  • Page 1 MSE PSE-SW5F Series Power Source Equipment (Power over Ethernet Switch) PSE-SW5F-ST PSE-SW5F-SC PSE-SW5F-SFP USER’S MANUAL MSTRONIC CO., LTD.
  • Page 2: Table Of Contents

    User’s Manual MSE PSE-SW5F-ST/-SC/-SFP 1. General Information.............. 2. Hardware Description............LED Indicators..................Power Wiring………………………………………………………………. Ethernet Port Wiring………………………………………………………. Fiber Port Wiring................... PD Port Wiring……………………………………………………………. 3.Model Information............4. Technical Specification............MSTRONIC CO., LTD.
  • Page 3: General Information

    User’s Manual MSE PSE-SW5F-ST/-SC/-SFP 1. General Information The PoE (Power Over Ethernet) Switch supports four Fast Ethernet ports with PoE injector plus one 100Base-FX up-link port. The switch provides Power over Ethernet functions to deliver 35Watts of power budget per port to a powered device(PD), which is in compliance with IEEE802.3af/at standard to deliver both Ethernet data and DC48V power through the traditional UTP or STP cable to a PD.
  • Page 4 User’s Manual MSE PSE-SW5F-ST/-SC/-SFP For PSE-SW5-SFP: LINK/ACT Link/Act Indicator Indicator *POWER Indicator STATUS Description Power Green LED ON if power input has valid power (PWR) apply. LED ON if the following condition happens. *Power input under voltage (Vin<10V) *Power input over voltage (Vin>59V) *PoE over current(2.5A/per port)
  • Page 5: Power Wiring

    User’s Manual MSE PSE-SW5F-ST/-SC/-SFP *SWITCH Indicator (the right LED of RJ-45) STATUS Description P1~P5 Green A network device is detected, but no Link/Act communication activity is detected. Blinking This port is transmitting to, or receiving @43ms package from another device at 100Mbps.
  • Page 6: Ethernet Port Wiring

    User’s Manual MSE PSE-SW5F-ST/-SC/-SFP For PoE (PSE) operation, the input voltage must be in the range of -42 to -60 VDC. Otherwise, the switch will function only as an Ethernet switch but will not provide any PoE power output. For PoE operation, make sure your 48 VDC supply is rated for at least 75 Watts for 4x 802.3af PoE port, or...
  • Page 7 User’s Manual MSE PSE-SW5F-ST/-SC/-SFP The following tables depict the wiring diagram of straight-through and crossover cabling. The crossover cables simply cross-connect the transmit lines at each end to the receive lines at the opposite end. Straight-through Cabling Pin 1 Pin 1...
  • Page 8: Fiber Port Wiring

    The maximum segment length is dependant upon the type of fiber optic transceiver installed in the switch. Refer to the technical specifications for details. Or contact a sales agent for the available fiber optic transceivers(Model NO.:MSE PSE-SW5F-ST or PSE-SW5F-SC or PSE-SW5F-SFP). The automatic MDI/MDI-X crossover function does not apply to fiber connections. To connect the fiber optic port on one switch to the fiber optic port of another switch, simply cross-connect the transmitter at each end to the receiver at the opposite end as illustrated in the figure below.
  • Page 9: Pd Port Wiring

    User’s Manual MSE PSE-SW5F-ST/-SC/-SFP *PD Port Wiring Port 1 to port 4 provides PoE inject functionality with a maximum 35W ability to power up the powered device using the straight-through or cross-over Ethernet cable. The PoE switch follows the IEEE802.3af Alternative B mode connector assignment. The following table shows pin assignments of alternative A and B for the Power Source Equipment.
  • Page 10: Model Information

    User’s Manual MSE PSE-SW5F-ST/-SC/-SFP 3. Model Information Model Input Voltage Output voltage 802.3af/at PSE-SW5F-ST-S PSE-SW5F-SC-S 10-57VDC 10-57VDC PSE-SW5F-SFP-S (non-regulated) (current mode) PSE-SW5F-ST24 PSE-SW5F-SC24 56VDC 12-36VDC PSE-SW5F-SFP24 (regulated) (24V-802.3at mode) PSE-SW5F-ST48 PSE-SW5F-SC48 40-57VDC 40-57VDC PSE-SW5F-SFP48 (non-regulated) (48V-802.3at mode) MSTRONIC CO., LTD.
  • Page 11: Technical Specification

    User’s Manual MSE PSE-SW5F-ST/-SC/-SFP 4. Technical Specifications Standards IEEE802.3/IEEE802.3u standards (10Base-T/100Base-T/100Base-FX) Ports 4 ports with 4 PoE(PSE), supports auto-crossover & auto-polarity, 1 port with the fiber connector Transmission speed 100Mbps(100Base-T), 10Mbps(10Base-T) Auto-negotiation Switch technology store-and-forward Protocols CSMA/CD Flow control IEEE802.3x(full-duplex),back pressure(half-duplex)
  • Page 12 User’s Manual MSE PSE-SW5F-ST/-SC/-SFP *Fiber max. distance 2km(mm),15km(sm) Note: Other fiber connector and transmission distance are available. PoE port Port 1-4, auto power management Pin assignment: TX(1,2), RX(3,6), V+(4,5), V-(7,8) Maximum PoE power Per port 35W PoE disconnect mode DC disconnect PoE auto detection IEEE802.3af/at...
