Summary of Contents for Time Gaurd SLB44
- Page 1 6 0 W P I R L A N T E R N L I G H T S L B 4 4 - B l a c k / S L W 4 5 - W h i t e...
- Page 2 SLB44 LAMP TYPE PIR LANTERN LIGHT - BLACK 60w ES WEATHERPROOF MAXIMUM IP43 PIR SWITCHING MAXIMUM DETECTION ANGLE TIME ON 110° 5sec 5min ADJUSTABLE ADJUSTABLE DUSK TO DAWN DETECTION RANGE ADJUSTABLE ADJUSTABLE 3 YEAR GUARANTEE In the unlikely event of this product becoming faulty due to defective material or manufacture, within 3 years of the date of purchase, please return it to your supplier with proof of purchase and it will be replaced free of charge.
- Page 3 SLW45 LAMP TYPE PIR LANTERN LIGHT - WHITE 60w ES WEATHERPROOF MAXIMUM IP43 PIR SWITCHING MAXIMUM DETECTION ANGLE TIME ON 110° 5sec 5min ADJUSTABLE ADJUSTABLE DUSK TO DAWN DETECTION RANGE ADJUSTABLE ADJUSTABLE 3 YEAR GUARANTEE In the unlikely event of this product becoming faulty due to defective material or manufacture, within 3 years of the date of purchase, please return it to your supplier with proof of purchase and it will be replaced free of charge.
-
Page 4: General Information
SECTION ONE GENERAL INFORMATION The unit utilises passive infrared technology to detect heat radiation of moving human bodies. During the hours of darkness the unit fully illuminates when it senses movement within its detection field. PARTS INCLUDED - Luminaire c/w PIR Sensor unit. - Instruction manual. -
Page 5: Installation
SECTION THREE INSTALLATION After choosing a suitable location (see previous section) install the unit as follows: The unit is suitable for connection to a 230 V ac 50Hz electricity supply. It is suggested that 3-core round flexible cable of 1mm gauge is used. - Page 6 CONNECTION Connect the cable to the terminal block on the unit as follows (see connection diagram): NEUTRAL (Blue) EARTH (Green/Yellow) LIVE (Brown) Ensure that the connections are secure. Fasten the lantern to the backplate using the domed nuts, ensuring the wiring box seal is correctly in place. Install the lightbulb (not supplied).
-
Page 7: Operation And Testing
SECTION FOUR OPERATION AND TESTING WALK TESTING PROCEDURE The sensor will rotate from left to right. Adjust the sensor to point in the desired direction. Set the two adjustment controls on the rear of the unit (diagram C) to the following positions: DUSK - Fully clockwise TIME - Fully anti-clockwise... -
Page 8: Technical Specifications
SECTION FIVE TECHNICAL SPECIFICATIONS Detection Range Up to 8 metres Detection Angle 110º Power Supply 230 V AC ~ 50Hz Not suitable for energy Lamp Type 230V 60W (max) GLS ES saving lamps Time On Adjustment 5 seconds - 5 minutes Dusk Level Adjustment Day &... -
Page 9: Troubleshooting Guide
SECTION SIX TROUBLESHOOTING GUIDE PROBLEM SOLUTION Lamp stays ON all the time The unit may be suffering from false activation. Cover the sensor lens completely with a thick cloth. This will prevent at night. the sensor from "seeing" anything. If the unit now switches off after the set time duration and does not re- activate, this indicates that the problem was caused by PIR keeps activating for no... - Page 10 TOP VIEW 110º Less sensitive More SIDE VIEW sensitive 2.5m Remove cover (using a small screwdriver and lift up gently) to reveal adjustment controls To replace cover simply line up and click back into position...
-
Page 11: Product Range
Floodlight - Black White SLB150 SLW89 150W PIR 60W PIR Halogen Bulkhead Floodlight - Light - Black White SLW150 SLB44 150W PIR 60W PIR Halogen Lantern Floodlight - Light - White Black SLB2000 SLW45 2000W PIR 60W PIR Light Lantern... - Page 12 Helpline 020-8450-0515 For a product brochure please contact: Timeguard Ltd. Victory Park, 400 Edgware Road, London NW2 6ND or email csc@timeguard.com...
