- Page 1 Quick Start Guide TRK-USB-MPC5602P StarterTRAK Mini USB for Automotive Applications...
- Page 2 USB development platform. It is designed for you to easily and inexpensively give Freescale’s 32-bit Qorivva microcontrollers a test drive. This board can also be used in conjunction with the Freescale Tower System, allowing you to rapidly prototype designs with a...
- Page 3 TRK-USB-MPC5602P Features • MPC5602P Qorivva microcontroller • Temperature sensor • Primary Tower System connector • Three user-programmable multi-colored LEDs • Two user-programmable push buttons • OSBDM debugger through USB...
-
Page 4: Connect Device To Computer
Quick Start Guide Step-by-Step Installation Instructions This quick start guide details how to set up the TRK-USB-MPC5602P board and run some demo projects on the device. Install Software Download Supporting and Tools Documentation • Download and install the CodeWarrior • Download the MPC5500/5600 Development Studio for MPC55xx/ Simple Cookbook and the MPC5xx v2.9 (Classic). Available at MPC5602P reference manual freescale.com/StarterTRAKmini from the downloads tab at freescale.com/StarterTRAKmini... - Page 5 TRK-USB-MPC5602P Explore Further • Download the example projects and applications located under the downloads tab. These include the MPC5500/5600 Simple Cookbook examples, a TRK-USB-MPC5602P- specific project and supporting Windows application. This application code utilizes the on-board temperature sensor switches and LEDs, as well as many on-chip peripherals. P&E CDC drivers will be required for this application. Note 1: Updated drivers are required for full device functionality and are available on the P&E OSBDM...
-
Page 6: Other Connections
Quick Start Guide On-Board Connections The following tables show the available signals and connections of the TRK-USB-MPC5602P board. Jumpers Other Connections Jumper Option Setting Description MCU Pin Signal LIN Tx to USB Pin 97 (PD2) Switch SW2 LIN Tx Pin 89 (PD3) Switch SW3 LIN Tx to Tower... - Page 7 TRK-USB-MPC5602P Tower System Interface Connections MCU Pin Signal MCU Pin Signal Connector Connector 3.3V 3.3V 3.3V Pin 2 DSPI1_SCK Pin 91 DSPI1_CS1 Pin 30 GPIO_PTC2 Pin 8 DSPI1_CS0 Pin 28 GPIO_PTC1 Pin 4 DSPI1_SOUT Pin 45 GPIO_PTC0 Pin 6 DSPI1_SIN...
- Page 8 Quick Start Guide MCU Pin Signal MCU Pin Signal Connector Connector Pin 75 GPIO_PTA4 Pin 94 GPIO_PTA9 Pin 35 GPIO_PTB9 Pin 32 ADC0_AN5 Pin 27 ADC0_AN4 Pin 41 ADC1_AN4 Pin 31 ADC0_AN1 Pin 44 ADC1_AN1 Pin 29 ADC0_AN0 Pin 42 ADC1_AN0 Pin 52 ETIMER0_ETC1...
- Page 9 TRK-USB-MPC5602P MCU Pin Signal MCU Pin Signal Connector Connector Pin 51 ETIMER0_ETC0 Pin 57 ETIMER0_ETC2 Pin 38 GPIO_PTB12 Pin 36 GPIO_PTB10 3.3V 3.3V Pin 73 FLEXPWM0_B1 Pin 84 FLEXPWM0_X3 Pin 67 FLEXPWM0_A1 Pin 90 FLEXPWM0_B3 Pin 54 FLEXPWM0_B0 Pin 78...
- Page 10 Quick Start Guide MCU Pin Signal MCU Pin Signal Connector Connector Pin 15 GPIO_PTD9 Pin 43 IRQ20_PTB15 Pin 96 IRQ18_PTB6 Pin 100 IRQ14_PTA15 Pin 71 ETIMER1_ETC1 Pin 99 IRQ13_PTA14 Pin 85 ETIMER1_ETC0 Pin 95 IRQ12_PTA13 Pin 56 ETIMER0_ETC5 Pin 83 IRQ11_PTA12 Pin 55 ETIMER0_ETC4...
- Page 11 TRK-USB-MPC5602P MCU Pin Signal MCU Pin Signal Connector Connector...
- Page 12 Freescale, the Freescale logo and CodeWarrior are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. Qorivva is a trademark of Freescale Semiconductor, Inc. All other product or service names are the property of their respective owners. © 2011 Freescale Semiconductor, Inc.
