COMPREHENSIVE INTERNET SECURITY
™
b
SonicWALL Internet Security Appliances
Secure Anti-Virus Router 80 Wireless
Getting Started Guide

Advertisement

Table of Contents
loading

Related Manuals for SonicWALL SAVR 80

Summary of Contents for SonicWALL SAVR 80

  • Page 1 COMPREHENSIVE INTERNET SECURITY ™ SonicWALL Internet Security Appliances Secure Anti-Virus Router 80 Wireless Getting Started Guide...
  • Page 2 SonicWALL Secure Anti-Virus Router 80 Wireless Getting Started Guide Thank you for your purchase of the SonicWALL Secure Anti-Virus Router 80 Wireless, the ultimate security platform for home and small office deployments. With integrated support for SonicWALL's Gateway Anti-Virus, the SonicWALL Secure Anti-Virus Router 80 Wireless delivers powerful, yet easy-to-use protection against hackers and viruses.
  • Page 3 Document Contents This document contains the following sections: Completing Pre-Configuration Tasks - page 3 Registering Your SonicWALL - page 9 Connecting for Initial Setup - page 11 Running the Setup Wizard - page 17 Connecting to Your Network - page 23...
  • Page 4 Completing Pre-Configuration Tasks In this Section This section provides pre-configuration information. It is necessary to review this section before setting up your SonicWALL Secure Anti-Virus Router 80 Wireless. • System Requirements section, on page 4 • Check Package Contents section, on page 5 •...

  • Page 5: System Requirements

    Before you begin the setup process, check to ensure that you have a computer that meets the following requirements. This computer is used to manage your SonicWALL Secure Anti-Virus Router 80 Wireless during the setup process. • Windows XP, Windows 2000, or Windows NT •...

  • Page 6: Check Package Contents

    Standard power adapter SonicWALL Resource CD Ethernet Cable wlan wan opt on/act link/act WiFiSec 10/100 SAVR 80 w i r e l e s s SonicWALL Resource CD SonicWALL Secure Anti-Virus Router 80 Wireless Getting Started Guide Page 5...
  • Page 7 SonicWALL appliance. Networking Information LAN IP Address: Select a static IP address for your SonicWALL appliance that is within the range of your local subnet. If you are unsure, you can use the default IP address (192.168.168.168).
  • Page 8 Subnet Mask: Cable or DSL with Default Gateway a static IP (Router IP Address): Primary DNS: Secondary DNS (optional): Dial-in to a server PPTP Server Address: User Name: Password: SonicWALL Secure Anti-Virus Router 80 Wireless Getting Started Guide Page 7...
  • Page 9 Page 8 Obtain Internet Service Provider (ISP) Information...
  • Page 10 Registering with MySonicWALL.com section, on page 10 Note: Product registration is an important part of the setup process, allowing you to enable product support, firmware updates and other key features. SonicWALL Secure Anti-Virus Router 80 Wireless Getting Started Guide Page 9...
  • Page 11 If you do not yet have a mysonicwall.com account, point your web-browser to <http://www.mysonicwall.com/> to register before continuing. Locate and record your SonicWALL Secure Anti-Virus Router 80 Wireless Software Serial Number and Authentication Code. This information is printed on the bottom panel of the appliance.
  • Page 12 Connect WAN Port to the Internet section, on page 14 • Connect the Computer to the LAN (1) Port section, on page 14 • Verify WAN / LAN / WLAN Connection section, on page 15 SonicWALL Secure Anti-Virus Router 80 Wireless Getting Started Guide Page 11...
  • Page 13 Adjust the antennas to meet your space / signal requirements. Console Power Apply Power Connect the AC plug to the power supply. Plug one end of the power supply to the back of the SonicWALL Secure Anti-Virus Router 80 Wireless. Page 12 Connect Antennas...
  • Page 14 When the Test LED is no longer lit, the SonicWALL Secure Anti-Virus Router 80 Wireless is ready for configuration. If the Test LED stays lit for more than a few minutes, cycle power to the appliance.
  • Page 15 Connect WAN Port to the Internet Using a standard network cable, connect the WAN port of the SonicWALL Secure Anti-Virus Router 80 Wireless to your gateway device (usually your cable/DSL modem or T1 router). Console Power SonicWALL Secure Anti-Virus Router 80...
  • Page 16 Verify WAN / LAN / WLAN Connection Once the cables are correctly connected, the WAN, LAN (1) and WLAN lights on the front panel of your SonicWALL Secure Anti-Virus Router 80 Wireless illuminate as illustrated below: Link/ACT (WAN / 1) - Indicates a network...
  • Page 17 Page 16 Verify WAN / LAN / WLAN Connection...

  • Page 18: Running The Setup Wizard

    Running the Setup Wizard In this Section This section provides instructions to log in and configure your SonicWALL Secure Anti-Virus Router 80 Wireless using the SonicWALL Setup Wizard. • Log into the Web Management Interface section, on page 18 •...
  • Page 19 Log into the Web Management Interface Your SonicWALL Secure Anti-Virus Router 80 Wireless employs the use of a Web-based management interface for setup and configuration. Complete the following steps to log into the management interface. In a Web browser on the computer, navigate to http://192.168.168.168 (the default IP address of the SonicWALL Secure...
  • Page 20 Local Area Connection settings. • Do you have the Ethernet cable connected between your computer and the LAN (1) port on your SonicWALL Secure Anti-Virus Router 80 Wireless? • Do you need to add the SonicWALL Secure Anti-Virus Router 80 Wireless to your list of trusted sites? Use the default IP address (192.168.168.168) for this purpose.
  • Page 21 SonicWALL Setup Wizard If the Setup Wizard does not display upon initial log into the SonicWALL Secure Anti-Virus Router 80 Wireless management interface, click the Wizards button in the left-hand navigation panel of the interface. Select Setup Wizard radio button and click the Next button to continue.
  • Page 22 Verify Management Interface Connectivity If your SonicWALL did not require a restart, skip to the Verify WAN (Internet) Connectivity section, on page 22. Otherwise, continue with step 2 Wait for the SonicWALL Secure Anti-Virus Router 80 Wireless to reboot. When the Test LED is no longer lit, the SonicWALL Secure Anti-Virus Router 80 Wireless is ready for login.
  • Page 23 • Is your computer set to accept DHCP addressing or, if using static IP addressing, it your IP address set to a range within the SonicWALL’s LAN subnet? • Is your SonicWALL WAN port connected to your Internet source and showing (link/act, 10/100) activity? •...

  • Page 24: Connecting To Your Network

    Connecting to Your Network In this Section This section provides SonicWALL Secure Anti-Virus Router 80 Wireless basic network connectivity verification and examples. • Connect and Configure Your Network section, on page 24 • The Front Panel section, on page 25 •...
  • Page 25 Congratulations! You have successfully completed set up of your SonicWALL Secure Anti-Virus Router 80 Wireless. For more detailed information on your SonicWALL Secure Anti-Virus Router 80 Wireless feature set, refer to the latest version of the SonicOS Standard Administrator’s Guide.

  • Page 26: The Front Panel

    (on/act) Solid indicates the wireless radio is powered on, blinking indicates wireless activity. (WiFiSec) Indicates WiFiSec wireless secuity is operational. The OPT Port is not a supported feature on the SonicWALL Secure Anti- Virus Router 80 Wireless. Indicates a device link, activity and connection speed on your WAN port.

  • Page 27: The Back Panel

    Antenna Provide (2) connection points for the included wireless antennas. Connections Console Port Provides a console connection to the SonicWALL. This feature is not supported on the SonicWALL Secure Anti-Virus Router 80 Wireless. WAN Port Provides a connection between your SonicWALL Secure Anti-Virus Router 80 Wireless and the Internet, usually connecting through a modem or router.
  • Page 28 Double-click TCP/IP in the TCP/IP Properties window. Select Obtain an IP address automatically. Click OK, and then click OK again. Restart the computer for the changes to take effect. SonicWALL Secure Anti-Virus Router 80 Wireless Getting Started Guide Page 27...

  • Page 29: Cable Connections

    Lithium Battery Warning Mount in a location away from direct • The Lithium Battery used in the SonicWALL sunlight and sources of heat. A maximum security appliance may not be replaced by the ambient temperature of 104º F (40º C) is user.
  • Page 30 Produkt darf nur in Verbindung mit einem nach den Normen der Underwriter Laboratories, USA als „UL-gelistet“ zugelassenen Netzteil der Kategorie „Class 2“ oder „LPS“ verwendet werden. Ausgang: 12 VDC Gleichsspannung, mind. 1,66 A. SonicWALL Secure Anti-Virus Router 80 Wireless Getting Started Guide Page 29...
  • Page 31 *Refer to the label on the bottom of the unit for device information including Class A or Class B FCC information. North American Authorized Channels SonicWALL declares that the APL17-049 (FCC ID: QWU-049) (IC: 4408A-049) when sold in US or Canada is limited to CH1~CH11 by specified firmware controlled in the USA. FCC RF Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
  • Page 32 All products with country code “” (blank) and “A” are made in the USA. All products with country code “B” are made in China. All products with country code "C" or "D" are made in Taiwan R.O.C. SonicWALL Secure Anti-Virus Router 80 Wireless Getting Started Guide Page 31...
  • Page 33 In oor Onl innen lecht int rieur Seulement Innen Nur ell interno Soltanto In oor Somen te e interior Solamente Page 32 Appendix B: Safety Instructions and Regulatory Information...

  • Page 34: Copyright Notice

    Firefox is a trademark of the Mozilla Foundation. Other product and company names mentioned herein may be trademarks and/or registered trademarks of their respective companies and are the sole property of their respective manufacturers. SonicWALL Secure Anti-Virus Router 80 Wireless Getting Started Guide Page 33...
  • Page 35 Notes Page 34 Notes...
  • Page 36 Notes SonicWALL Secure Anti-Virus Router 80 Wireless Getting Started Guide Page 35...
  • Page 37 Notes Page 36 Notes...
  • Page 38 F +1 408.745.9300 PN: 232-000770-00 Rev B 3/07 ©2007 SonicWALL, Inc. is a registered trademark of SonicWALL, Inc. Other product names mentioned herein may be trademarks and/or registered trademarks of their respective companies. Specifications and descriptions subject to change without notice.
