Workrite PA4000 Assembly Instruction

PA4000 - Poise Twin Assembly Instructions
(PA3000 - Poise - Heavy Duty Arm + PATWIN-B Wing Bracket)
Use these instructions for the monitor attachment step on page 5 of the Poise Heavy Duty instructions.
A
Wing Bracket
Qty: 1
1
Attach Wing Bracket to Poise Arm
Remove Mounts (B) from Wing Bracket (A), then attach
Wing Bracket to the Poise - Heavy Duty forearm VESA 100
Mount using the four M4x10mm screws (C) (horizontal
orientation shown). Be sure to tighten securely. Attach
M4x8mm screw and washer (E) to lock pivot.
E
E
Horizontal
Note: It is strongly recommended to use the mounting screws provided by the monitor manufacturer. Due to the variety of monitor
!
mounting designs, the mounting holes at the back of the monitor might not be suitable for the M4 screws we have provided and could
cause damage to the Monitor.
B
Monitor Mount
Qty: 2
C
A
Vertical
E
C
M4x10mm Screw
Qty: 12
D
M4x6mm Screw
Qty: 10
2
Determine Mounting Configuration
There are five possible recommended configurations for
mounting - three with a horizontal orientation and two with
a vertical orientation. Choose the configuration you wish to
use, then orient your Mounts accordingly.
Workrite Ergonomics | 800.959.9675 www.workriteergo.com
F
M4x8mm Screw and M4x18mm Screw
Qty: 8
Washer
Qty: 1 each
G
Vertical
are positioned with two
fasteners at the top.
Horizontal
#1500155 - Rev C
⅜" Nylon Spacer
Qty: 8
When using
!
horizontal
orientation, be
sure Mounts
