Legend Industries 745 Clearview Front Kit Installation Instructions Manual

CSA approved for use ONLY with Valor Heater Models 738, 739
and RF24XB when installed in RA24ZC Zero Clearance Kit
WARNING
!
A barrier designed to reduce the risk of burns from the hot viewing
glass is provided with this appliance and shall be installed
for the protection of children and other at-risk individuals.
The 745 Clearview Front is designed to
be used along with an outer surround
trim (supplied separately).
The Clearview Front fi ts within the
outer surround trim and clips onto the
standard mounting brackets supplied
with the 738 and 739 heaters or the
RA24ZC Zero Clearance Kit.
The Clearview Front is compatible with
all outer surround trims and cast iron
surrounds available for use with the
738 and 739 heaters and the RA24ZC
Zero Clearance Kit.
4001761-08
© Copyright Miles Industries Ltd., 2014
L
EGEND
745 Clearview Front Kit

Installation Instructions

HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
Extension Baffl e
(738 only)
Window Trim
(738/739 only)

Overview

(Heater, outer trim, fret sold separately)
G3
IN STA LLER
Leave this manual
with the appliance.
CO N SUM ER
Retain this manual
for future reference.
Note: This kit must be installed
by a qualifi ed installer, service
agency or gas supplier. These
instructions are to be used in
conjunction with the fi replace
main installation instructions.
Convection Baffl e
(739 only)
Fret Barrier Screen
738, 739 or
RF24XB in
RA24ZC
3-Sided
Outer Trim
Clearview Front
