- Page 1 ICS2030 Cube Type H.264 Mega Pixel Wireless Network Camera Advanced Installation Guide Version 1.0...
-
Page 2: Preface
REFACE Thank you for purchasing ICS2030, a standalone system that can be connected directly to an Ethernet or Fast Ethernet network. Equipped with a megapixel CMOS sensor, the camera allows you to capture a wider field of view with a resolution of up to 1280 x 1024. - Page 3 This Advanced Installation Guide provides you with the instructions and illustrations on how to use your camera, which includes: Chapter 1 Introduction to Your Camera describes the features of the camera. You will also know the components and functions of the camera. Chapter 2 Hardware Installation helps you install the camera according to your application environment.
-
Page 4: Table Of Contents
Contents Preface ....................1 Chapter 1 Introduction To Your Camera ..........4 Checking the Package Contents ..........4 Getting to Know Your Camera........... 5 Features and Benefits..............7 System Requirement ..............9 Chapter 2 Hardware Installation............. 10 Installing the Camera Stand ............ 10 Connecting the Camera to LAN/WLAN........ -
Page 5: Chapter 1 Introduction To Your Camera
HAPTER NTRODUCTION AMERA 1.1 Checking the Package Contents Check the items contained in the package carefully. You should have the following: One ICS2030 One AC Power Adapter One External Antenna One Camera Stand One Ethernet Cable (RJ-45 type) ... -
Page 6: Getting To Know Your Camera
1.2 Getting to Know Your Camera Front and Right-side Panel Power LED indicates the camera is powered on with the steady amber light. Internal Microphone allows the camera to receive sound and voice. Infrared LEDs (x 6) allow your camera to Link LED indicates capture clear image in the camera’s network... -
Page 7: Back Panel
Back Panel Wireless Antenna Screw Hole is used to connect the camera stand. Audio-out Connector (for 2-way audio WPS Button* model) is used to is used to protect connect an external your WLAN. active speaker. DC Power Connector Ethernet Cable is used to connect the Connector is used to AC power adapter, in... -
Page 8: Features And Benefits
1.3 Features and Benefits H.264/MPEG4/MJPEG Multi-codec Supported The camera provides you with excellent images by the H.264/MPEG4/ MJPEG multi-codec selectable technology, allowing you to adjust image size and quality, and bit rate according to the networking environment. High Resolution Surveillance Equipped with a megapixel CMOS sensor, the high performance camera is designed for your professional surveillance and security applications. - Page 9 For iPhone application software, please search "iPuxCam" in the app store on iPhone to download and install. For Android application software, please visit the website: http://www.ipux.net to download and install. Multiple Platforms Supported The camera supports multiple network protocols, including TCP/IP, SMTP e-mail, HTTP, and other Internet related protocols.
-
Page 10: System Requirement
1.4 System Requirement Networking LAN: 10Base-T Ethernet or 100Base-TX Fast Ethernet; Auto-MDIX. WLAN: IEEE 802.11b/g/n Accessing the Camera using Web Browser Platform: Microsoft® Windows® 2000/XP/Vista/Win7 CPU: Intel Pentium III 800MHz or above RAM: 512MB ... -
Page 11: Chapter 2 Hardware Installation
HAPTER ARDWARE NSTALLATION 2.1 Installing the Camera Stand The camera comes with a camera stand, which uses a swivel ball screw head to lock to the camera’s screw hole. When the camera stand is attached, you can place the camera anywhere by mounting the camera through the three screw holes located in the base of the camera stand. -
Page 12: Connecting The Camera To Lan/Wlan
2.2 Connecting the Camera to LAN/WLAN Use the provided Ethernet cable to connect the camera to your local area network (LAN). When you connect the AC power adapter, the camera is powered on automatically. You can verify the power status from the Power LED on the front panel of the camera. - Page 13 If you use a wireless network in your application environment, you need to attach the included external antenna to the camera. When the camera is powered on, the camera will automatically search any access point with “default” SSID. Installing the antenna - 12 -...
-
Page 14: Applications Of The Camera
2.3 Applications of the Camera The camera can be applied in multiple applications, including: Monitor local and remote places and objects via Internet or Intranet. Capture still images and video clips remotely. Upload images or send email messages with the still images attached. -
Page 15: Chapter 3 Accessing The Camera
HAPTER CCESSING AMERA 3.1 Using IPFinder The camera comes with a conveniently utility, IPFinder, which is included in the Installation CD-ROM, allowing you to search the camera on your network easily. 1. Insert the Installation CD-ROM into your computer’s CD-ROM drive to initiate the Auto-Run program. -
Page 16: Accessing To The Camera
3.2 Accessing to the Camera Whenever you want to access the camera: 1. Since the default configuration of the camera is DHCP mode enabled, you are recommended to launch IPFinder to search the IP address that is assigned to the camera by the DHCP server, and then click Link to access the camera via the Web browser. - Page 17 After you login into the Web Configuration of the camera, the Main screen will appear as below: The Main screen of the Web Configuration provides you with many useful information and functions, including: ...
- Page 18 Compression Buttons: Select to transmit and record the video using H.264, MPEG4 or MJPEG compression. Function Buttons: Use these buttons to control the audio, video, and trigger functions. Manual Record allows you to record and save a video clip. ...
-
Page 19: Configuring The Ip Address Of The Pc
3.3 Configuring the IP Address of the PC If you are failed to access to the camera, please check the IP address of your computer. When you connect the camera to your computer directly to proceed with configuration of the camera, you need to set up the IP addresses to be in the same segment for the two devices to communicate. -
Page 20: Chapter 4 Configuring The Camera
HAPTER ONFIGURING AMERA 4.1 Using the Web Configuration You can access and manage the camera through the Web browser and the provided software application UltraView Pro. This chapter describes the Web Configuration, and guides you through the configuration of the camera by using the Web browser. To configure the camera, click on the Main screen of Web Configuration. -
Page 21: Quick Setup
4.2 Quick Setup 4.2.1 Using Smart Wizard The camera’s Smart Wizard lets you configure your camera easily and quickly. The wizard will guide you through the necessary settings with detailed instructions on each step. To start the wizard, click Smart Wizard in the left menu bar. Step 1. - Page 22 Step 3. Email Settings Enter the required information to be able to send email with image. Step 4. Wireless Networking Enter the required settings for wireless networking. - 21 -...
- Page 23 Step 5. Confirm Settings Click Apply to finish the wizard and reboot the camera. Click Prev to go back to the previous step(s) and change the settings; or click Cancel to end the wizard and discard the changes. 4.2.2 Using My Android The camera’s My Android wizard lets you set up your Android mobile and Google services (Google Talk and Picasa) easily and quickly.
- Page 24 Step 2. Setting Up Gmail Account Enter the Gmail account for your camera. Step 3. Setting Up Picasa Account Enter the Picasa account for your camera. Step 5. Confirm Settings Click Apply to finish the wizard and reboot the camera. Click Prev to go back to the previous step(s) and change the settings;...
-
Page 25: Basic Setup
4.3 Basic Setup The Basic menu contains three sub-menus that provide the system settings for the camera, such as the Camera Name, Location, Date & Time, and User management. 4.3.1 Basic >> System Basic: This item allows you to assign the camera name and location information. - Page 26 Indication LED: This item allows you to set the LED illumination as desired. There available options include: Normal, OFF, and Dummy. IR LED: This item allows you to set the IR LED control by selecting Auto or OFF. If you select OFF in the IR LED option, you can set the Start/ End Time to control the time to use the IR LED function.
- Page 27 General User - User Name: Enter the user’s name you want to add to use the camera. - Password: Enter the password for the new user. - UserList: Display the existing users of the camera. To delete a user, select the one you want to delete and click Delete.
-
Page 28: Network Settings
4.4 Network Settings The Network menu contains two sub-menus that provide the network settings for the camera, such as the IP Setting, DDNS Setting, IP Filter, and Wireless network. - 27 -... - Page 29 4.4.1 Network >> Network IP Setting: This item allows you to select the IP address mode and set up the related configuration. The default setting is DHCP mode enabled. - DHCP: Select this option when your network uses the DHCP server.
- Page 30 1. Select the Enable option to enable this feature. 2. Select the Provider from the pull-down list. 3. Enter the required information in the Host Name, User Name, and Password boxes. NOTE You have to sign up for DDNS service with the service provider before configuring this feature.
- Page 31 4.4.3 Network >> IP Filter The IP Filter setting allows the administrator of the camera to limit the users within a certain range of IP addresses to access the camera. To disable this feature, select the Disable option; otherwise, select the Accept option to assign the range of IP addresses that are allowed to access the camera, or select the Deny option to assign the range of IP addresses that are blocked to access the camera.
- Page 32 4.4.4 Network >> Wireless Setting The camera supports WLAN while you use the wireless network. Select the Enable option to enable this feature. Wireless - Network ID (SSID): Keep the default setting of this option to connect the camera to any access point under the infrastructure network mode.
- Page 33 List of searching results - Wireless Mode: Select the type of wireless communication for the camera: Infrastructure or Ad-Hoc. - Channel: Select the appropriate channel from the list. - Authentication: Select the authentication method to secure the camera from being used by unauthorized user: Open, Shared-key, WPA-PSK, and WPA2-PSK.
- Page 34 Encryption: Select the WEP option to enable the data encryption feature to secure the camera within the wireless network. Format: Once you enable the Encryption feature, you need to determine the encryption format by selecting ASCII or HEX. ASCII format causes each character you type to be interpreted as an eight-bit value.
- Page 35 4.4.5 Network >> Wireless >> WPS Setting WPS (Wi-Fi Protected Setup) sets a new standard of Wi-Fi security, providing a simplified secure network setup solution for the end users. WPS can be enabled by the following two options: 1. PIN Mode 2.
-
Page 36: Device Status
c. You need to press the WPS button on the router (or access point) within 120 seconds to complete the setup. Device Status Display the WPS configuration of the camera. The Power LED indicates the WPS connection status by: - blinking 3 times when the connection is built successfully. -
Page 37: Setting Up Video & Audio
4.5 Setting up Video & Audio The Video & Audio menu contains four sub-menus that provide the video and audio settings for the camera. 4.5.1 Video & Audio >> Camera Image Setting - Brightness: Adjust the brightness level from 0 ~ 100. - Saturation: Adjust the colors level from 0 ~ 100. - Page 38 - Light Frequency: Select the proper frequency according to the camera’s location to reduce the noise: 50Hz, 60Hz, or Outdoor. 4.5.2 Video & Audio >> Video H.264 - Video Resolution: Select the desired video resolution from the four formats: SXGA, VGA, QVGA and QQVGA. The higher setting (VGA) obtains better video quality while it uses more resource within your network.
- Page 39 - None IE Browser Viewer: If you are not using Internet Explorer as your Web browser, select Java Applet, Still Image, or Server Push for MJPEG setting. NOTE The camera supports H.264, MPEG4 and MJPEG compression. Please note that that MJPEG mode captures the images in JPEG format, which requires higher bandwidth to view smooth video.
- Page 40 4.5.4 Video & Audio >> Overlay / Mask This sub-menu is used to set the image overlay and mask feature of the camera. Image Overlay: This item allows you to set the image overlay. In the Image File option, click Browse to select the image file from your computer, and then click Upload.
- Page 41 4.5.6 Video & Audio >> Overlay / Mask >> Text Overlay This page is used to set the text overlay feature of the camera, including the following three options: date & time, heading text, and background transparency setting. Include Date & Time: Select this option to display the date &...
-
Page 42: Event Server Configuration
4.6 Event Server Configuration The Event Server menu contains four sub-menus that allow you to upload images to FTP, send emails that include still images, and store the images to a NAS system. When you complete the required settings for FTP, Email, or Network Storage, click Test to test the related configuration is correct or not. - Page 43 - User Name: Enter the user name to login into the FTP server. - Password: Enter the password to login into the FTP server. - Directory Path: Enter the destination folder for uploading the images. For example, /Test/. - Passive Mode: Select the Enable option to enable passive mode.
-
Page 44: Network Storage
- Receiver #2 Email Address: Enter the second email address of the user who will receive the email. - Send Email With: Select the attachment type that is to be added to the email. NOTE Due to the network environment, the camera may not upload number of images that you set. - Page 45 4.6.4 Event Server Setting >> Instant Message The camera supports the Jabber IM service, so that you can send an instant message once you have a Jabber account. For more information of Jabber, please visit the Jabber Website at: http://jabber.org/Main_Page. ...
- Page 46 4.6.5 Event Server Setting >> Picasa Setting The camera supports the Picasa upload service, so that you can send the camera’s image to your Picasa account once you have a Picasa account. Picasa Setting - User Name: Enter your user name to login into the Picasa account.
-
Page 47: Motion Detect
4.7 Motion Detect The Motion Detect menu contains the command and option that allow you to enable and set up the motion detection feature of the camera. The camera provides three detecting areas. To enable the detecting area, select Window 1/2/3 from the pull- down list, and then select Enable. -
Page 48: Event Configuration
4.8 Event Configuration The Event Config menu contains five sub-menus that provide the commands to configure event profiles. 4.8.1 Event Configuration >> General Setting General - Snapshot/Recording Subfolder: You can assign a descriptive name for the subfolder to save the captured image/video files. - Page 49 4.8.2 Event Configuration >> Arrange Schedule Profile Schedule Profile: This sub-menu displays the scheduled profile(s). To customize the profile, click Add and then enter a descriptive name for the profile in the prompt dialog window. After entering the profile name, click OK and the profile is added to the Schedule Profiles list.
- Page 50 - Start/End Time: Enter the start and end time and then click Add to assign a time period within in the selected weekday. 4.8.3 Event Configuration >> Motion Detect Trigger Motion Detect Trigger: Select the Enable option to enable the trigger function of the camera, so that you can send captured images within the detecting area to the FTP server, email receiver, or the Network Storage server.
-
Page 51: Tools
4.9 Tools The Tools menu provides the commands that allow you to restart or reset the camera. You can also backup and restore your configuration, and upgrade the firmware for the camera. Factory Reset: Click Reset to restore all factory default settings for the camera. - Page 52 Update Firmware: You can upgrade the firmware for your camera once you obtained a latest version of firmware. - Current Firmware Version: This item displays the current firmware version. - Select the firmware: Click Browse to locate the backup file and then click Update.
-
Page 53: Usb
4.10 USB The USB menu provides the information and controls of the connected USB device. USB Dismount: To safely remove the connected USB device, you can press the Unmount button for four seconds on the camera or click Dismount from this item. ... -
Page 54: Information
4.11 Information The Information menu displays the current configuration and events log of the camera. 4.11.1 System Information >> Device Information Display the Basic, Video & Audio, and Network settings of the camera. 4.11.2 System Information >> Logs The Logs table displays the events log recorded by the system. - 53 -... -
Page 55: Appendix
Appendix A.1 Specification Image Sensor Sensor 1/4” Color 1.3 Megapixel color CMOS Resolution 1280 x 1024 Min. Illumination 1.0 Lux Video Compression H.264 / MPEG4 / MJPEG Video resolution SXGA (1280 x 1024) @ 15fps VGA (640 x 480) @ 30fps QVGA (320 x 240) @ 30fps QQVGA (160 x 120) @ 30fps ... - Page 56 User Interface One RJ-45 port Antenna One external antenna One WPS button Reset One Reset button USB 2.0 port, with one unmount button; Power distribution: 500mA Max. LEDs Power LED (amber); Link LED (green) Audio Input Built-in MIC Output Headphone output jack (Mono) Codec...
-
Page 57: Glossary Of Terms
A.2 Glossary of Terms NUMBERS 10BASE-T 10BASE-T is Ethernet over UTP Category III, IV, or V unshielded twisted-pair media. 100BASE-TX The two-pair twisted-media implementation of 100BASE-T is called 100BASE-TX. ADPCM Adaptive Differential Pulse Code Modulation, a new technology improved from PCM, which encodes analog sounds to digital form. - Page 58 Communication Communication has four components: sender, receiver, message, and medium. In networks, devices and application tasks and processes communicate messages to each other over media. They represent the sender and receivers. The data they send is the message. The cabling or transmission method they use is the medium.
- Page 59 Enterprise An enterprise network consists of collections of network networks connected to each other over a geographically dispersed area. The enterprise network serves the needs of a widely distributed company and operates the company’s mission-critical applications. Ethernet The most popular LAN communication technology. There are a variety of types of Ethernet, including 10Mbps (traditional Ethernet), 100Mbps (Fast Ethernet), and 1,000Mbps (Gigabit Ethernet).
- Page 60 Short for hexadecimal refers to the base-16 number system, which consists of 16 unique symbols: the numbers 0 to 9 and the letters A to F. For example, the decimal number 15 is represented as F in the hexadecimal numbering system. The hexadecimal system is useful because it can represent every byte (8 bits) as two consecutive hexadecimal digits.
- Page 61 connection methods, you get connected to the computer that “owns” that IP address. ISP (Internet Service Provider) is a company that maintains a network that is linked to the Internet by way of a dedicated communication line. An ISP offers the use of its dedicated communication lines to companies or individuals who can’t afford the high monthly cost for a direct connection.
- Page 62 internal network appear to the Internet as a single address. For routing messages properly within your network, each device requires a unique IP address. But the addresses may not be valid outside your network. NAT solves the problem. When devices within your network request information from the Internet, the requests are forwarded to the Internet under the router's IP address.
- Page 63 Protocol Communication on the network is governed by sets of rules called protocols. Protocols provide the guidelines devices use to communicate with each other, and thus they have different functions. Some protocols are responsible for formatting and presenting and presenting data that will be transferred from file server memory to the file server’s net work adapter Others are responsible for filtering information between networks and forwarding data to its destination.
- Page 64 Server It is a simple computer that provides resources, such as files or other information. SIP (Session Initiated Protocol) is a standard protocol that delivers the real-time communication for Voice over IP (VoIP), which establishes sessions for features such as audio and video conferencing. SMTP The Simple Mail Transfer Protocol is used for Internet mail.
- Page 65 The User Datagram Protocol is a connectionless protocol that resides above IP in the TCP/IP suite User Name The USERNAME is the unique name assigned to each person who has access to the LAN. Utility It is a program that performs a specific task. Unshielded twisted-pair.
