INSTALLATION INSTRUCTIONS
GALANT(09.5MY-)
Warning
!
This system is exclusively for automatic transmission vehicles. Never install this system on manual
transmission vehicles.
Thank you for purchasing the Mitsubishi Genuine Accessory.
To install and use the product correctly with proper knowledge of it, read this publication carefully.
Keep this publication for reference when maintenance is required.
- This publication gives precautionary instructions in the boxes titled as follows.
Read through these instructions thoroughly.
Warning
!
Caution
!
Note
- Failure to follow these instructions not only prevents the product from working properly but may lead to trouble
with the vehicle. Be sure to follow all instructions carefully.
- If there is anything unclear about the installation, handling and/or usage of the product, contact your Mitsubishi
Motors dealer for clarification.
- Mitsubishi Motors Corporation is not responsible for any defects or difficulties caused by or resulting from the
failure to follow given instructions.
- We recommend you to have the installation performed at an authorized Mitsubishi Motors dealer.
To the dealer:
Be sure that the customer receives this publication.
REMOTE ENGINE STARTER
MZ360360EX
Applicable Models
ECLIPSE/SPYDER(10MY-)
Attention
Describes precautions that should be observed in order to prevent serious injury or
death to the user.
Describes precautions that should be observed in order to prevent injury or damage
to the vehicle or its components, which may occur if sufficient care is not taken.
Provides additional information that facilitates installation work.
ENDEAVOR(09MY-)
ZZ100-00420-0
10, 8

Advertisement

loading

Summary of Contents for Mitsubishi MZ360360EX

  • Page 1 - Failure to follow these instructions not only prevents the product from working properly but may lead to trouble with the vehicle. Be sure to follow all instructions carefully. - If there is anything unclear about the installation, handling and/or usage of the product, contact your Mitsubishi Motors dealer for clarification.
  • Page 2 Note On GALANT without theft alarm system, the hood switch (Mitsubishi genuine part, sold separately) is also required. PRECAUTIONS - Be sure to apply the parking brake securely. Remove the ignition key from the key cylinder.
  • Page 3 Before installation When installing or removing parts - Be sure to disconnect the - Loosen or tighten bolts and - Use a Phillips screwdriver that - To remove plastic parts, use a negative terminal cable from nuts using tools that match their fits the recess in the head of the trim remover.
  • Page 4 QUICK SPLICE CONNECTOR Precautions for installing quick splice connector - Be careful not to damage the vehicle harness when cutting the vinyl tape wound around the harness to expose the wire to which the quick splice connector is to be installed. - When connecting a quick splice connector, confirm that a click is heard and also visually check that its two locks are engaged firmly.
  • Page 5 INSTALLATION PROCEDURES FOR ECLIPSE/SPYDER A. PREPARATORY WORK 1) Confirm that the ignition key is removed and all the electrical switches are off. Then disconnect the battery (–) cable from the battery. 2) Remove the following parts in accordance with the workshop manual.
  • Page 6 - 6 -...
  • Page 7 - 7 -...

  • Page 8: Installing The Antenna Unit

    C. INSTALLING THE ANTENNA UNIT 1) Cut the urethane sheet into the following dimensions. A: 35 x 140 mm (2 pieces) B: 70 x 20 mm (4 pieces) C: 70 x 70 mm (1 piece) B B B B D: 70 x 10 mm (1 piece) 2) Wrap the two pieces of urethane sheet A around the cable of the antenna unit 3) Pass the cable of the antenna unit...

  • Page 9: Ignition Switch

    D. CONNECTING THE HARNESS TO THE IGNITION SWITCH 1) Disconnect the 6-pin connector from the ignition switch and connect the 6-pin connector (female) of the harness to the ignition switch. 2) Fix the harness leading to the 6-pin connector (female) to the instrument panel harness near the branch to the disconnected 6-pin connector.

  • Page 10: Control Unit

    F. INSTALLING THE ELECTRONIC CONTROL UNIT 1) Apply the two pieces of double-sided adhesive tape and the urethane sheet B on the electronic control unit as shown in the drawing. 2) Wipe clean and degrease the installation position of the electronic control unit at the deck crossmember stay above the steering shaft using isopropyl alcohol or degreaser.
  • Page 11 G. ROUTING THE HARNESS AROUND THE ETACS-ECU 1) Connect the 1-pin connector (female) of the harness to the 1-pin connector of the front harness taped with the black tape on the front harness at the front of the ETACS-ECU. 2) Connect the three quick splice connectors of the harness to the wires from the gray and white 24-pin connectors connected to the ETACS-ECU...
  • Page 12 4) Disconnect the 3-pin connector of the instrument panel harness from the junction block. Draw out the No. 3 terminal from the connector and install the terminal with red/green wire of the harness that cavity. Reconnect the connector to the junction block.

  • Page 13: Combination Meter

    H. ROUTING THE HARNESS TO THE COMBINATION METER 1) Route the quick splice connector with white/black wire and the ground terminal of the harness the combination meter. 2) Connect the quick splice connector with white/black wire to the black/white wire from the No. 13 terminal of the 18-pin connector for combination meter.
  • Page 14 J. REGISTRATION AND OPERATION CHECK 1) Perform the registration and operation check in accordance with “REGISTRATION AND OPERATION CHECK PROCEDURES” (Page 37). Check K. REINSTALLATION 1) Reinstall the removed parts to the vehicle in accordance with the workshop manual. Caution Be careful not to pinch the harnesses or damage the parts.

  • Page 15: Preparatory Work

    INSTALLATION PROCEDURES FOR GALANT A. PREPARATORY WORK 1) Confirm that the ignition key is removed and all the electrical switches are off. Then disconnect the battery (–) cable from the battery. 2) Remove the following parts in accordance with the workshop manual.
  • Page 16 - 16 -...
  • Page 17 - 17 -...
  • Page 18 C. INSTALLING THE ANTENNA UNIT 1) Cut the urethane sheet into the following dimensions. A: 35 x 140 mm (2 pieces) B: 70 x 20 mm (4 pieces) C: 70 x 60 mm (1 piece) B B B B D: 70 x 10 mm (1 piece) 2) Wrap the two pieces of urethane sheet A around the cable of the antenna unit 3) Pass the cable of the antenna unit...
  • Page 19 D. CONNECTING THE HARNESS TO THE IGNITION SWITCH 1) Disconnect the 6-pin connector from the ignition switch and connect the 6-pin connector (female) of the harness to the ignition switch. 2) Fix the harness leading to the 6-pin connector (female) to the instrument panel harness near the branch to the disconnected 6-pin connector.
  • Page 20 F. INSTALLING THE ELECTRONIC CONTROL UNIT 1) Apply the two pieces of double-sided adhesive tape and the urethane sheet B on the electronic control unit as shown in the drawing. 2) Wipe clean and degrease the installation position of the electronic control unit at the deck crossmember stay above the steering shaft using isopropyl alcohol or degreaser.
  • Page 21 G. ROUTING THE HARNESS AROUND THE ETACS-ECU 1) Route the 1-pin connector (female) of the harness along the front harness and connect it to the 1-pin connector of the front harness which is taped with the black tape on the front harness. 2) Route the three quick splice connectors and the terminal with red/green wire of the harness along the instrument panel harness to the ETACS-ECU.
  • Page 22 4) Connect the quick splice connector with blue/red wire to the blue/red wire from the No. 18 terminal of the 24-pin white connector connected to the ETACS-ECU. 5a) On vehicles with theft alarm system, connect the quick splice connector with blue/white wire to the blue/white wire from the No.
  • Page 23 7) Disconnect the 3-pin connector of the instrument panel harness from the junction block. Draw out the No. 3 terminal from the connector and install the terminal with red/green wire of the harness that cavity. Reconnect the connector to the junction block.
  • Page 24 H. INSTALLING THE HOOD SWITCH (vehicles without theft alarm system) In order to install this system on a vehicle without the theft alarm system, the hood switch (sold separately) and the sub harness for hood switch must be installed. 1) Release the 2-pin connector (female) fixed with the black tape near the left headlamp in the engine compartment.
  • Page 25 I. ROUTING THE HARNESS TO THE COMBINATION METER 1) Route the quick splice connector with white/black wire and the ground terminal of the harness to the combination meter. 2) Connect the quick splice connector with white/black wire to the white/black wire from the No. 1 terminal of the 22-pin connector for combination meter.
  • Page 26 K. REGISTRATION AND OPERATION CHECK 1) Perform the registration and operation check in accordance with “REGISTRATION AND OPERATION CHECK PROCEDURES” (Page 37). Check L. REINSTALLATION 1) Reinstall the removed parts to the vehicle in accordance with the workshop manual. Caution Be careful not to pinch the harnesses or damage the parts.
  • Page 27 INSTALLATION PROCEDURES FOR ENDEAVOR A. PREPARATORY WORK 1) Confirm that the ignition key is removed and all the electrical switches are off. Then disconnect the battery (–) cable from the battery. 2) Remove the following parts in accordance with the workshop manual.
  • Page 28 - 28 -...
  • Page 29 - 29 -...
  • Page 30 C. INSTALLING THE ANTENNA UNIT 1) Cut the urethane sheet into the following dimensions. A: 35 x 140 mm (2 pieces) B: 70 x 20 mm (4 pieces) C: 70 x 60 mm (1 piece) D: 70 x 10 mm (1 piece) 2) Wrap the two pieces of urethane sheet A around the cable of the antenna unit 3) Pass the cable of the antenna unit...
  • Page 31 D. CONNECTING THE HARNESS TO THE IGNITION SWITCH 1) Disconnect the 6-pin connector from the ignition switch and connect the 6-pin connector (female) of the harness to the ignition switch. 2) Tilt the steering shaft to its uppermost position. Align the instrument panel harness with the rear end of the vinyl tube of the harness and secure them with the tie-wrap...
  • Page 32 F. INSTALLING THE ELECTRONIC CONTROL UNIT 1) Apply the two pieces of double-sided adhesive tape and the urethane sheet B on the electronic control unit as shown in the drawing. 2) Wipe clean and degrease the installation position of the electronic control unit at the deck crossmember stay above the steering shaft using isopropyl alcohol or degreaser.
  • Page 33 G. ROUTING THE HARNESS AROUND THE ETACS-ECU 1) Connect the 1-pin connector (female) of the harness to the 1-pin connector of the front harness taped with the black tape on the front harness at the front of the ETACS-ECU. 2) Route the three quick splice connectors and the terminal with red/green wire of the harness along the instrument panel harness toward the ETACS-ECU.
  • Page 34 4) Bundle the excess lengths of the wires and fix them to the instrument panel harness using the tie-wraps 5) Disconnect the 3-pin connector of the instrument panel harness from the junction block. Draw out the No. 3 terminal from the connector and install the terminal with red/green wire of the harness that cavity.
  • Page 35 H. ROUTING THE HARNESS TO THE correction: white/black COMBINATION METER 1) Route the quick splice connector with white/black wire and the ground terminal of the harness the combination meter. 2) Connect the quick splice connector with white/black wire to the black/white wire from the No. 1 terminal of the 22-pin connector for combination meter.
  • Page 36 J. REGISTRATION AND OPERATION CHECK 1) Perform the registration and operation check in accordance with “REGISTRATION AND OPERATION CHECK PROCEDURES” (Page 37). Check K. REINSTALLATION 1) Reinstall the removed parts to the vehicle in accordance with the workshop manual. Caution Be careful not to pinch the harnesses or damage the parts.
  • Page 37 REGISTRATION AND OPERATION CHECK PROCEDURES Caution Never perform the registration and operation check procedures simultaneously on some vehicles to prevent duplicated registration. (1) Operation check of remote controller Check Perform the operation check in the following procedure. Caution - The remote controller should be checked with the (-) terminal of the vehicle’s battery disconnected. - For how to install batteries, refer to the owner’s handbook.
  • Page 38 2) Perform the engine stop operation. Push Stop SW for 1 seconds or more. → Buzzer sounds, and Transmission, Stop Mark lights approx. 3 seconds. Go to Troubleshooting A. Beep (2) Registration of the remote controller Check Connect the (-) terminal of the vehicle's battery and perform the registration in the following procedure. Caution -The engine starter cannot function unless the remote controller is registered correctly.
  • Page 39 3) Within 10 seconds after the sound of the buzzer in the above step 2), push three switches (Function Switch, Start Switch, and Stop Switch) on the right side of the remote controller at the same time for 1 second or more. The buzzer of the remote controller sounds when pushing for 1 second or more, Faulty remote and the Start Mark and Stop Mark begin blinking.
  • Page 40 (3) Operation check Perform the operation check in the following procedure while referring to the owner's manual. Caution On ENDEAVOR models, make sure to set the interior light switch to "ROOM" position before proceeding. 1) Set the vehicle in the following conditions. - Set the shift lever in the "P"...
  • Page 41 Check 5) Failsafe function check Perform the engine start operation with a door opened. → The engine would not start. Go to Close all doors, insert the ignition key into the key cylinder, and perform Troubleshooting C. the engine start operation. → The engine would not start. Remove the ignition key from the key cylinder, open the hood, and perform the engine start operation.
  • Page 42 Circuit Diagram - 42 -...
  • Page 43 - 43 -...
  • Page 44 Troubleshooting <P.38 step (2)> - 44 -...
  • Page 45 <P.38 step (2)-3)> - 45 -...
  • Page 46 <P.41 step (3)-3)> - 46 -...
  • Page 47 <P.51 terminal No.3> <P.51 > - 47 -...
  • Page 48 <P.51 > <P.51 terminal No.13> - 48 -...
  • Page 49 <P.51 terminal No.18> <P.51 terminal No.24> - 49 -...
  • Page 50 - 50 -...
  • Page 51 Checking Harnesses Note The probes of the multimeter must be applied from the harness side of the connector. 1. Checking connector terminals Check that the battery voltage is 10 V or higher. Then, while referring to the circuit diagram, check each connector of the connector (13-pin, natural) and the connector (12-pin, black) connected to the ECU in accordance with...
