- Page 1 HT-900 SERIES HIGH THROUGHPUT ETHERNET BRIDGE Addendum to the FreeWave Manual V1.0h Firmware Release Version 7.60 FreeWave Technologies Inc. 1880 S Flatiron Ct. / Suite F Boulder, CO 80301 303-444-3862 LAD0013AB Rev H 1 of 11...
-
Page 2: Table Of Contents
FreeWave Technologies HT Ethernet Addendum 900MHz V1.0h Table of Contents: Description:............................3 Back Panel:............................4 Front Panel: ............................. 5 Setup: .............................. 6 Setup Menus ..........................6 Menu 1,............................. 6 Menu 1, Submenu F......................... 6 Menu 2,............................. 7 Menu 3 (for Point to Point) ....................... 7 Menu 3 (for Point to Multipoint) .................... -
Page 3: Description
HTP-900xx models of Ethernet radios. Please use this addendum in conjunction with the Main Manual. The Data Port in a FreeWave HT Ethernet Modem is a 10Base-T RJ45 connector, to be used as part of an Ethernet LAN (Local Area Network). -
Page 4: Back Panel
DIAG : 3-pin connector for diagnostics and programming of the radio. Diagnostic cable, part number ASC0409DC, is available from FreeWave. NORMAL/CROSSOVER: Switches the RJ45 connector from normal wiring to crossover wiring to avoid the need for a crossover cable. POWER: 2.1 mm coaxial power connector. -
Page 5: Front Panel
FreeWave Technologies HT Ethernet Addendum 900MHz V1.0h Front Panel: The modem has 2 rows of LED's. The bottom row of LED's is described in the Main Manual. The top row has 7 LED’s that indicate the state of the Ethernet Interface. -
Page 6: Setup
FreeWave Technologies HT Ethernet Addendum 900MHz V1.0h Setup: To program the modem, proceed as described in the Main Manual, with the following exceptions: • Capital U on the diagnostics port brings up the setup menu. • You must use the diagnostic port (there's no RS232 Data Port in this modem) •... -
Page 7: Menu 2
FreeWave Technologies HT Ethernet Addendum 900MHz V1.0h Menu 2, The Call Book is to be set as normal for Point to Point configurations. Network ID (Menu 5, option 6) is recommended for Point to Multipoint networks. Menu 3 (for Point to Point) -
Page 8: Errata For Firmware Versions
FreeWave Technologies HT Ethernet Addendum 900MHz V1.0h Errata for Firmware Versions The Following are known issues with Firmware version 2.54F: • Firmware version 2.54F is the first release of HT firmware that is field upgradeable. This firmware also supports over the air firmware upgrades. - Page 9 FreeWave Technologies HT Ethernet Addendum 900MHz V1.0h The following are known issues with Firmware version 2.58: Overall (Point to Point and Point to Multipoint) Functionality • Wideband mode is not operational. • Slave/Repeater is not supported. • Frequency Zones are not supported.
-
Page 10: Installation
Upon power up, the Ethernet interface’s MAC filtering table can become corrupted, and must be reset, or allowed to timeout. After power up, press the reset button on the back of the FreeWave Ethernet, or allow 4.5 minutes to pass and the table to reset. •... -
Page 11: Glossary Of Terms
HT Ethernet Addendum 900MHz V1.0h Glossary of Terms: Ethernet Modem: The entire FreeWave modem, which includes a Radio Modem and an Ethernet Interface. Ethernet Bridge: A bridge between two Ethernet LANs, using an Ethernet modem at each end. Radio Modem: The radio portion of the Ethernet Modem.
