BuckMaster 42ZCBB User Manual

Firebox enclosure for gas-fired decorative type unvented room heaters
Hide thumbs Also See for 42ZCBB:
Table of Contents

Advertisement

Quick Links

Download this manual
BUCK STOVE MODEL 42ZCBB VENTLESS
FOR GAS-FIRED DECORATIVE TYPE UNVENTED ROOM
HEATERS FOR USE WITH OPTIONAL WOODEN FLUSH MOUNT
MANTEL (FF) AND OPTIONAL WOODEN SURROUND (WS)
MEETS THE MINIMUM DIMENSIONS REQUIRED
WARNING: If information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
INSTALLER:
CONSUMER:
MANUFACTURED BY NEW BUCK
CORPORATION
200 ETHAN ALLEN DRIVE, PO BOX 69
SPRUCE PINE, N.C. 28777
www.buckstove.com
FIREBOX ENCLOSURE
(UNIVERSAL BOX)
FOR USE ONLY WITH
A LISTED GAS-FIRED UNVENTED
DECORATIVE ROOM HEATER
NOT TO EXCEED
40,000 BTU/H
DO NOT BUILD A WOOD FIRE
Carefully review instructions supplied
with decorative type unvented room heater
for minimum fireplace size requirement.
DO NOT INSTALL AN APPLIANCE IN
THIS FIREBOX UNLESS THIS FIREBOX
FOR THE INSTALLATION
Leave this manual with appliance.
Retain this manual for future reference.
Revised January 2013
