Summary of Contents for SkyLine HDSR 400
-
Page 2: Table Of Contents
Table Of Contents Introduction ..................2 Front panel and rear panel illustration..........3 Front Panel..................3 Rear Panel ..................3 Remote control..................4 Installing the batteries ................ 5 Connecting to equipments ..............6 First time installation ................9 Basic Operation................. 13 Teletext and EPG Operation............. -
Page 3: Safety Instructions
Safety Instructions Notes • Always read the safety instructions carefully • Keep this User's Manual for future reference • Keep this equipment away from humidity • Lay this equipment on a reliable flat surface before setting it up. • Do not stand it on soft furnishings. •... -
Page 4: Introduction
Introduction This high definition (HD) DVB-S2 receiver is suitable for the reception of FTA digital satellite TV and radio programs with the best picture quality for your digital life. Main Features Fully DVB-S2 and DVB-S compliant Support HDTV MPEG-2 & MPEG-4 H.264 decoding Support DiSEqC 1.2 &... -
Page 5: Front Panel And Rear Panel Illustration
Front panel and rear panel illustration Front Panel STANDBY: To enter standby mode. MENU: To enter the main menu. OK: To confirm your selections. VOL-: To decrease the volume level. VOL+: To increase the volume level CH- : Used to change channels. CH+ : Used to change channels. -
Page 6: Remote Control
Remote control Remote key functions: 1. STANDBY: To switch the set top box to on and off. 2. NUMERIC buttons: To select a channel by direct number input. 3. REC: To start to record program. 4. REW: To scan backward when playing a recorded program or time shift. -
Page 7: Installing The Batteries
Installing the batteries Remove the battery cover from the remote control and put two AAA size batteries inside the compartment. The diagram inside the battery compartment shows the correct way to install the batteries. Caution: 1. Keep batteries out of children’s reach. 2. -
Page 8: Connecting To Equipments
Connecting to equipments In order to gain optimum signal quality, please read this chapter carefully before using and select the most appropriate procedure depending on the equipment you have. Note: If you encounter any problems setting up your product, please contact your local product distributor. - Page 9 Connecting to equipment 2). HDMI cable also carry audio, so you will need to mute the TV volume if you are using the Digital Audio Out (Optical out) connected through a HI-FI amplifier. 3). To get the best image quality, recommend to set the video output mode to HDTV, press the “FORMAT”...
-
Page 10: Connecting To Equipment
Connecting to equipment 3. Connect the receiver with TV via TV Scart. NOTE: 1. SCART support will provide only standard definition output at 576i.This connection enables you to record the program that you are watching. -
Page 11: First Time Installation
First time installation This menu consists of 5 main menus: Installation Channels System Setting USB DEVICE System Information 1 By pressing the Arrow (▲/▼) buttons you can move upwards and downwards on the menus. 2 When you have reached the required subject menu, press the OK button to confirm your choice. - Page 12 First time installation 5. Select the item(s) you want to edit or change any of the parameter(s) of, however these should be preset to the default value shown in brackets [ ] for the most popular configuration using a Universal LNB and will only need to be changed if you need to fit motorized systems, non standard LNB’s or Satellite DiSEqC switches for multiple dish LNB feeds.
- Page 13 First time installation 3. Select Frequency using the Arrow (▲/▼) buttons and press the OK button. To view the frequency list, press the OK button. Select the frequency using the Arrow (▲/▼) buttons and press the OK buttons. Motorized Setting menu indicates the selected frequency.
- Page 14 First time installation Search Type: All, Free and TV. You can select All (Free to view and Pay to view TV and Radio channels are downloaded), Free (Free to view TV and Radio are downloaded) or TV (Free to View and Pay to View channels are downloaded) to be searched for the selected satellite(s).
-
Page 15: Basic Operation
Basic Operation Change Channels 1. Press the numeric buttons (0~9) on the remote control to select the channel number you want. 2. Press the ▲ or ▼button on the remote control or the front panel to change the available channels upward/downward. 3. -
Page 16: Teletext And Epg Operation
Teletext and EPG Operation View teletext 1. Press the TTX button to open a teletext page (the teletext transmitted depends on the program providers), press again to exit. 2. Press the 4 colour buttons and numeric buttons (0-9) to assist the operation. 3. -
Page 17: Menu Operation
Menu Operation Channel Editing You can modify the TV and radio programs using these items: Favorite, Edit, Move, Lock, Skip, Delete channels. Press the MENU button to enter the main menu then select the Channels by pressing the ▲ and ▼ buttons and press the OK button to access the Channel Editing menu. -
Page 18: System Setting
Menu Operation To Move Channel You can organize the number or sequence of the channels by using the◄►,▲▼ buttons, select the channel you want to move by pressing the OK Button, then press the INFO and ▲▼ buttons to move the cursor to the point you want the channel to be stored and then press the OK button to store at the new location. - Page 19 Menu Operation Time Setting You can set system time using this menu. Press the ▲ and ▼ buttons to select the Time Setting and press the OK button to enter the Time Setting menu. A/V output Setting You can set the AV items: Video format, Screen format, Display format, SPDIF output and Scart mode, modify these settings to be compatible with your TV display and any other equipment you may have connected to this satellite reciever Press the ▲...
- Page 20 Menu Operation OSD Setting Transparency: To set a level of transparency for the OSD (On Screen Display) menu. Menu language: To set the menu language you want. The default language is English. Security Setting This menu allows you to set Receiver lock, Install lock, Channel lock, Age limit, New password and Verify password.
-
Page 21: Usb Device
Menu Operation Database Reset The status of the receiver will return to factory default parameters by using this function. Press the MENU key. Select System Setting with the ▲ and ▼ buttons and press OK. Select Database Reset with the ▲ and ▼ buttons and press OK. -
Page 22: To Play Or View Recorded Program
Menu Operation 2. To Play or View Recorded Program All the recorded programs can be viewed and browsed under the USB DEVICE menu. Play the program After accessing to USB DEVICES menu, press the Arrow (◄/►) buttons to select the Partition C item. Press OK button to enter the Partition C. -
Page 23: Trouble Shooting
Trouble shooting If you experience problems with this receiver or its installation, in the first instance please read carefully the relevant sections of this User Manual and this Troubleshooting section. 1. No message displayed on the front panel. (The product will not switch on.) - Check the main power cable and make sure it is plugged into a suitable power outlet. -
Page 24: Technical Specifications
Technical specifications LNB/Tuner input: Connector: IEC 169-24,female Frequency range: 950Mhz -2150Mhz Signal level: -65dBm-25dBm LNB supply:14/18V max 400mA LNB switch control: 22KHz DisEqC Ver 1.2 Compatible Demodulator: Frontend QPSK /8PSK Symbol rate 2Msps -45Msps SCPC and MCPC Capable Spectral inversion Auto conversion 2.
