Summary of Contents for Apollo GEM Wireless Extender
-
Page 1: Wireless Extender
Wireless Extender User & Installation Manual Revision 1 September 2013 UD9039-V01 Apollo Solar Electric Limited Burnt Thorns Kilsby Lane Rugby CV21 4PN Tel: +44 (0) 1788 511055 Fax: +44 (0) 1788 511078 service@apollosolarelectric.co.uk... -
Page 2: Table Of Contents
Contents Important Safety Information Introduction The GEM Wireless Extender Positioning Commissioning Pairing with the GEM Transmitter Pairing with the GEM Controller Page 2... -
Page 3: Important Safety Information
Safety Information Warranty Apollo Solar Electric Ltd. has made every effort to ensure the accuracy of the content of this manual. However, it is possible that it may contain technical inaccuracies or typographical or other errors. Apollo Solar Electric Ltd. will assume no liability for any inaccuracy found in this publication, nor for damages, direct, indirect, incidental, consequential or otherwise, that may result from such an inaccuracy. -
Page 4: Introduction
GEM User Manual Introduction The GEM wireless extender can be used where it is required to extend the range of the standard GEM wireless system. For most installations the range of the standard wireless GEM system will be adequate. However in situations where a greater distance between the GEM wireless sensor... -
Page 5: The Gem Wireless Extender
GEM User Manual The GEM Wireless Extender Green Receive LED Orange Transmit LED Recessed pairing button LED Functions RX LED TX LED Description Mode Pairing mode scanning for Transmitter RX-TX Quick Flashing Alternately RX Flashing Slowly Waiting for Transmitter Signal... -
Page 6: Positioning
GEM User Manual Positioning The GEM wireless extender is typically placed mid way between the GEM sensor transmitter and the GEM controller and is simply plugged into a convenient spare 13A socket outlet in the desired area. There are no hard and fast rules regarding placement of the unit and some trial and error may be required to find the best location. -
Page 7: Commissioning
GEM User Manual Commissioning Commissioning essentially comprises two operations: Pairing the extender with the GEM transmitter Pairing the GEM Controller with the extender. Pairing with the GEM Transmitter When the unit is first powered up the factory default will cause it to be in pairing mode. This is indicated by both LEDs quick flashing alternately. -
Page 8: Pairing With The Gem Controller
The GEM controller should now display [Finding New Sensor] on the bottom line of the display. Now turn off the GEM wireless extender and turn it back on again. The wireless extender will now transmit its “find me” signal for 5 minutes.
