- Page 2 Thank you for purchasing our player! To get to know your player, please carefully read through this manual in its entirety. While writing this manual, we aim to be as accurate as possible, providing you with reliable information. However, if you find any mistakes or omissions, please feel free to contact us with your comments.
- Page 3 No drivers required for windows 2000 or later operating systems Built-in rechargeable Lithium ion battery Your Genesis player uses a built in, rechargeable, Lithium Ion battery. To charge the battery, first turn the ON/OFF switch on the top of the player to the ON position and connect it to your computer's USB port.
- Page 4 Description Description LCD Display II Button Power OFF/ON Switch MODE Button USB Jack VOL- Button Phones Jack VOL+ Button PREV Button NEXT Button 0:03:12 S/N Description Description EQ Mode Lyric Indicator Repeat Mode Bitrate of current Track Volume Level Elapsed Time Battery Meter Elapsed Time of Current Track Total Numbers of Tracks...
- Page 5 1) Power on: Set the ON/OFF switch to the ON position, and press and hold the [>II] (play/stop) button for 3 seconds. 2) Power off: Press and hold the [>II] (play/stop) button for 5 seconds, until the player powers off. You can then set the ON/OFF switch to the OFF position.
- Page 6 Music mode allows you to listen to your music files. To access music mode, use the [PREV] or [NEXT] buttons to select “Music” on the main menu and press [MODE] . NOTE- To return to the main menu, you must pause the music before holding the [MODE] button When in the music mode, the player will display the first song you have loaded on the player.
- Page 7 Repeat- Repeat allows you to adjust the playmode. Select from Normal, Repeat One, Folder, Repeat Folder, Repeat All, Random, and Intro. Equalizer- Natural, Rock, Pop, Classic, Soft, jazz, and DBB SRS WOW mode- Allows you to adjust your SRS WOW settings Tempo- Allows you to adjust the song speed Replay mode- Allows you to set the A-B repeat mode.
-
Page 8: Movie Mode
your .lrc file “goodbyes.lrc” and put it in the same folder as the music file. You can obtain .lrc files from many places on the web. You can also create your own .lrc files using a program called LRC editor 4. You can download this program at www.machspeed.com/drvrs/LRC_Editor_4.zip If a song has a lyric file associated to it, the ball next to “LYRIC”... -
Page 9: Record Mode
to make your selection. If the file is in a folder, you will see “/” at the top of the screen, select this and press [MODE] to leave the current folder and go up one folder level. Delete all- Allows you to delete all of the music files in the player. Repeat- Allows you to adjust the playmode. -
Page 10: Voice Mode
Recording submenu Local folder- Allows you to select which folder you want to save voice recordings in. the default location is the “Voice” folder on the player. REC Type- Allows you select the recording type Fine REC- 32k/WAV: used to make quality voice recordings Long REC- 8k/ACT: Used to make long recordings, uses less disk space Fine VOR- 32k/VOR: Used to make Quality voice recordings, the mic... -
Page 11: Picture Browsing
Repeat- Repeat allows you to adjust the playmode. Select from Normal, Repeat One, Folder, Repeat Folder, Repeat all, Random, and Intro. Tempo- Allows you to adjust the file speed Replay mode- Allows you to set the A-B repeat mode. Once this is selected, you will be returned to your file. - Page 12 When you first enter the picture browser, a list of the pictures on your player will be displayed. Use [PREV] and [NEXT] to highlight the picture you would like to view, and press [>II] to display the picture, or press [MODE] to enter the picture submenu.
- Page 13 Note- Optimal viewing size for this player is 128*128 resolution. Larger files will take longer to load, and may experience a loss of quality or completely fail to load. Setup Setup allows you to customize your player. To access Setup, use the [PREV] or [NEXT] buttons to select “Setup”...
- Page 14 Replay Mode- Allows you to set manual or Auto play. When in manual, you will have to use [NEXT] or [PREV] to advance to the next or previous file in music, movie or photo mode. Online Mode- Allows you to set the method your computer recognizes the player.
- Page 15 When you first enter the E-Book reader, a list of the files on your player will be displayed. Use [PREV] and [NEXT] to highlight the file you would like to view, and press [>II] to display the file, or press [MODE] to enter the file submenu.
- Page 16 Open Windows Media Player and connect the MP3 player to a working USB port. Windows Media player will prompt you with a setup screen asking you to name the MP3 player Once you have named your MP3 player, select Finish, and your Windows Media Player will open to the Sync tab.
- Page 17 Windows Media player will load the songs on to your MP3 player. Once all the songs you have added are synced to the unit, and Windows Media Player says that is safe to disconnect your MP3 player, disconnect the device.
- Page 18 Copy and paste: 1. Connect the MP3 player to a working USB port When the player is connected to your computer, it will create a gray and green icon in the system tray (lower right hand corner of your desktop). The icon will be called safely remove hardware.
- Page 19 Locate the drive created by the unit, generally just called Removable Disk, with a letter in parenthesis. Drive letters vary depending on your system configuration. Open the drive by either double left clicking on the drive itself, or by right clicking on the drive, then left clicking on the “Open”...
- Page 20 Once you have located the song files, you can right click on the song itself, and select “copy”. Open the disk drive, right click on the empty space, and select “Paste”. This will transfer the song on to your MP3 player Repeat step 7 for as many songs as you want to copy on to the unit.
- Page 21 Disconnecting the Player from your computer Before disconnecting your player from your computer, It is important to properly eject the player using the “safely remove hardware” feature of your windows operating system. 1. Left click on the gray and green icon in the system tray (lower right hand corner of your desktop).
- Page 22 WINSE/ME/2K/XP, MacOS10.Linux2.4.2 (Only WIN98 needs the CD driver)
- Page 23 Caution Modifications not approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE- This equipment has been tested and found to comply with the limits for Class B Digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
