Limited Warranty
Products for Home Use
Manufacturuer (Seller) warrants to the original Buyer only, that each product will be free from defects in
material and workmanship for a period of one (1) year from date of purchase. SELLER'S SOLE
OBLIGATION AND BUYER'S EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE
THE REPAIR OR REPLACEMENT OF PARTS, WITHOUT CHARGE, WHICH ARE DEFECTIVE IN
MATERIAL OR WORKMANSHIP. ANY PARTS AS DETERMINED BY THE SELLER WHICH HAVE BEEN
MISUSED; ABUSED OR DAMAGED EITHER DIRECTLY OR INDIRECTLY FROM REPAIRS OR
ALTERATIONS ATTEMPTED BY UNAUTHORIZED PERSONS; IMPROPER MAINTENANCE, NEGLECT
OR ACCIDENT ARE NOT COVERED BY THIS LIMITED WARRANTY. This warranty does not apply to
damage, heat-induced coloration changes, scratching or alteration due to normal use or weathering. To
make a claim under this Limited Warranty, you must return the complete product with proof of purchase,
transportation prepaid, to any Manufacturuer's authorized service center. Call 1-888-424-3354 for the
location of the nearest authorized service center.
Additional Limitations
THIS LIMITED WARRANTY DOES NOT APPLY TO ACCESSORY OR CONSUMABLE ITEMS RELATED
TO THIS PRODUCT. ALL IMPLIED WARRANTIES SHALL BE LIMITED IN DURATION TO ONE (1) YEAR
FROM DATE OF PURCHASE. IN NO EVENT SHALL SELLER BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO LIABILITY FOR LOSS OF PROFITS,
ARISING FROM THE SALE OR USE OF THIS PRODUCT.
If any provision of this Limited Warranty is for any reason held to be invalid or unenforceable, such
provision shall not affect any other provision herein, this Limited Warranty shall be construed as if such
invalid and/or unenforceable provision had never been contained herein.
This Warranty contains the entire agreement between Seller and Buyer and supersedes any and all
prior agreements, arrangements, or understandings between the parties relating to product warranty.
IF YOU HAVE ANY PROBLEMS OR QUESTIONS CONCERNING THIS PRODUCT,
DO NOT RETURN IT TO YOUR RETAILER, CONTACT CUSTOMER SERVICE AT
1-888-424-3354.
NOTE: This product is intended for residential, non-commercial use.
Due to ongoing product development
the actual product or products may vary from
the illustrations or photos shown within this manual.
Technical Data
Type/Model
Scroll Saw
Throat Depth
Blade Length
Max Cutting Depth
No Load Speed
Table Tilt
Manufactured in China for
Ace Hardware Corp.
Oak Brook, Illinois 60523, USA©2009
200409rev1
www.acehardware.com
2205375/60701040
16 in. (406 mm)
5 in. (127 mm)
2 in. (55 mm)
400-1600 SPM (Strokes per min)
0-45 degrees to the left
16" Scroll Saw
Instruction Manual
Ace No. 2205375
Model No: 60701040
Read the instructions and precautions before use of this product
Model No. 60900015
Please keep this instruction manual for future reference
IF YOU HAVE ANY PROBLEMS OR QUESTIONS CONCERNING THIS PRODUCT,
DO NOT RETURN IT TO YOUR RETAILER, CONTACT CONSUMER SUPPORT AT
1-888-424-3354
IF YOU ARE A STORE MANAGER OR EMPLOYEE IN NEED OF ASSISTANCE CALL
1-888-851-5569
PLEASE HAVE YOUR STORE NUMBER READY
OR
Advertisement
Table of Contents
Summary of Contents for Ace 16" Scroll Saw
-
Page 1: Technical Data
NOTE: This product is intended for residential, non-commercial use. Due to ongoing product development the actual product or products may vary from the illustrations or photos shown within this manual. Technical Data Ace No. 2205375 Type/Model 2205375/60701040 Scroll Saw Model No: 60701040 Throat Depth 16 in. -
Page 2: General Safety Rules
GENERAL SAFETY RULES TROUBLESHOOTING WARNING: To prevent the saw from starting accidentally and causing serious injury, turn off WARNING! READ AND UNDERSTAND ALL INSTRUCTIONS. Failure to follow all instructions listed and unplug the saw before carrying out any maintenance work on the saw. below may result in electric shock and/or serious personal injury. -
Page 3: Electrical Safety
Arm Bearing (Figure 15) ELECTRICAL SAFETY Figure 15 1. Lubricate the arm bearings after the first 10 hours of use. Oil them every 50 hours of use Grounding Instructions or whenever the bearing squeaks. 2. Carefully place the saw on its side as shown 1. -
Page 4: Specific Safety Rules For Scroll Saw
Stack Cutting (Figure 14) SPECIFIC SAFETY RULES FOR SCROLL SAW Figure 14 Stack cutting may be used when several identical shapes need to be cut. WARNING! For Your Own Safety Read Instruction Manual before Operating Saw Several workpieces (2) may be stacked one on 1. -
Page 5: Glossary Of Terms
Blade Information GLOSSARY OF TERMS Scroll blades wear out and must be replaced frequently for best cutting results. Scroll saw blades generally become dull after one half hour to 2 hours of cutting, depending on the type of material and speed of operation. Bevel Cut - A cut made with the saw table at any angle to the blade other then 90 degrees. -
Page 6: Know Your Tool
Jamming of the Saw Blade and Workpiece KNOW YOUR TOOL When backing out the workpiece, the blade may bind in the kerf (cut). This is usually caused by sawdust clogging the kerf or by the blade coming out of the blade holder. If this happens: Blade Tension Knob Figure 2 1. -
Page 7: Operation
Mounting the Scroll Saw to a Work Bench (Figure 4) OPERATION WARNING! To avoid serious personal injury from unexpected tool movement, securely mount the scroll saw onto a workbench.If the saw is to be used in a specific location, it should be WARNING: RISK OF PERSONAL INJURY. - Page 8 Squaring the Saw Table (Figure 6) Changing Blades (Figures 9 & 10) Figure 9 Figure 6 Scroll saw blades wear out quickly and must be 1. Loosen the drop foot lock knob (1) and move replaced frequently. Expect to break some blades the drop foot rod (4) all the way up.
