SpaceLogger
.S10
®
User Manual
For the latest information and support please go to our website
www.spacelogger.com
©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom
Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk
017SL167/3 04/09/13
Advertisement
Table of Contents
Summary of Contents for Richard Paul Russell SpaceLogger.S10
- Page 1 For the latest information and support please go to our website www.spacelogger.com ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk...
-
Page 2: Table Of Contents
WEEE (Waste, Electrical and Electronic Equipment) Statement ..................33 RoHS Statement ................................. 33 ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk... -
Page 3: Spacelogger .S10
Office applications (e.g. Notepad or MS Excel). The SpaceLogger.S10 will also output RS232 data to another device. Refer to section 5.15 for details. The logger requires a 7 - 30 volt DC supply which can be provided by an AC/DC mains adaptor or suitable battery. -
Page 4: Quick Start: Easy Steps To Data Logging
PC card reader SpaceLogger.S10 Figure 1 ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk - 3 - 017SL167/3 04/09/13... -
Page 5: Connecting
RS232 GND 1 Table 1 ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk - 4 - 017SL167/3 04/09/13... -
Page 6: Rs232 Interface
Note if it is required to drive a switch input directly from the user’s circuit the input signal must not exceed 3 volts. ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk... -
Page 7: Cable Preparation
All GNDs are common and so damage to the logger may result if they are connected to different voltages. ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk... -
Page 8: Setup Features
Please refer to Appendix A1 for full list of commands and the valid inputs for their values and the default settings. ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk... -
Page 9: Setting The Time & Date
If no time and date is set up on the SpaceLogger, the unit will emit a warning ‘Beep’ four times a minute as a reminder. ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk... -
Page 10: To Define The Data Sample(S) To Be Recorded
To Define the Data Sample(s) to be Recorded The SpaceLogger.S10 is capable of being used with any sensors that output their information in ASCII sentences. The format of the data must be 8 bits and no parity. It is also a requirement that each data record has identifying start and end characters to define the data sequence to be sampled. -
Page 11: To Enable Recording Of Second Data Sample
This second data sample (defined by STX2 and ETX2) will be appended to the first sample (defined by STX and ETX), rather than being independently time & date stamped. The SpaceLogger.S10 will only monitor for this second data sample once the first data sample has been detected. -
Page 12: To Select Whether The Stx And Etx Identifiers Are Logged
If p= N, the logger will not add a separating character ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk... -
Page 13: To Add A Line Break After Each Data Set
NEWLINE=Y. To Set a Timeout By default, when the SpaceLogger.S10 is set to sample data, it will expect to receive the appropriate STX, EXT, STX2 and ETX2 in that order. It will not be able to advance to monitor for the next data sample until each of the first set of identifiers have been detected and logged. -
Page 14: To Enable Logging From The Second Rs232 Input
The baud rate on RS232 Input 2 and RS232 Output 2 is fixed at 4800 bits per second. ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk... -
Page 15: To Select A Logging Interval
By default, the SpaceLogger.S10 will record every sample output by the attached sensor. If an alternative logging interval is required, the SpaceLogger.S10 may be set to record at a less frequent sample rate by using the following SETUP.TXT command line: RATE=r Where r is the time in seconds between sampling for the STX condition, as an integer. -
Page 16: To Customise File Names
Question marks (?) may be used to denote a space. ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk... -
Page 17: To Disable The Time-Stamp
If t = N, data will not be date & time stamped 5.14 To Record all Data (Disable Sampling) It is possible to disable the sampling function of the SpaceLogger.S10 and to record all data that is received on the RS232 input(s). -
Page 18: To Output Rs232 Data From The Spacelogger.s10
Should one of the connected devices require a handshake response to initiate data output, the SpaceLogger.S10 may be set to detect a message from the device defined by any one of the STX, ETX, STX2 or ETX2 conditions. One receipt of this message, the logger outputs the ASCII string defined by command RESPONSE. - Page 19 \v = 0x0B The default setting is RESPONSE=“Q”. The response to the handshake is output by the SpaceLogger.S10 on RS232 Output 1 by default, unless the logger has been set up to output RS232 data using command OUTPUT=L or I. If data has been set to output on RS232 Output 1, the response to handshake will be output on RS232 Output 2 instead.
-
Page 20: To Record Unprintable Ascii Characters
Refer to section 4.2 and 4.4 for details of connecting the digital I/O terminals. ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk... -
Page 21: To Output A File's Content To Rs232 Output On Card Initialisation
RS232 Input 1. By default the input is RS232 logic compatible. To set the SpaceLogger.S10 to invert the logic of the received signal command RX_INV is used. RX_INV = Y Logic inverted on received signal on RS232 Input 1 RX_INV = N Signal not inverted on RS232 Input 1 The default setting is RX_INV=N. -
Page 22: Resetting The Spacelogger.s10 To Default Settings
HANDSHAKE=N RESPONSE=“Q” RAW=N SWITCH=N STARTUP=N RX_INV=N ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk - 21 - 017SL167/3 04/09/13... -
Page 23: Setup.txt File
5. Comments may be added to the SETUP.TXT file using //. The SpaceLogger will not read any text following // until the end of the line. ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk... -
Page 24: Notes On Saving File Setup.txt
With Windows and Vista it is beneficial to have File Extensions visible when viewing documents in Explorer. ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk... -
Page 25: Logging
SpaceLogger is compatible with SD cards up to 2GB capacity but not SDHC cards. MMC and MMC mobile cards up to 2GB capacity are also compatible. ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk... -
Page 26: Data Transfer
When the memory card becomes full the SpaceLogger will stop logging data; it will not overwrite files already saved. ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk... -
Page 27: Spacelogger.s10 Specification
Supply input protection Polarity reversal protected and internal re-settable fuse – 140 mA Connection 1.3 mm centre pin DC connector, or ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk... - Page 28 Enclosure protection IP203 Guarantee Period 1 year (refer to Appendix) ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk - 27 -...
-
Page 29: Appendices
NEWLINE Adds <CR><LF> to end of each data sample ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk - 28 -... - Page 30 Controls logic inversion of the received data RESET Returns logger to default settings ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk - 29 -...
-
Page 31: A2 Ascii - American Standard Code For Information Interchange
Value Hex Character Value Hex Character Value Hex Character ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk - 30 -... -
Page 32: A3 Guarantee
Richard Paul Russell Ltd’s liability is limited to items of its own manufacture, and it does not accept liability for any loss resulting from the operation or interpretation of the results from this equipment. -
Page 33: A4 Electromagnetic Conformity
New Harbour Building, Bath Road Lymington SO41 3SE, UK ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk - 32 -... -
Page 34: Weee (Waste, Electrical And Electronic Equipment) Statement
Polybrominated diphenyl ether (PBDE) PBB and PBDE are flame retardants used in some plastics. ©2012-13 Richard Paul Russell Limited, New Harbour Building, Bath Road, Lymington SO41 3SE United Kingdom Tel +44 (0) 1590 679755 Fax +44 (0) 1590 688577 e-mail sales@r-p-r.co.uk web www.r-p-r.co.uk...
