RCAVICTOR 721TS Service Data

^
rcaVictor
TELEVISION RECEIVER
MODEL
721TS
Chassis
No.
KCS
26-1 (60
cycles)
,
KCS
26-2
(50 cycles)
Mfr.
No.
274
Service
Data
Model
7
2
ITS
Walnut
or
Mahogany
—
1947 No.
T4
RADIO CORPORATION OF
AMERICA
RCA VICTOR DIVISION
CAMDEN,
N.).,
U.S.A.
GENERAL
DESCRIPTION
Model 721TS
is
a
twenty-one tube, direct-viewing,
table-model
Television Receiver
having a
10"
tube (kinescope).
The
receiver
is
complete
in
one
unit
and
is
operated
by
the
use
of
seven front-panel controls.
Features
of
the receiver include:
Full thirteen
channel coverage; f-m
sound
system:
improved
picture brilliance:
two
stages of
video amplification;
A-F-C
horizontal hold, stabilized vertical hold;
improved sync ampli-
fier
and
separator;
and reduced-hazard
high-voltage supply.
ELECTRICAL
AND MECHANICAL
SPECIFICATIONS
r
