Call Saint Nuisance Call Blocker User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

1. Check Box Contents

(i)
Call Saint Nuisance Call Blocker
(ii) Call Saint Nuisance Call Blocker stand
(iii) Cable 1 (short cable): 15cm / RJ11 to BT socket adaptor
(iv) Cable 2 (long cable): 300cm / RJ11 to BT socket cable
The Call Saint Nuisance Call Blocker is powered by the phone line. No
plugs or batteries are required.
2. Plug In
Refer to the Quick Setup Guide (with images) or use the instructions below.
without ADSL Micro-filter...
Step 1
Plug the short cable supplied (RJ11 male to BT female) into the socket
marked "TO PHONE" (left socket) on the call blocker
Step 2
Unplug your telephone line cable from your telephone wall socket.
Step 3
Plug your telephone line cable into the other end of the short cable.
Step 4
Plug the long cable supplied (RJ11 male to BT male) into your telephone
wall socket.
Step 5
Plug the other end of the long cable into the socket marked "TO LINE"
(right socket) on the call blocker
User Guide
Page | 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Nuisance Call Blocker and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Call Saint Nuisance Call Blocker

Summary of Contents for Call Saint Nuisance Call Blocker

  • Page 1: Check Box Contents

    (iii) Cable 1 (short cable): 15cm / RJ11 to BT socket adaptor (iv) Cable 2 (long cable): 300cm / RJ11 to BT socket cable The Call Saint Nuisance Call Blocker is powered by the phone line. No plugs or batteries are required.

  • Page 2: User Guide

    Your Call Saint Nuisance Call Blocker is now ready to use. IMPORTANT: The Call Saint Nuisance Call Blocker will only work if you subscribe to a Caller ID service from your phone line provider. with ADSL Micro-filter…...

  • Page 3: Setting The Date And Time

    Your Call Saint Nuisance Call Blocker is now ready to use. IMPORTANT: The Call Saint Nuisance Call Blocker will only work if you subscribe to a Caller ID service from your phone line provider. 3. Set Up...

  • Page 4: Adjusting The Screen Brightness

    User Guide  Use the  and  buttons on the call blocker to select the correct day of the month and then press “SET”  Use the  and  to set the hours of the time (24 hour format) then press “SET”...
  • Page 5 User Guide  Press “REMOVE” on the call blocker if you want to delete the number from the list (to remove all numbers from the list press “REMOVE” on the call blocker and keep it pressed until the screen displays “NO CODE”) ...
  • Page 6 User Guide  Enter the number you want to block on your telephone. The number will be displayed on the call blocker screen  Press the  button on the call blocker to save the number  The screen will display “SAVE” and then “SUCCEED” ...
  • Page 7 User Guide unblock all numbers from the blocked outgoing caller list…  Press “BLACKLIST” on the call blocker and keep it pressed until the screen displays the last outgoing number that was blocked  Press “REMOVE” on the call blocker and keep it pressed until the screen displays “PASS”...
  • Page 8 User Guide  “-END-“ will appear when you have viewed the complete list of calls received  Press “SET” to exit viewing the list of calls received Block incoming calls (up to 1200 numbers) One-Touch Call Blocking: block a number from the calls received list… One-Touch Call Blocking cannot be used to block withheld numbers.
  • Page 9 User Guide Block a number during a call using your telephone… This feature allows you to block a number during a call using your telephone. This feature cannot be used to block withheld numbers. Details on how to block withheld numbers can be found further on in the User Guide.
  • Page 10 User Guide add another number…  Press “*” (star button) on your telephone  Enter the number you want to block on your telephone. The number will be displayed on the call blocker screen  Press the  button on the call blocker to save the number ...
  • Page 11 User Guide Block incoming dialling codes (up to 10 numbers) This feature allows you to block all incoming calls that start with a specific number. For example, block all calls that start with “00” to block international calls or block all calls that start with “08” to block callers that call from an 0800, 0845, 0870, etc…...
  • Page 12 User Guide Unblock incoming dialling codes  Press “SET” on the call blocker. The screen will display “SET 1234567”  Pick up your telephone so you can hear a dial tone (if you are using a cordless telephone, press the green telephone button) ...

  • Page 13: Changing The Pin

    User Guide Changing the PIN The default PIN is “0000”  Press “SET” on the call blocker. The screen will display “SET 1234567”  Pick up your telephone so you can hear a dial tone (if you are using a cordless telephone, press the green telephone button) ...

  • Page 14: Making And Receiving Calls

    User Guide Lock/Unlock the call blocker Lock the call blocker  Pick up your telephone so you can hear a dial tone (if you are using a cordless telephone, press the green telephone button)  Press “*” (star button) 000111 “#” (hash button) on your telephone ...

  • Page 15: Troubleshooting And Frequently Asked Questions

    User Guide Troubleshooting & Frequently Asked Questions For support and advice on the most frequently asked questions visit www.callsaint.co.uk/faqs Page | 15...
