  • Page 2: Table Of Contents

    Assembly Instructions .10. Setup Sheet .36. Exploded View .38. Parts List - Standard Parts .40. Parts List - Option Parts .41. Team Durango Ltd .43. Inhaltsverzeichnis Herzlichen Glückwunsch Einführung Bevor Sie anfangen Zusammenbau Sicherheitswarnungen – WICHTIG Symbol Schlüssel Montage Anleitung .10.
  • Page 3 • Alloy bulkheads and shock mounts • Revolutionary disk brake system • Adjustable chassis-flex system • Quick-release differentials • Ultra-low Centre Of Gravity • Memory engine mount • Ultra-slim chassis design • Vented receiver box • Quick-release radio plate If you are ‘Serious About Racing’, then you have the right car – Team Durango DNX408 Team Durango ha empleado el último año en desarrollar el DNX408. El DNX408 es el 1/8 todo terreno gas de competición definitivo, construido con una tecnología innovadora vencedora en competición, ingeniería precisa, y un diseño sin concesiones que ofrece como estándar las siguientes características: • Manguetas y soportes de amortiguador de aleación • Revolucionario sistema de freno de disco • Chasis de flexibilidad ajustable con el sistema “chassis-flex” • Diferenciales de extracción rápida • Centro de gravedad ultra-bajo • Memoria de posición de montaje del motor • Chasis con diseño ultra-estrecho • Caja de receptor ventilada • Bandeja de radio de extracción rápida...

  • Page 4: Before You Begin

    If, for any reason, you decide that you do not want your DNX408, you must not begin assembly. Your DNX408 cannot be returned to your Team Durango dealer for a refund or exchange if it has been fully or partially assembled.
  • Page 5 Assembly Zusammenbau 組立て前に 组装 Contained in your DNX408 box are different parts bags. Each bag is marked with a letter. Within each bag are all the parts required to complete a build-stage of the kit. As noted in ‘Before you begin’ (above), you must ensure that you only open one bag at a time, following the correct sequence of assembly.
  • Page 6 Please read this manual carefully to understand which ancillary items (tools, electrics, electronics etc) are used with this kit. Team Durango Ltd accept no responsibility for the operation of any such ancillary items. It is entirely the owner’s responsibility to ensure this product is in good working order before operation.

  • Page 7: Team Durango Ltd

    安全のために –重要！ このキットは玩具ではありません 本製品の推奨年齢は14歳以上です。13歳以下のお子様が組立・ご使用になる場合には必ず保護者の監督・ 補助の元で作業を進めてください。 本製品は高性能な競技用のラジオコントロールカーです。使用方法を誤りますと怪我をする恐れがありま す。 Team Durango Ltdは本製品を組立中、使用中に発生したいかなる怪我に対して責任を負うものではあ りません。 本製品はサーキット走行向けにデザインされており公共の場所（公園・駐車場等）での走行には適しませ ん。 組立前に本マニュアルをお読み頂き、どのような工具・パーツが必要か理解して下さい。Team Durango Ltdは組立時に使用した工具等によるいかなる怪我・損害に対して責任を負うものではありません。 走行前には必ず本製品のチェックを行い、安全を確認してから走行を開始してください。R/Cカーの走行は 全てお客様の責任の元に行ってください。 本製品は多数の小さなパーツを含んでおり、誤飲しますと窒息の可能性があり大変危険です。組立の際に は必ず小さなお子様の手の届かない場所で作業してください。 本製品に含まれる液体・その他は飲物ではありません。万が一これら（ショックオイル、デフグリス等） を誤飲した場合にはすぐに医師の診察を受けてください。一部の液体は可燃性です。火気・炎を近づけた り投げ入れたりしないでください。Team Durango Ltdはキットに含まれるパーツや液体等で負ったいかな る怪我・損害に対して責任を負うものではありません。 回転しているパーツには怪我をする恐れがありますので絶対に触れないでください。 R/Cカーが視界の外に行った場合や薄暗い明りの元での走行は危険ですのでおやめください。視界の悪い状 態で走行を続けますと走行中のR/Cカーを破損したり、他人に怪我を負わせたり、器物を破損する危険があ りますのですぐに走行を中止してください。 R/Cカーの走行中は外部から発せられた電波等によりR/Cカーがコントロールを失う危険性が常にありま す。R/Cカーの走行中は常に電波障害発生の危険性を考慮しながら走行してください。 安全须知–重要！ 本产品非玩具类商品 本产品不适用于十四岁以下儿童，若您的年龄或者使用者是低于十岁以下的儿童，请确认在任何组装与操作时，有成年 人陪同以防任何不慎造成遗憾。 本产品为高性能的遥控竞速模型，因于产品特性，若操作或使用不当时，可能引发对人体的伤害。Team Durango对于任 何不当组装或操作上造成的意外不具任何责任。 本产品为专对遥控车模型赛道开发的竞赛车种。请勿在一般的开放地使用本产品。Team Durango对于任何不当使用上造...

  • Page 8: Symbol Reference Key

    Symbol Reference Key Symbol Schlüssel シンボルリファレンス 说明书符号说明 The symbols below are used are various stages throughout the build of your kit. Paying close attention to these symbols, and following them properly, will ensure your kit is built properly. Die untenstehenden Symbole werden Sie in den verschiedenen Baustufen wiederfinden. Bitte achten Sie auf diese Symbole und folgen Sie den Anweisungen, um einen korrekten Zusammenbau Ihres Modells zu gewährleisten.
  • Page 9 Required items (not included in k it) En gi ne L i -P O / L i F E B atte r y G low P lu g G low plu g Wrench N i M H B at ter y Trans mi t te r R ecei ve r Nee dl e no se P li ers...
  • Page 10 210018 210017 310090 210016 310083 PIN 2.5x11.8 210016 210018 x2 602003 709022 709022 602003 210018 310082 BB 8x14x4 602003 x2 210016 210016 S 8x10x0.1 210017 709022 x2 704003 704003 DIFF PINION SHAFT 210017 x2 210017 210017 210017 210017 DIFF PINION GEAR 10T 210017 x4 210017 210017...
  • Page 11 704003 704003 DIFF PINION SHAFT 210017 x4 210017 210017 210017 DIFF PINION GEAR 10T 210017 210017 x8 210017 210017 210017 210017 CM M3x12 704003 x8 210017 Differential Oil Front 70000CST # TD390032 Rear 20000CST # TD390004 210022 BB 10x15x4 601003 x4 210022 310063 601003...
  • Page 12 701012 330070 330133 330122-11 330122-11 330117 330133 701012 330104 330122-11 (1.3mm) x2 330133 330117 330104 SETSCREW M4x12 330069 701012 x2 330133 A-ARM PIN 59mm 330104 x2 SH M3x8 704028 x4 320010 704028 704028 704028 704028 Thread Lock 320011 320022 CS M3x10 704007 x4 330087 704007...
  • Page 13 SH M3x8 704028 x4 704028 704028 Thread Lock 704028 704028 CS M3x8 704006 x2 704024 704024 SH M3x16 704024 704024 x4 704024 310093 704006 704006 320028 Thread Lock 701012 330072 330118 330133 330133 330122-10 330122-10 701012 330104 330122-9 (2.0mm) 330122-9 (2.0mm) x2 330122-9 330133 (2.0mm)
  • Page 14 SH M3x10 704009 x4 SH M3x8 704028 x2 Tuning tip 3/3 Inserts give 3° toe-in and 3° kick up 3/2 Inserts give 3° toe-in and 2° kick up 704028 704009 704028 704009 704009 Thread Lock 704009 320012 SH M3x10 320014 704009 x2 330086 SH M3x16...
  • Page 15 BH M3x8 705002 x2 SH M3x10 704009 x4 330079 705002 705002 704009 704009 704009 Thread Lock 704009 210020 Front 310065 310066 210018 DRIVESHAFT BUSHING 210020 x2 310059 CVD BOOT 9 4 mm 310059 x2 DRIVESHAFT FRONT 310066 x2 Gear Grease PIN 2.5x11.8 210018 x2 210020...
  • Page 16 330106 701009 210028 330119 PIN 4x18 701003 330106 x4 S 13.0x16.0x0.1 BB 12x18x4 709023 X4 601007 X2 330131 709022 310087 PIN 3x16.9 310087 x2 601005 701003 709023 601007 SETSCREW M3x5 701003 x4 BB 8x16x5 601005 X2 701009 x2 330106 Note: Make 2 sets - 1 Left & 1 Right Thread Lock S 8x10x0.1 709022 x2...
  • Page 17 715002 A-ARM PIN REAR SHORT 330105 x2 330122 NUT M3 high 715002 x2 330105 330122 330075 ANTI ROLLBAR BALL 330074 x4 330074 330121 701005 (Short) ANTI ROLLBAR PIVOT BALL 330075 x4 330121 (Long) SETSCREW M3x10 701005 x4 SETSCREW M3x4 701002 x2 SETSCREW M3x3 701004 701004 x2...
  • Page 18 Optional Equipment 705002 705002 ANTIROLLBAR REAR 3,3MM TD330092 ANTIROLLBAR REAR 2,5MM 701002 TD330093 SETSCREW M3x4 701002 X2 701002 310093 310093 SETSCREW M3x3 701004 X2 330209 BH M3x8 701004 705002 X2 BH M3x18 705012 X2 705012 Thread Lock 715002 340013 715002 240002 240002 270004...
  • Page 19 704025 704025 CS M3x8 704006 x2 CS M3x10 704007 x2 704006 320027 715002 704006 SH M3x40 704025 x2 NUT M3 high 715002 x2 704007 Thread Lock 704007 .19.
  • Page 20 220004 REARSTIFFENER SHAFT 220004 x1 704003 220004 220004 220004 220004 715002 REARSTIFFENER BUSHING 220004 x2 330027 RUBBER BUSHING 220004 x2 704003 CS M3x12 704003 x2 CS M3x14 704013 x3 NUT M3 high 715002 x2 704013 704013 Thread Lock 704013 Front Camber Link 2 6mm 330121 330103...
  • Page 21 Rear Camber Link 330121 330121 Right Side Left Side PIVOTBALL A-TYPE 330073 x4 330102 330102 330073 330073 330121 330121 330073 330073 3 6 m m TIE ROD 64MM 330102 x2 Front Camber Link Installation BH M3x18 705012 x2 715002 BH M3x22 709011 705013 x2 SHIM A-TYPE...
  • Page 22 Steering Link Installation SH M3x16 704024 x2 BH M3x18 705012 x2 704024 SHIM A-TYPE 709011 x2 NUT M3 high 715002 x4 715002 705012 709011 715002 Rear Camber Link Installation BH M3x18 705012 x2 BH M3x20 705014 x2 705012 SHIM A-TYPE 709011 x4 715002 NUT M3 high...
  • Page 23 BH M3x14 705011 x2 705011 320027 320028 320028 320027 705011 705012 320028 705012 BH M3x18 705012 x4 320028 320028 NUT M3 high 715002 x2 715002 320028 715002 705012 705012 320028 704024 715002 SH M3x12 704024 704022 x2 SH M3x16 704024 x2 715002 704022 NUT M3 high...
  • Page 24 210029 210029 BRAKE BOLT SHORT 6x8 390011 x1 210029 701003 320091 210025 BRAKE BOLT LONG 6x13 310062 701003 390012 x1 310062 210025 210025 BRAKEPAD SPRING 210029 x4 210025 210025 210029 210025 320016 BRAKE SCREW M3x20 210029 x4 704007 210029 320015 310062 SETSCREW M3x5mm 701003 x2...
  • Page 25 Note: Make 2 Front and 2 Rear Front - Piston 'A' (1.3mm) Rear - Piston 'B' (1.4mm) 705016 Front 330080 x2 330111 330122 SHOCK PISTON SHIM 330111 x4 Rear 230018 330084 x2 330122 330122 330099 SHOCK CAP-B Front 330083 x4 330110 x2 330083 Rear...
  • Page 26 715002 330122 330101 712002 SHOCK MOUNT 330101 x2 715002 BH M3x16 705015 x2 PIVOT BALL BUSHING 712002 x2 NUT M3 high 705015 715002 x4 715002 330122 712002 330101 SHOCK MOUNT 330101 x2 715002 BH M3x16 705015 x2 PIVOT BALL BUSHING 712002 x2 NUT M3 high 715002 x4...
  • Page 27 Throttle Servo Steering Servo BH M3x10 340016 340016 705005 x8 340016 340016 SERVO SHIM 709007 x8 709007 709007 709007 709007 705005 705005 705005 705005 BH M3x10 705005 x4 340016 320018 340016 705005 705005 Note: Only required if servo touches radio plate. 705005 705005 290009...
  • Page 28 705006 705006 390002 320032 SETSCREW M3x4 705005 701002 x1 705005 390001 320032 CS M2x5 704046 x4 BH M3x6 705001 x2 290009 705015 BH M3x10 705005 x2 BH M3x5 705006 x2 330123 BH M3x16 701002 705015 x1 704046 704046 704046 704046 705001 705001 705005...
  • Page 29 704019 704019 704019 SH M2.5x6mm 704019 x3 705002 BH M3x8 705002 x2 705002 330123 Thread Lock CLUTCH SPRING 310159 x3 CLUTCH NUT 270002 x1 270002 310160 270002 CLUTCH SHOE 310161 x3 704009 704009 704009 704009 BALL BEARING FOR CLUTCH 601002 x2 SH M3x10 704009 x4 FLYWHEEL...
  • Page 30 CS M4x12 704037 x4 BH M3x5 705006 x2 ENGINE MOUNT SHIM 320019 709020 x4 709020 709020 704037 704037 705006 Thread Lock 704014 705002 704003 270003 320031 270003 FUELTANK BUSHING INSERT 270003 320031 270003 x2 270003 320027 705001 FUELTANK BUSHING 705001 270003 x2 320031 CS M3x12...
  • Page 31 MUFFLERSPRING HOLDER 290006 x1 701009 290006 MUFFLER SPRING 290006 290006 x1 SETSCREW M4x5 701009 x1 704026 SH M3x5 704026 x1 310098 310098 705012 330073 x2 709011 330121 BH M3x18 330114 Futaba Hitec KO Propo 330073 705012 x1 Sanwa SHIM A-TYPE 330121 715002 709011 x1...
  • Page 32 BH M3x6 705001 x1 BH M3x16 705015 x1 705015 715002 SHIM A-TYPE 709011 x1 709011 NUT M3 high 705001 715002 x1 330121 PIVOTBALL E-TYPE LONG 330108 330109 x2 PIVOTBALL J-TYPE 330116 x1 330121 Futaba Hitec KO Propo 330109 Sanwa PIVOTBALL I-TYPE 330121 330115 x1 330123...
  • Page 33 704003 704003 330122 330122 480002 CS M3x12 704003 x2 WHEELNUT 310043 x4 510006 510006 310043 310043 .33.
  • Page 34 290002 704006 290002 290002 CS M3x8 704006 x1 290002 290002 Ai r Fi l te r O i l 390007 402002 SNAP PIN 4mm 390007 x2 390007 .34.
  • Page 35 Further set-ups can be found online @:http://www.team-durango.com/in-the-pits.php .35.
  • Page 36 Further set-ups can be found online @:http://www.team-durango.com/in-the-pits.php .36.

  • Page 38: Exploded View

    Exploded View 704003 310093 210018 601005 310074 210017 210018 390002 210016 210017 210017 715006 210016 705005 701002 320032 330121 705015 705005 210017 330108 390001 210017 210017 320032 705005 210017 330121 330109 210016 290009 290009 210017 210016 705015 715002 705005 330121 210017 602002 210017 330109...
  • Page 39 704009 704006 290002 704009 290002 290002 704003 290002 290002 330122 270002 310159 310160 310161 709015 310157 601002 480002 310159 270002 310040 709015 709020 704003 601002 320014 320019 705005 709020 704037 220004 705012 220004 220004 704037 705006 320028 320027 715002 715002 220004 715002 220004...
  • Page 40 CLUTCH SHOE (3pcs) TD320010 CHASSIS PLATE (5mm) TD390017 GEAR GREASE TD390028 TURNBUCKLE WRENCH 4&5mm TD320011 FRONT BULKHEAD (RIGHT) TD402002 DNX408 CLEAR BODY SET TD320012 REAR BULKHEAD (LEFT) TD320014 REAR BULKHEAD (RIGHT) TD480002 REAR WING BLACK TD320015 MID DRIVE HOLDER FRONT TD490005...
  • Page 41 Par ts List- O ption Par ts Parts# Description TD701009 SET SCREW M4x5mm (10pcs) Parts# Description TD701012 SET SCREW M4x12mm (10pcs) TD704003 FLAT HEAD HEX CS SCREW M3x12mm (10pcs) TD230014 ANTI-ROLL BAR TUNING SET FRONT TD704004 FLAT HEAD HEX CS SCREW M3x6mm (10pcs) TD230019 SPRING TUNING SET FRONT (8 PAIRS) TD704006...
  • Page 42 .42.

  • Page 43: Team Durango Ltd

    Team Durango Ltd Team Durango Ltd Team Durango Ltd is registered in Derbyshire, Team Durango Ltd 登記住所：Derbyshire, England, England, UK Internet: ウェブサイト: www.team-durango.com www.team-durango.com support@team-durango.com support@team-durango.com The contents of this owner ’s manual and all 本書の内容は著作権法により保護されています。 associated material are copyright © Team Durango Ltd.
  • Page 44 2011.
