Hawk gk-150-Q Owner's Manual

Off-road buggy

Advertisement

Record the VIN number and Model number of your Kart below for
service and insurance records.
The VIN number is hard tagged on the kart frame just behind the
driver seat.
VIN:
YOUR WARRANTY RIGHTS AND OBLIGATIONS
The emission control system warranty period for this vehicle begins on the date the vehicle is delivered to the first
purchaser other than an authorized dealer, or the date it is first used as
a demonstrator, lease, or company vehicle, whichever comes first and continues for 30 months after that date, or
5,000km, whichever comes first, provided there has been no abuse,
neglect or improper maintenance of your vehicle. Where a warrantable condition exists, the Distributor will repair your
vehicle at no cost to you, including diagnosis, parts and labor. If an emission-related part on your vehicle is defective,
the part will be repaired or replaced by the Distributor. This is your emission control defects warranty.
OWNER'S WARRANTY RESPONSIBILITIES
As the vehicle owner, you are responsible for the performance of the required maintenance. You should maintain a
record of all maintenance performed on your vehicle and retain all receipts covering maintenance on your vehicle.
You may not be denied a warranty claim solely because of your failure to ensure the performance of all scheduled
maintenance or lack of maintenance records or receipts. You are responsible for presenting your vehicle to an
authorized dealer as soon as a problem exists. The warranty repairs should be completed in a reasonable amount of
time, not to exceed 30 days.
As the vehicle owner, you should be aware that you may be denied your warranty coverage if your vehicle or a part
has failed due to abuse, neglect, improper maintenance, or unapproved modifications.
WARRANTY COVERAGE
The Distributor warrants that each new 2008 and later vehicle:
· is designed, built, and equipped so as to conform at the time of initial retail purchase with all applicable regulations
of the United States Environmental Protection Agency, and the California Air Resources Board; and
· is free from defects in material and workmanship which cause such vehicle to fail to confirm with applicable
regulations of the United States Environmental Protection Agency or the California Air Resources Board for the
periods specified above.
Your emission control system warranty covers components whose failure would increase an engine's emission,
including electronic controls, fuel injection system, carburetor, the ignition system, catalytic converter, or any other
system utilized in this vehicle to control emission if it is originally equipped. Also included may be hoses, connectors
and other emission-related assemblies. Replacing or repairing other components (including parts, labor, and other
costs) not covered by this emission control system warranty or the standard warranty is the responsibility of the
owner.
Coverage of repairs under this warranty applies only when repairs are completed at an authorized dealer or repair
facility. The Distributor will not cover repairs performed outside of an authorized dealer or repair facility, except in an
emergency situation. The use of replacement parts not equivalent to the original parts may impair the effectiveness of
your vehicle's emission control system. If such a replacement part is used and an authorized dealer determines it is
defective or causes a failure of a warranted part, your claim for repair to bring your vehicle into compliance with
MY VEHICLE IDENTIFICATION NUMBER

EMISSION CONTROL SYSTEM WARRANTY

Model :
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the gk-150-Q and is the answer not in the manual?

Questions and answers

Summary of Contents for Hawk gk-150-Q

  • Page 1: Emission Control System Warranty

    MY VEHICLE IDENTIFICATION NUMBER Record the VIN number and Model number of your Kart below for service and insurance records. The VIN number is hard tagged on the kart frame just behind the driver seat. VIN: Model : EMISSION CONTROL SYSTEM WARRANTY YOUR WARRANTY RIGHTS AND OBLIGATIONS The emission control system warranty period for this vehicle begins on the date the vehicle is delivered to the first purchaser other than an authorized dealer, or the date it is first used as...
  • Page 2 applicable standards may be denied. If an emergency situation exists when a warranted part or a dealer is not reasonably available to the owner, repairs may bent part. The Distributor shall reimburse the owner for the expenses, including diagnostic charges, not to exceed the Distributor’s suggested retail price for all warranted parts replaced and labor charges based on the Distributor’s recommend time allowance for the wa performed at any available service establishment, or by the owner, using any replacemerranty repair and the geographically appropriate hourly labor rate.
  • Page 3 WHAT IS NOT COVERED UNDER THIS WARRANTY Misuse, Negligence, Alterations, Accidents or any abnormal use including non genuine parts, renting or leasing, competition or racing. This warranty does not cover loss of use of the unit or loss of time, or inconvenience or normal wear and deterioration caused by the use or storage of consumable items such as spark plugs, chain, brake shoes, fuses, clutch plate, sprockets, light bulbs, battery and tires.
  • Page 4: Table Of Contents

    SAFETY LABELS……………………………………………………………...7 QUALIFICATIONS FOR FUN-KART USERS…………………………… …7 ARE YOU READY TO DRIVE?……………………………………………….9 IS YOUR VEHICLE READY TO DRIVE?……………………………………11 SAFE DRIVING PRECAUTIONS…………………………………………….12 9. INSTALL INSTRUCTION…………………………………………………… …14 10. SPECIFICATIONS………………………………………………………… ….17 11. OPERATION……………………………………………………………………18 12. SERVICE INSTRUCTIONS…………………………………………………..21 13. REPAIR…………………………………………………………………………24 14. PERIODICAL CHECK AND SERVICE………………………………………26 WIRING DIAGRAM ……………………………………………………………27 SPARE PARTS CATALOGUE ………………………………………………..28 FOREWORD...
  • Page 5: A Few Words About Safety

    familiar with operations of this Kart. Children must be of specified age or older and supervised by an adult at all times when using the fun kart. We hope you will have a pleasant experience with our products and thanks again for choosing our Kart.
  • Page 6: Safety Labels

    Always Wear a DOT or Snell approved Motorcycle type Helmet It’s a proven fact: helmets significantly reduce the number and severity of head injuries. Always wear an approved motorcycle helmet. We also recommend that you wear eye protection, sturdy boots, gloves, and other protective gear. Drive Off-Road Only Your Kart is designed and manufactured for off-road use only.
  • Page 7 hard to read, contact your dealer for warning label replacement. ! ATTENTION ! Prior to operating vehicle,check and adjust tire pressure to proper operating pressure as indicated on the sidewall of each tire . ! WARNING THIS KART IS NOT SUITBALE FOR A CHILD UNDER 12 YEARS OLD ! WARNING -A HELMET MUST BE WORN AT...
  • Page 8: Qualifications For Fun-Kart Users

    QUALIFICATIONS FOR FUN-KART USERS This Fun-Kart is restricted to use by operator and passenger with a minimum age of twelve years. Fun-Karts are intended for use by operators who meet the physical and cognitive capabilities set out by the manufacturer in the material provided with the Fun-kart. A 20mph speed reduction kit is available for this fun-kart.
  • Page 9 6. Fun karts shall only be fueled by a supervisor knowledgeable with regard to proper fueling techniques. 7. A supervisor shall verify personally that everyone operating or riding is knowledge able, capable, and has the cognitive capacity to operate the Fun-kart safely, including those items specified in 1 through 6.
  • Page 10 a .Transport a passenger except in the seating area provided. b .Transport materials or equipment; c . Transport animals. 11. Fun-kart operators always shall use appropriate protective clothing including but not limited to a motorcycle type helmet and eye protection,with appropriate certification.and any other equipment recommended by the Fun-Kart manufacturer including gloves ,...
  • Page 11: Are You Ready To Drive

    Additional Driving Gear In addition to a helmet and eye protection, we also recommend: ■ Sturdy off-road motorcycle boots to help protect your feet, ankles, and lower legs. ■ Off-road motorcycle gloves to help protect your hands. ■ Driving pants with knee and hip pads, a driving jersey with padded elbows, and a chest/shoulder protector.
  • Page 12: Is Your Vehicle Ready To Drive

    WARNING Improperly maintaining this Kart or failing to correct a problem before driving can cause a crash in which you can be seriously hurt or killed. Always perform a pre-drive inspection before every drive and correct any problems. Pre-drive Inspection Check the following items before you get on the Kart: ■...
  • Page 13 Off-Road Use Only Your Kart and its tires are designed and manufactured for off-road use only, not for pavement. Driving on pavement can affect handling and control. You should not drive your Kart on pavement. WARNING Operating this Kart on paved surfaces may seriously affect handling and control of the Kart, and may cause the vehicle to go out of control.
  • Page 14: Install Instruction

    Use Care on Unfamiliar or Rough Terrain Before driving in a new area, always check the terrain thoroughly. Don’t drive fast on unfamiliar terrain or when visibility is limited. (It’s sometimes difficult to see obstructions like hidden rocks, bumps, or holes in time to react.) WARNING Failure to use extra care when Operating this Kart on unfamiliar terrain could result in the Kart overturning or going out of control.
  • Page 15: Specifications

    INSTALL INSTRUCTION SPECIFICATIONS DIMENSIONS Overall Length ………………………………………………………2230mm (87.80 in) Overall Width ………………………………………………………1520mm (59.84in) Overall Height ………………………………………………………1437mm (56.57in) Wheelbase …………………………………………………………1651mm (65 in) Ground Clearance ……………………………………………………320mm (12.60in) ENGINE Type ………………………..149.6cc strong Air cooled, single cylinder four stroke Bore/Stroke ………………………………………………………………57.4X57.8mm Displacement …………………………………………………………………149.6cm3 Compression ratio ………………………………………………………………….9.5:1 Max power ………………………………………………………...
  • Page 16: Operation

    Rating power ………………………………………………………………..5.2kw/7000 Maximum Torque ……………………………………………………….7.6nm/6000rpm Starting …………………………………………………………Electric and foot push Ignition ……………………………………………………………………………….C.D.I. Lubrication ……………………………………………………………….Force & Splash Transmission …………………………………………… …Automatic (C.V.T system) …………………………………………..dry and hoofed method clutch ……………………………………Front: CVT, Rear: 2 gears decelerate ………………………………… CVT transmission ratio: 2.577 ~0.86 Fuel Type …………………………………………………RQ90 (unleaded) GB17930 Lubricate oil ………………………………………………………...
  • Page 17 OPERATION c. Start engine nsert the key into key-switch, turn the key clockwise, and release the key when the engine starts. The engine will warm up within 5 minutes and the engine choke will close automatically and operate at the normal RPM (Warning: Don’t crank starter more than 5 seconds at one time). d.
  • Page 18 i. Check Roll cage bar, Ensure all protective roll cage bars are in place before operating the Kart. j. Check Brake Light. Check for proper operation. k. Check Wheels. Check for tightness of wheel nuts and axle nuts; check that axle nuts are secured by cotter pins.
  • Page 19 C.Passengers The vehicle allows for two riders only. Combine maximum Weight of driver and the passenger should not exceed 180kg or 400lbs. D. Seat Adjustment The seat must always be securely fastened in the position which best affords the operator control of the foot pedals, steering wheel, and the emergency stop button.
  • Page 20: Service Instructions

    OPERATION/SERVICE INSTRUCTIONS F. Starting And Operation Instructions a. Before starting the engine, be sure that the driver is seated properly in the Kart with the seat belt. b. Testing the Kart in an open space at the beginning to learn how to start, turn and stop. c.
  • Page 21 of operation. Add oil to bring up to proper level. Do not mix various grades of oil. C. Spark Plug Remove the spark plug and inspect it each time you change the oil. (Use a spark plug wrench) The electrodes should be kept clean and free of carbon. The presence of carbon or excess oil will greatly reduce engine performance.
  • Page 22 To increase chain life, lubricate with a spray on dry graphite chain lubricant. (See Fig.10) FIGURE10 H. Chain Adjustment Check the chain adjustment after first two hours of use. Readjust if it has more than 1/2” flex. a. Loosen Nut #1 b.
  • Page 23 In the event your kart is not to be operated for a period in excess of 30 days or at the end of each driving season prepare for storage as follows: a. Drain fuel tank and carburetor by allowing engine to run out of fuel, or use a fuel stabilizer. b.
  • Page 24: Repair

    FIGURE13 REPAIR C. Front Wheel Alignment a. The front wheels should be “toe-in” from 1/8” to 1/4”. To check for alignment, measure distance A and B between the centerline (CL) of the wheels. The proper toe-in dimension A should be 1/8”-1/4” greater than dimension B. b.
  • Page 26: Periodical Check And Service

    PERIODICAL CHECK AND SERVICES The maintenance intervals in the following table are based upon average driving conditions. Driving in unusually dusty areas, require more frequent servicing: Time of service Initial service Monthly Quarterly Yearly (First week) Items Tire pressure/wear Brake performance Tightness of screws Air cleaner Carburetor...
