ROTARY GLASSWASHER
INSTALLATION AND OPERATION
(GWR-24)
Printed in the USA
100 Haul Rd. Wayne, NJ 07470 • Toll Free: (800) 631-0442 • Fax: (973) 872-1129
sales@krowne.com • www.krowne.com • www.facebook.com/KrowneMetal • www.twitter.com/KrowneMetal
INSTRUCTION MANUAL
SERIAL NO.
Krowne Metal Corporation
MODEL: ROTATION:
GWR-24
CLOCKWISE
GWR-24L COUNTER-CLOCKWISE
DOOR & CONTROLS ON LEFT
GWR-24R CLOCKWISE
DOOR & CONTROLS ON RIGHT
Rev. 1/2012
No. GWR-1.00

Advertisement
