Gericom GTV4200-V3 Owner's Instruction Manual

Pal/secam plasma tv
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GTV4200-V3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gericom GTV4200-V3

Summary of Contents for Gericom GTV4200-V3

  • Page 2: Table Of Contents

    Contents ......................2 Important Safety Information Overview Of Your New PDP ......................8 OSD key Position ......................... 8 OSD key function .......................... 8 Back Panel and Ports ........................9 Ports descriptions and RS-232C ....................10 Accessories ............................11 Optional Extras ..........................12 Remote Control ..........................

  • Page 3: Important Safety Information

    Important Safety Information This symbol is intendded to alert the user to the CAUTION presence of uninsulated "dangerous voltage" within magnitude to constitute a risk of electric - TO PREVENT DAMAGE WHICH MAY RESULT shock to persons. IN FIRE OR SHOCK HAZARD. - DO NOT EXPOSE THIS APPLIANCE TO RAIN This symbol is intendded to alert the user to the OR MOISTURE.
  • Page 4 Important Safety Information Always be careful when using your PDP. To reduce the risk of fire, electrical shock, and other injuries, keep these safety precautions in mind when installing, using, and maintaining your machine. 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings.
  • Page 5 Important Safety Information Follow all operating and use Unplug the Monitor from the wall Never add any attachments and/or instructions. outlet before cleaning. Use a damp equipment without approval of the cloth; do not use liquid or aerosol manufacturer. Such additions can cleaners.
  • Page 6 Important Safety Information Provide ventilation for the Monitor. The unit is designed Use only the accessory cord designed for this product to with slots in the cabinet for ventilation to protect it from prevent shock. The power supply voltage rating of this overheating.
  • Page 7 Important Safety Information Do not overload the wall outlet or Do not insert anything through the Bend antenna cable between inside extension cords. Overloading can openings in the unit, where they can and outside building to prevent rain result in fire or electric shock. touch dangerous voltage points or from flowing in.
  • Page 8 Important Safety Information When replacement parts are Upon completion of any service or If you make adjustments yourself, required, be sure the service repairs to this Monitor, ask the adjust only those controls that are technician uses replacement parts service technician to perform safety covered by the operating instructions.

  • Page 9: Overview Of Your New Pdp

    Overview Of Your New PDP OSD Key Position <Front Panel> OSD key & Function Input Source Select DOWN (See the box below.) Power (Stand By) Status / Power Indicator LED Remote Sensor OSD Key Function INPUT SELECT Select the signal source from multiple input sources such as TV, SCART 1, SCART 2, S-Video / AV, Component1, Component2, PC and DVI.

  • Page 10: Back Panel And Ports

    Overview Of Your New PDP Back Panels and Jacks <Back panel of the monitor> RS-232C Only for service. For PC, Set top box. Speakers PC/DVI Audio Input. D-Sub (PC) For PC, Set top box. Component 1, 2 For DVD, Set top box. Speakers To connect speakers (2CH, Stereo) only 8 ohm! SCART 1 (Euroconnector)

  • Page 11: Ports Descriptions And Rs-232C

    Overview Of Your New PDP RS-232C Jack Only for Service do not use this connector!!! DVI INPUT JACK Connects a digital video signal from a DVI output jack of PC or Set Top box. RGB PC INPUT JACK ( D-SUB ) Connects a video signal from a video output jack of PC.

  • Page 12: Accessories

    Accessories Remote Control Handset Power Cord D-sub 15 pin cable Alkaline Batteries RF Cable Owner's Manual OWNER'S MANUAL...

  • Page 13: Optional Extras

    Optional Extras Table Stand Table Stand (type United) (Type Separated) Flexible Wall Side Mount Speaker Mount Bracket OWNER'S MANUAL...

  • Page 14: Remote Control

    Controls Of The Remote Control Key Description Power Turn the PDP on and off. Mute Temporarily cut the sound and restore it. Pre PG Turn to the previous programme or exit OSD. V.Size Choose the screen form. 16:9 Panorama Zoom1 Zoom2 FAVORITE (FAVOURITE) Tune to your next favorite programme.

  • Page 15: Controls Of The Remote Control

    Controls Of The Remote Control Choose the MTS (Stereo) mode. Each time it is pressed, different mode is selected. Mono Stereo Nicam LanguageA LanguageB LanguageAB You can select only available modes depending on the source. PG INFO Display the current information about time, screen form, source and MTS mode.

  • Page 16: Loading The Batteries

    Controls Of The Remote Control Loading The Batteries Press on the cover and slide Load two AAA batteries, Close the cover until it clicks. in the direction of the arrow. taking care that the + and - ends face the correct direction.

  • Page 17: Monitor Installation

    Monitor Installation The Monitor can be installed in various ways such as Wall Mounting type, Table Stand type, etc.. Wall Mount (optional) Installation <The monitor can be installed on the wall as the picture above> • Install this monitor only in a location where adequate ventilation is available. OWNER'S MANUAL...
  • Page 18 Monitor Installation 1. Before installation of monitor, Assemble to the same inch of the PDP shown as left(2). 2. Lift the monitor brackets off the mounting frame shown as arrow 1. GUIDE BRACKET MONITOR BRACKET WALL MOUNTING BRACKET 1. Drill the 8 hole positions shown as left. Using an 8mm drill appropriate for the material on the wall, drill each hole to a depth of exceed 80mm.
  • Page 19 Monitor Installation 1. Shown as left, carefully place the monitor screen side down on a cushioned surface that will protect the monitor and screen from damage. 2. Insert the monitor brackets on the monitor shown as left. Install the 4 bolts securely, in the back of the monitor in the holes provided.
  • Page 20 Monitor Installation Wall Mount Accessories ANCHOR 8EA SCREW 8EA BOLT 6EA BOLT 6EA M8 x 30L M4 x 6L OWNER'S MANUAL...

  • Page 21: Table Stand Installation (Optional)

    Monitor Installation Table Stand Installation(optional) <The Monitor can be installed on the desk as shown above.> • Table Stand mount minimum allowable clearances for adequate ventilation. OWNER'S MANUAL...
  • Page 22 Monitor Installation Installation OWNER'S MANUAL...

  • Page 23: Speaker Installation (Optional)

    Monitor Installation Speaker Installation Speaker Installation (Optional) Attention: Please use only speakers with 8 ohm! • Match red to red, black to black of speaker / TV • Be sure monitor power is turned off before making any connections. Place the speakers in the position you want. Install the speaker wires on the monitor and speaker. Be sure to connect the positive "+"...
  • Page 24 Monitor Installation Speaker Accessories 4-Iron Plates (Mount speakers to monitor) 8-4 x 16 Long Bolts (Attach iron plates to speakers) 8-4 x 8 Short Bolts (Attach iron plates to monitor) 2-Speaker Wires 9673 OWNER'S MANUAL...

  • Page 25: Watching Tv

    Watching TV To watch TV Connect the TV Antenna cable to the TV input jack. Press INPUT button on the remote control and select TV on OSD. Use PG+, PG- button or numeric button to change TV programme for your programme selection. Press Pre PG button on the remote control to tune the previous programme.

  • Page 26: Watching Vcr

    Watching VCR How to connect With SCART (Eurocable) Connect a SCART cable to the SCART jacks of the VCR and the PDP. With S-Video Connect a S-Video cable to the S-Video jacks of the VCR and the PDP. Connect L (White), R (Red) sound cable (composite) to the sound jacks of the VCR and the PDP. With AV input Connect a composite cable to the AV video jacks of the VCR and the PDP.

  • Page 27: Watching Dvd

    Watching DVD How to connect • Connect the three separate component video cables to the DVD player's Y, Pb and Pr jacks and to the Component jacks on the PDP. • Connect the audio cable to the DVD player's audio L (White) and R (Red) jacks and to the L and R audio jacks beside the Component jacks on the PDP.

  • Page 28: Watching Set Top Box

    Watching Set Top Box How to connect Connect Set Top Box video inputs to SCART, COMPONENT, PC or DVI jacks on the PDP. Audio inputs to Audio sockets beside the L (White) and R (Red) audio jacks which you connect video inputs. How to use Supported Signals Component1...

  • Page 29: Connecting The Pc

    Connecting The PC(D-Sub and DVI) Connecting a PC to the PDP Connect a PC (15pin) video cable between the Video Output port on the PC and the Pin No. Description PC port on the PDP. Red (R) Green (G) Pin Configuration Blue (B) 15Pin Signal Cable Grounding...

  • Page 30: Displayable Monitor Specification

    Displayable Monitor Specification Resolution Horizontal Frequency (KHz) Vertical Frequency (Hz) 31.468 70.09 640 x 350 37.861 85.08 31.469 70.08 640 x 400 37.927 85.03 31.469 59.94 35.000 66.66 37.861 72.80 37.500 75.00 640 x 480 43.269 85.00 45.913 90.03 53.011 100.04 64.062 120.00...

  • Page 31: Basic Operation

    Basic Operation Turning PDP TV On And Off Press the Power button on the remote control. The PDP will turn on and you will be ready to use its features. You can also use the Power key on the front panel. Select Source Press INPUT button on the remote control.

  • Page 32: Osd Menu Structure

    OSD Menu Structure • OSD (On Screen Display) allows users to control or adjust various features and settings in accordance with his/her preferences. • Press the Menu/Set button on the remote control to see the main OSD menu. EXAMPLE of OSD Menu part Main Menu Press Menu / Set key on the remote control to enter the main OSD menu.

  • Page 33: Channel (Tv)

    CHANNEL (TV) Store TV channels You can now search for and store the TV channels in two different ways : using Auto Scan or Manual Scan. Auto Scan Press Menu/set button to display the main OSD menu. Select the TV Main menu. Press Menu/Set to enter the sub menu.
  • Page 34 CHANNEL (TV) Manual Scan Press Menu/set button on the remote control to display the main OSD menu. Select the TV main menu with PG+ / PG- button on the remote control. Press Menu/Set button to enter the sub menu. Select Manual Scan with PG+ / PG- button and press Menu/Set button.
  • Page 35 CHANNEL (TV) Edit Favorite programme List You can store of your favorite channels for each available input source (such as TV or CATV). Then, when you press the FAVORITE button on the remote control, the PDP display only the favorite channels you previously stored, allowing you to quickly and easily find frequently wanted channels.
  • Page 36 CHANNEL (TV) Digest With the Digest function, you can select a TV prgoramme watching 9 programme at once. This function works in TV mode only. Press the DIGEST button on the remote control. Then the digest windows will appear. Press the channel number to watch with the numeric buttons on the remote control.

  • Page 37: Picture (Tv)

    PICTURE Mode Your PDP has 3 automatic factory preset picture settings ("Standard", "Sharp" and "Mild"). You can choose Standard, Vivid or Mild by pressing "Picture" key on the remote control (or by making a selection from the menu). Or you can select USER which automatically recalls your personalized picture settings.
  • Page 38 PICTURE Adjust USER Mode You can change the Contrast, Brightness, Color, and Sharpness according to personal preference in USER mode. Select the item to adjust with PG-, PG+ button. Select USER mode (Previous page) Press Menu/Set button. Adjust the item with VOL-, VOL+ button. To cancel all adjust, select Recall and press Menu/Set button.
  • Page 39 PICTURE CONTRAST Adjust brightness difference between bright part of the screen and dark part. Distinct Vague BRIGHTNESS Adjust brightness of the screen. Dark Bright COLOR Adjust deep and light color of the screen. Decrease Increase SHARPNESS Adjust vividness of the screen. Less sharp Sharp OWNER'S MANUAL...
  • Page 40 PICTURE Temperature Your PDP has 5 screen temperatures (color settings): Press Menu/set button to display the main OSD menu. Select the picture main menu. Press Menu/Set to enter the picture menu. Select Temperature and press Menu/Set to enter the under menu. Then the Picture-Temperature under menu appear.
  • Page 41 PICTURE Video NR This function automatically filters out and reduces the image noise and improves picture quality where receiving weak signals. Press Menu/Set button to display the main OSD menu. Select the picture main menu item. Press Menu/Set to enter the sub menu. Select Video NR and press VOL+ button to enter the parts.
  • Page 42 PICTURE Screen Format Your PDP has four Screen Formats: 16:9, PANORAMA, ZOOM1, ZOOM2, 4:3. (For more detail description for these modes, refer to the next page.) Press Menu/Set button to display the main OSD menu. Select the picture main menu. Press Menu/Set to enter the picture menu.
  • Page 43 PICTURE Screen Format Description 16 : 9 16:9 video: No change. 4:3 video: Expands 4:3 video signal horizontally to fit the 16 : 9 screen. Panorama 16:9 video: No change. 4:3 video: Expands 4:3 video horizontally to fit the 16 : 9 screen and to minimize distortion, sides are expanded more than center.

  • Page 44: Picture (Pc)

    PICTURE ( PC ) In PC mode, you can adjust the H,V-Position, Clock and Phase. Also you can adjust them automatically. Geometry You can change H, V-Position, Clock and Phase in PC mode like usual PC monitors. You can also adjust them automatically.
  • Page 45 PICTURE ( PC ) H-POSITION V-POSITION PHASE Mismatch Match CLOCK Mismatch Match OWNER'S MANUAL...

  • Page 46: Sound

    SOUND In SOUND Menu, you can adjust balance, MTS ( Multi-Track Sound), AVC (Auto Volume Control) and select the equalizer settings. Balance This control allows you to adjust the balance of the left and right speaker output. Press Menu/set button to display the main OSD menu.
  • Page 47 SOUND Sound Mode Your PDP has four automatic sound settings ("Standard", "Movie", "Music" and "News") that are preset at the factory. You can activate either Standard, Movie, Music or News by pressing "SOUND" on the remote control (or by making a selection from the menu) or you can select "Custom" which automatically recalls your personalized sound settings.
  • Page 48 SOUND User Adjust You can use the OSD menu to change the Treble, Bass, Balance and DRC according to your preference. equalizer menu appear when you Select USER mode (Previous page) select USER mode. Select a gain bar with VOL+, VOL- button on the remote control and adjust it with PG+ / PG- button.
  • Page 49 SOUND Select sound signal format from the input source. There are Mono, Stereo, NICAM and Bilingual sound formats. Press Menu/set button to display the main OSD menu. Select the SOUND main menu with CH+ / CH- button on the remote control. Press Menu/Set to enter the sub menu.

  • Page 50: Set Up

    SET UP In SET UP menu, you can adjust the transparency of the OSD menu and set PIP and others. Translucent Adjust the transparency of the OSD menu. There are 8 step from OFF to 7. Press Menu/set button to display the main OSD menu.
  • Page 51 SET UP PIP (Picture In Picture) You can watch two programmes or sources at the same time. And set up PIP size and position Press Menu/set button to display the main OSD menu. Select the SET UP main menu with PG+ / PG- button on the remote control.
  • Page 52 SET UP Source in PIP (Continued from 50 page) Change the source of the PIP window. Select Source and press Menu/Set to enter the sub menu. Then the PIP sub menu appear. The available sources will be displayed. Select the source and press Menu/Set button.
  • Page 53 SET UP Position in PIP (Continued from 50 page) Change the position of the PIP window. Select Position with PG+ / PG- button on the remote control and press Menu/Set to enter the sub menu. Then the PIP sub menu appear. In Sub Menu, there are four positions.
  • Page 54 SET UP Advanced You can se up ID, Burn Protect, Blue Back, Language and Child Lock in Advanced Menu. Press Menu/set button to display the main OSD menu. Select the SET UP main menu with PG+ / PG- button on the remote control. Press Menu/Set to enter the sub menu.
  • Page 55 SET UP Burn Protect in Advanced PDP may be damaged from displaying a static image long time (over 30 minute). It is called as image sticking, and Burn protect function moves image regularly to relieve image sticking. You can set the moving range of the Burn Protection function (How much the image will move.). Burn Protection function moves image 1 pixel per 2 minute, and after moving the set range, image starts to go back to the original position.
  • Page 56 SET UP Language in Advanced Set the language to use in OSD. Supported languages are English, French, German, Spanish, Italian. Select language and press VOL+ button to enter the parts. Then the cursor moves into the parts. Choose the Language with PG+ / PG- button and press BACK button.

  • Page 57: Time

    TIME In the TIME menu, you can set the current time and auto power on / off. Time Set Set the current time. Press Menu/set button to display the main OSD menu. Select the TIME main menu. Press Menu/Set to enter the sub menu. Select Time Set by pressing VOL+ button.
  • Page 58 TIME On Channel Set the channel when PDP power turn on automatically. • Available only when the Time is set and On Time is ON. Press Menu/set button to display the main OSD menu. Select the TIME main menu with PG+ / PG- button on the remote control.
  • Page 59 TIME Off Time This PDP can be set to turn off automatically at specific times that you choose. Before using the timer, you must set the PDP's clock as described previously. Press Menu/set button to display the main OSD menu. Select the TIME main menu with PG+ / PG- button on the remote control.

  • Page 60: Teletext

    TELETEXT Teletext On / Mix / Off You can switch on and off teletext function by pressing TEXT button on remote control. TOP text The user guide displays four fields - red, green, yellow and blue - at the bottom of the screen. The yellow field denotes the next group and the blue field denotes next block.

  • Page 61: Viewing The Picture-In-Picture

    Viewing the Picture-in-Picture Move key : Move the position of PIP window Left Up Right Up(Start) Left Down Right Down Swap key : Swap the sources of the main screen and PIP window. MODE KEY : Change the PIP window mode. SMALL LARGE TWIN...

  • Page 62: Specification

    Specification 42” Plasma TV Display Panel Function and Specification Display Size 42-Inch 16 : 9 Diagonal Screen Display Mode Variable 4 Modes (4:3 Mode/ 16:9 X 3 Modes) Pixel Format 852 X 480 Physical Pixel Contrast Ratio 3000 : 1 Brightness 1000 cd/m Resolution (RGB)
  • Page 63 Specification 50” Plasma TV Display Panel Function and Specification Display Size 50-Inch 16 : 9 Diagonal Screen Display Mode Variable 4 Modes (4:3 Mode/ 16:9 X 3 Modes) Pixel Format 1366x768 Physical Pixel Contrast Ratio 900:1 Brightness 800 cd/m Resolution (RGB) 1366 X 768 / 50,60Hz Advanced multi-windows viewing PIP(picture in picture) with four selectable window positions on Video mode...

  • Page 64: Troubleshooting

    Troubleshooting Before you call a service technician, please scan this list of problems and possible solutions. It may save you time and money. Problem Quick Action for Possible Solution No picture & No sound Check whether the Monitor is turned on. Power cord inserted into wall outlet? Plug another product’s power cord into the wall outlet where the Monitor’s power cord was plugged in.

  • Page 65: Warranty Card
