarm generated deliberately, to summon assistance if being ATTACK (PA) attacked, operative whether system is switched on or not. If remote signalling is fitted, the PA alarm may be silent. -
Page 7: The Keypad
Castle Care-Tech Ltd. The Keypad The 10 numeric keys are for entering your code for setting and unsetting the system, or entering other information when required. Four lettered keys (A,B,C,D) are provided to access additional functions. The # (YES) and * (NO) keys allow confirmation or cancelling of codes entered, also the choice of 'Full' or 'Part' setting the system. -
Page 8: Using The System
1700 Alarm System (LCD) Operating Instructions Using the System Setting the System 2.1.1 Setting the System with the Keypad Step Action Response Display Verify that all doors, etc. are closed, System and that 'd' is displayed Ready (* / #) Enter your 4-digit code, followed by # if Acceptance of code will be Leave by Exit... -
Page 9: Setting The System Using The Keyswitch (If Fitted)
Castle Care-Tech Ltd. 2.1.2 Setting the System using the Keyswitch (if fitted) Step Action Response Display Verify that all doors, etc. are closed, and System Ready that 'd' prompt is displayed (* / #) Insert your key and turn from the 'OFF'... -
Page 10: Unsetting The System
1700 Alarm System (LCD) Operating Instructions Unsetting the System NOTE: deviating from the prescribed ENTRY-EXIT route before switching the system off will cause an alarm. 2.3.1 Unsetting the system with the Keypad Step Action Response Display Enter building Intermittent tone will System Ready prescribed route only commence... -
Page 11: Unsetting Following An Alarm
"anticode" will show on the display. Quote this "anticode" - stating that your system has a 'Castle Care-Tech 1000 Series Panel' - and you will be given a special code to enter to free your system for use. This special code will be valid for one occasion only. - Page 12 1700 Alarm System (LCD) Operating Instructions Using the 'Chime' Facility You may switch part of the system to provide warning of an intruder in the building whilst it is occupied, without restricting your freedom of movement. Step Action Response Display Press A, followed by # Chime now active A musical note appears at the end of the second line...
-
Page 13: Additional Keypad Facilities
Castle Care-Tech Ltd. Additional Keypad Facilities Keypad Personal Attack Alarm If switching off the system under duress, it is possible to initiate a Personal Attack alarm by pressing the '3' and '9' keys simultaneously. This facility is available at all times. -
Page 14: System Faults
1700 Alarm System (LCD) Operating Instructions System Faults System Tamper Fault This indicates a fault in the wiring which requires attention by the alarm company. Mains Failure This indicates a break in the mains supply to the alarm control equipment. A battery back up supply is provided which should enable the system to continue functioning normally for a minimum of 8 hours. -
Page 15: Manager Functions
Castle Care-Tech Ltd. Manager Functions Accessing Manager Functions Step Action Display Ensure that the system is in normal mode System Ready Enter Manager Code (factory pre-set 2222) Manager Mode followed by # Enter Command The system is now in 'Manager mode' and provides... -
Page 16: Zone Selection
1700 Alarm System (LCD) Operating Instructions Zone Selection The zones on which 'Chime' monitoring is operative and on which Part Set 'C' functions may be adjusted as follows: 6.4.1 Chime Step Action Display Ensure that Manager prompt is showing Manager Mode Enter Command Enter 4, followed by zone number, and # - eg Zone 01... -
Page 17: Testing The System
Castle Care-Tech Ltd. Testing the System: 6.6.1 Walk Test This function enables you to test that all the detectors are working correctly, without generating an alarm. Step Action Response Display Ensure that 'Manager prompt' Manager Mode is showing. Enter Command... -
Page 18: Displaying System Logs
1700 Alarm System (LCD) Operating Instructions Displaying System Logs The system logs contain a history of events relevant to the operation and maintenance of the system, divided in to 'Alarm' events, 'Trouble' events and 'Activations'. These are stored in chronological order, and are displayed commencing with the most recent. Step Action Display... -
Page 19: An Alarm Or Trouble Record
The printer should NOT be left connected to the system when 'off line' or not in use. Note: Castle Care-Tech Ltd. reserve the right to change the specification of this system at any time in the interests of product improvement... - Page 20 1700 Alarm System (LCD) Operating Instructions THIS PAGE LEFT BLANK FOR NOTES January 2000 Page 19...
- Page 21 Castle Care-Tech Ltd. THIS PAGE LEFT BLANK FOR NOTES Page 20 Issue 3a...
- Page 22 Castle Care-Tech Ltd. INSTRUCT - 33...
