Description of Display Symbols
SYS
Indicates a measurement
within Stage 3 Hypertension.
DIA
SYS
Indicates a measurement
within Stage 2 Hypertension.
DIA
SYS
Indicates a measurement
within Stage 1 Hypertension.
DIA
Appears when batteries should be
replaced.
Troubleshooting
If any abnormalty occurs during use, please check and correct the following:
Condition
Display is blank when power is on.
Measurement incomplete or
abnormally low or high values
displayed.
EE symbol displays.
Measurements are different from
those typically measured by
physician or every measurement
reading is different.
Shows the pulse rate per minute.
Occurs when an error was made
during measurement.
Appears when there is an irregular
heartbeat detected during
measurement.
Appears when the cuff is unstable or it
has too much air left in it. Once the arrow
stops flashing, the unit is ready to take a
measurement.
Appears when the unit is ready or a
measurement error has occurred. Restart
the measurement if an error occurs.
Appears when recalling a
measurement from memory.
Correction
Check and correct the polarity of the installed
batteries. Reinstall or replace batteries.
Review and follow "Applying Your Blood
Pressure Cuff" and "Taking Your Blood Pressure
Reading" sections. Replace the batteries.
Do not talk or move during the measurement.
Review "Applying Your Blood Pressure
Cuff" section.
Remember, blood pressure readings are
influenced by physical and mental conditions
and/or even the time of day. Daily
measurements should be interpreted by your
physician.
16
Care and Maintenance
1. Disconnect the cuff tubing from the monitor and remove batteries prior to storing.
2. Only use a soft, dry cloth to clean your blood pressure monitor.
3. Avoid using any types of liquids on the monitor or cuff.
4. Do not store the unit where it will be exposed to direct sunlight, dust or humidity.
5. Avoid extreme temperatures.
6. Never disassemble the monitor or cuff.
7. Dropping or subjecting your blood pressure monitor to strong shocks should be avoided.
Specifications
Name and model number
Talking Automatic Digital Blood Pressure Arm Monitor,
04-695-001
Display system
Digital display/LCD
Measuring method
Oscillometric
Power source
4 "AA" batteries
Measuring range
Pressure: 0-300 mmHg
Pulse: 40-180 beats/minute
Accuracy
Pressure: ±3 mmHg
Pulse: ±5% of reading
Inflation
Automatic Inflation
Deflation
Automatic Pressure Release Valve/Manual fast release
Memory
Built-in memory enabling display of up to 120 measurements
Automatic shut-off
Approximately 1 minute after last button operation
Operation environment
Temperature 41
Humidity < 90%
Storage environment
Temperature -4
Humidity < 95%
Monitor dimensions
5" x 5-1/8" x 2-3/8"
Weight
11.11 oz. (without batteries)
Arm circumference range
Adult cuff fits arm circumference: 11-3/4" – 16-1/2" (30-42 cm)
Large cuff fits arm circumference 16-1/2" – 18-7/8" (42-48 cm)
Accessories
Cuff, batteries, case, detailed guidebook, quick start guide,
blood pressure log
Specifications are subject to change without notice
o
o
o
o
F – 104
F (5
C – 40
C)
o
o
o
o
F – 131
F (-20
C – 55
C)
#91-032-695 08/10
©2010 Briggs Medical Service Company
17
